FMS-2000C

BACnet objects

See Table 28 to Table 33 for a list of points available for integration in a building management system (BMS). They contain the objects
for open BACnet integration.
Table 28: Analog inputs for integration in a BMS
Object
AI-1
AI-2
AI-3
AI-4
AI-5
AI-6
Table 29: Analog outputs for integration in a BMS
Object
AO-1
AO-2
AO-3
AO-4
Table 30: Binary inputs for integration in a BMS
Object
BI-1
BI-2
BI-3
BI-4
Table 31: Binary outputs for integration in a BMS
Object
BO-1
BO-2
BO-3
BO-4
Table 32: Analog values for integration in a BMS
Object
AV-1
AV-2
AV-3
AV-4
AV-5
AV-6
AV-7
AV-8
AV-9
AV-10
AV-11
Analog inputs
Analog input 1, default: isolation pressure
Analog input 2
Analog input 3
Analog input 4
Thermistor input 1
Thermistor input 2
Analog outputs
Analog output 1, default: damper position
Analog output 2, default: anteroom damper control
Analog output 3, spare control output
Analog output 4, spare control output
Binary inputs
Digital input 1, default: door switch
Digital input 2, default: anteroom door switch
Digital input 3, spare digital input
Digital input 4, spare digital input
Binary outputs
Relay output 1, default: primary alarm relay output
Relay output 2, default: spare relay output
Relay output 3, spare relay output
Relay output 4, spare relay output
Analog values
AI-1 setpoint for room pressure
AI-2 setpoint
AI-3 setpoint
AI-4 setpoint
TI-1 setpoint
TI-2 setpoint
Air change rate based on flow input at AI-1
Air change rate based on flow input at AI-2
Air change rate based on flow input at AI-3
Air change rate based on flow input at AI-4
Alarm relay 1 high setpoint
42
Read or write
Read only
Read only
Read only
Read only
Read only
Read only
Read or write
Read only
Read only
Read only
Read only
Read or write
Read only
Read only
Read only
Read only
Read or write
Read only
Read only
Read only
Read only
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read or write
Read only
Read only
Read only
Read only
Read or write
