Configuring display module settings

Table 20: Options DIP switch S2 mode configuration
Product type
Mode select
Operational mode

Configuring main controller module settings

Table 21: Analog input configuration DIP switch S1
Switch position
1 AI-1 mode selection
2 AI-2 mode selection
3 AI-3 mode selection
4 AI-4 mode selection
5 AI-1 voltage range selection
6 AI-2 voltage range selection
7 AI-3 voltage range selection
8 AI-4 voltage range selection
Notes: • To configure the FMS-2000C controller for a remote sensor, set the DIP switch position 1 ON and DIP switch position 5
OFF. See Table 24 for other inputs.
• FMS-1655 Remote Pressure Controller flush mount with internal sensor does not support the FMS-2000C controller display.
Table 22: Analog output configuration DIP switch S3
Switch position
1 AO-1 mode selection
2 AO-2 mode selection
3 AO-3 mode selection
4 AO-4 mode selection
Table 23: Network configuration DIP switch S3
RS485 network termination
RS485 display termination
Note: See Table 25 for protocol selection settings.
OFF = FMS
OFF = FMS-2000C
OFF = Demo mode
Configuration setting
Configuration setting
OFF = disabled
OFF = disabled
OFF position
OFF = voltage input
OFF = voltage input
OFF = voltage input
OFF = voltage input
OFF = 0 VDC - 5 VDC
OFF = 0 VDC - 5 VDC
OFF = 0 VDC - 5 VDC
OFF = 0 VDC - 5 VDC
OFF position
OFF = current output
OFF = current output
OFF = current output
OFF = current output
40
ON = N/A
ON = N/A
ON = Run mode
ON position
ON = current input
ON = current input
ON = current input
ON = current input
ON = 0 VDC - 10 VDC
ON = 0 VDC - 10 VDC
ON = 0 VDC - 10 VDC
ON = 0 VDC - 10 VDC
ON position
ON = voltage output
ON = voltage output
ON = voltage output
ON = voltage output
ON = enabled
ON = enabled
