- Page 1 EasyIO FW-28 Quick Start Guide Building Technology and Solutions LIT-12013879 www.johnsoncontrols.com 2022-03-15...
- Page 2 EasyIO FW-28 Quick Start Guide...
-
Page 3: Table Of Contents
Establishing a connection to a controller with Wi-Fi............... 14 Interfacing with a controller's web server..................15 Interfacing with controller objects using CPT.................. 15 Related documents............................16 Technical specifications..........................17 Regulatory compliance..........................17 Product warranty............................18 Contact information............................18 Patents................................18 Single point of contact...........................18 EasyIO FW-28 Quick Start Guide... - Page 4 EasyIO FW-28 Quick Start Guide...
-
Page 5: Overview
• Connect to the controller with a LAN or Wi-Fi connection • Connect to the controller with the CPT application • Connect to the controller's web server dashboard with CPT Graphics Figure 1: FW-28 legend front view EasyIO FW-28 Quick Start Guide... - Page 6 EasyIO FW Series User Reference. Service button Universal Output (UO) and COM (Common) terminals Antenna connectors Serial port terminals DIN rail end clips Antennas Ethernet ports Universal Input (UI) and COM terminals Mounting clips EasyIO FW-28 Quick Start Guide...
-
Page 7: Physical Dimensions
• In an area with excessive moisture, corrosive fumes, or explosion vapors • Where excessive vibration or shock occurs • In locations with excessive electrical noise, such as large magnetic interference, or variable speed drive modules EasyIO FW-28 Quick Start Guide... -
Page 8: Mounting The Controller On A 35Mm Din Rail
Hang the top mounting clip on the DIN rail and then place the controller on the DIN rail. Figure 6: Placing the controller on the DIN rail To secure the controller to the DIN rail, close the mounting clip. EasyIO FW-28 Quick Start Guide... - Page 9 Figure 7: Closing the mounting clips (rear view) Optional: For added security, use DIN rail end clips. For more information, see DIN rail end clips in Table 1. EasyIO FW-28 Quick Start Guide...
-
Page 10: Mounting The Controller To An Enclosure Base Plate
To connect the male antenna connectors to the a female RP-SMA jacks, screw on the antennas in a clockwise direction. Note: For a secure connection, when you tighten the antennas to the female RP-SMA jack, hold the metal part of the RP-SMA male connector. A poor connection reduces reception. EasyIO FW-28 Quick Start Guide... -
Page 11: Removing The Controller Cover
Use a Philips screwdriver to unscrew both of the top cover screws. Figure 10: Unscrewing the cover Hold both ends of the top cover and remove it. If the the top cover is stuck, separate the cover with a standard screwdriver. EasyIO FW-28 Quick Start Guide... -
Page 12: Wiring And Connecting Controllers
For more information on the following topics, refer to the EasyIO FW Series User Reference: • Powering the controller • Jumpers • Creating a network of controllers with the following methods: - Daisy chaining controllers - Connecting controllers with Wi-Fi • Network connection best practices • Site coverage EasyIO FW-28 Quick Start Guide... -
Page 13: Wiring Diagram
120 Ohm resistor in parallel with the RS-485 terminal. Voltage transmitter 0 V to 10 V or 0 V to 5 V Switch Thermistor, RTD, or potentiometer EasyIO FW-28 Quick Start Guide... -
Page 14: Controller Interfacing
MAC address on the label on the back of the controller. Enter the default password. For more information, contact your supplier. To ping the controller, at the command line, enter ping, followed by the controller's IP address. EasyIO FW-28 Quick Start Guide... -
Page 15: Interfacing With A Controller's Web Server
Note: By default, there is no password. To increase security, when you log on, complete the steps in Creating a new CPT admin password for a controller in EasyIO Hardening Guide. What to do next: For more information on CPT, Refer to EasyIO CPT User Guide. EasyIO FW-28 Quick Start Guide... -
Page 16: Related Documents
EasyIO FW Series SQL Lite EasyIO F Series Dashboard User Guide EasyIO F Series MQTT User Guide EasyIO FW Series BACnet User Guide EasyIO FW Series Modbus User Guide EasyIO FW Antenna Datasheet EasyIO FW Series SQL Lite EasyIO FW-28 Quick Start Guide... -
Page 17: Technical Specifications
-4°F to 150°F or -20°C to 65 °C Operating humidity 10% to 70% relative humidity, non-condensing Regulatory compliance Table 7: Regulatory compliance Standards UL 916 Energy Management Equipment FCC Class B, Part 15, Subpart C 15.247 CE Compliance EasyIO FW-28 Quick Start Guide... -
Page 18: Product Warranty
GLENDALE, WI 53209 WUXI JIANGSU PROVINCE 214028 THE NETHERLANDS MANCHESTER CHINA M40 2WL UNITED KINGDOM © 2021 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice.
