Johnson Controls FMS-2000C Installation Manual page 46

FMS-2000C
Object instance
ADF-15
ADF-16
ADF-17
ADF-18
ADF-19
ADF-20
ADF-21
ADF-22
ADF-23
ADF-24
ADF-25
ADF-26
ADF-27
ADF-28
ADF-29
ADF-30
ADF-31
ADF-32
ADF-33
ADF-34
ADF-35
ADF-36
ADF-37
ADF-38
ADF-39
ADF-40
ADF-41
ADF-42
ADF-43
ADF-44
ADF-45
ADF-46
ADF-47
ADF-48
ADF-49
ADF-50
ADF-51
ADF-52
ADF-53
ADF-54
ADF-55
ADF-56
ADF-57
ADF-58
Internal float values
PID control loop 4 setpoint
Air change rate based on flow input at AI-1
Air change rate based on flow input at AI-2
Air change rate based on flow input at AI-3
Air change rate based on flow input at AI-4
Alarm relay 3 high setpoint
Alarm relay 3 low setpoint
Alarm relay 4 high setpoint
Alarm relay 4 low setpoint
AI-2 low alarm setpoint
AI-2 low warning setpoint
AI-2 high warning setpoint
AI-2 high alarm setpoint
AI-3 low alarm setpoint
AI-3 low warning setpoint
AI-3 high warning setpoint
AI-3 high alarm setpoint
AI-4 low alarm setpoint
AI-4 low warning setpoint
AI-4 high warning setpoint
AI-4 high alarm setpoint
TI-1 low alarm setpoint
TI-2 low warning setpoint
TI-1 high warning setpoint
TI-1 high alarm setpoint
TI-2 high alarm setpoint
TI-2 low warning setpoint
TI-2 high warning setpoint
TI-2 high alarm setpoint
Humidity network variable, writable
Temperature network variable, writable
Air changes network variable, writable
Differential pressure network variable, writable
Air flow based on flow input at AI-1
Air flow based on flow input at AI-2
Air flow based on flow input at AI-3, default: supply flow
Air flow based on flow input at AI-4, default: exhaust flow
Volumetric offset, supply flow - exhaust flow
Volumetric offset setpoint
AO-1 override level
AO-2 override level
AO-3 override level
AO-4 override level
AI-1 deadband setting
46
Read or write
Read or write
Read only
Read only
Read only
Read only
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read only
Read only
Read only
Read only
Read only
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
