ADLINK Technology ETX Series User Manual page 19

X3: CRT, LCD (LVDS), & Video
Pin Signal
1 GND
3 R
5 HSY
7 VSY
9 NC
11 LCD16
13 LCD17
15 GND
17 LCD13
19 LCD12
21 GND
23 LCD8
25 LCD9
27 GND
29 LCD4
31 LCD5
33 GND
35 LCD1
37 LCD0
39 5VCC
41 JILI_SDA
43 JILI_SCL
45 NC
47 COMP
49 NC
ETX-CV User's Manual
ETX-CV User's Manual
Pin Signal
2 GND
4 B
6 G
8 DDCK
10 DDDA
12 LCD18
14 LCD19
16 GND
18 LCD15
20 LCD14
22 GND
24 LCD11
26 LCD10
28 GND
30 LCD7
32 LCD6
34 GND
36 LCD3
38 LCD2
40 5VCC
42 LTGO0
44 BLON#
46 DIGON
48 Y
50 C
X3
First LVDS Channel
Signal LVDS Signal
LCD0 Txout 0-
LCD1 Txout 0+
LCD2 Txout 1-
LCD3 Txout 1+
LCD4 Txout 2-
LCD5 Txout 2+
LCD6 Txclk -
LCD7 Txclk +
LCD8 Txout 3-
LCD9 Txout 3+
Second LVDS Channel
Signal LVDS Signal
LCD10 Txout 0-
LCD11 Txout 0+
LCD12 Txout 1-
LCD13 Txout 1+
LCD14 Txout 2-
LCD15 Txout 2+
LCD16 Txclk -
LCD17 Txclk +
LCD18 Txout 3-
LCD19 Txout 3+
Page 19
Page 19
99 100
1 2
