Johnson Controls FMS-2000C Installation Manual page 47

FMS-2000C
Object instance
ADF-59
ADF-60
ADF-61
ADF-62
Table 39: Internal integer values for integration in a BMS
Object instance
ADI-1
ADI-2
ADI-7
ADI-8
ADI-9
ADI-10
ADI-11
ADI-12
Technical specifications
Intended use
Overvoltage category
Altitude
Pressure range
Alarm range
Display range
Accuracy
Air flow sensor type
Flow control resolution
Displayed pressure resolution
Control capability
I/O Resources
Operating temperature
Operating humidity
Mounting
Alarm indication
Alarm silence
Password protection
Communications protocol
Internal float values
AI-2 deadband setting
AI-3 deadband setting
AI-4 deadband setting
TI-1 deadband setting
Internal integer values
AI-1 isolation mode: 1 = positive, 2 = negative, 3 = neutral
AI-1 alarm status: 1 = normal, 2 = warning, 3 = alarm
AI-2 isolation mode: 1 = positive, 2 = negative, 3 = neutral
AI-2 alarm status: 1 = normal, 2 = warning, 3 = alarm
AI-3 alarm status: 1 = normal, 2 = warning, 3 = alarm
AI-4 alarm status: 1 = normal, 2 = warning, 3 = alarm
TI-1 alarm status: 1 = normal, 2 = warning, 3 = alarm
TI-2 alarm status: 1 = normal, 2 = warning, 3 = alarm
Indoor use
II
Up to 2000 m
± 0.2500 in. W.C.
± 0.2500 in. W.C.
± 0.2500 in. W.C.
± 0.5% full scale
Digital differential pressure features no offset, zero drift and is hysteresis free
± 0.0010 in. W.C.
± 0.0001 in. W.C.
Up to 4 independent spaces
4 universal inputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
2 thermistor inputs (NTC Type 2 or 3, 10K at 77° F)
4 digital inputs (active-high or active-low 0 VDC to 5 VDC or 0 VDC to 24 VDC)
4 universal outputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
4 relay outputs (NO or NC contacts 1A at 24 VDC)
32°F to 125°F (0°C to 52°C)
10% to 95% relative humidity, non-condensing
Thin mount for shallow wall cavities, surface mount for mounting to standard single-gang wall box
360° Safety Halo color coded visual, audible alarm
Touchscreen, auto-reset
Up to 50 user passwords with 2 access levels (administrator and restricted)
BACnet MS/TP (to BAS) 76.8k, 38.4k, 19.2k, 9600 baud, Metasys N2 open
47
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read only
Read or write
Read only
Read only
Read only
Read only
Read only
LIT-12013508
