7.3

Interrupt Request (IRQ) Lines

PIC Mode
IRQ# Typical Interrupt Resource
0 Counter 0
1 Keyboard controller
2 Cascade interrupt from slave PIC
3 Serial Port 2 (COM2) / PCI
4 Serial Port 1 (COM1) / PCI
5 Parallel Port 2 (LPT2) / PCI
6 Floppy Drive Controller
7 Parallel Port 1 (LPT1) / PCI
8 Real-time clock
9 SCI / PCI
10 PCI
11 PCI
12 PS/2 Mouse / PCI
13 Math Processor
14 Primary IDE controller / PCI
15 Secondary IDE controller / PCI
(1) These IRQs can be used for PCI devices when onboard device is disabled.
APIC Mode
IRQ# Typical Interrupt Resource
0 Counter 0
1 Keyboard controller
2 Cascade interrupt from slave PIC
3 Serial Port 2 (COM2) / PC
4 Serial Port 1 (COM1) / PCI
5 Parallel Port 2 (LPT2) / PCI
6 Floppy Drive Controller
7 Parallel Port 1 (LPT1) / PCI / ISA
8 Real-time clock
9 SCI / PCI
10 PCI
11 PCI
12 PS/2 Mouse / PCI
13 Math Processor
14 Primary IDE controller / PCI
Page 34
Connected to Pin
N/A
N/A
N/A
IRQ3 via SERIRQ
IRQ4 via SERIRQ
IRQ5 via SERIRQ
IRQ6 via SERIRQ
IRQ7 via SERIRQ,
N/A
IRQ9 via SERIRQ
IRQ10 via SERIRQ
IRQ11 via SERIRQ
IRQ12 via SERIRQ
N/A
IRQ14 via SERIRQ
IRQ15 via SERIRQ
Connected to Pin
N/A
N/A
N/A
IRQ3 via SERIRQ
IRQ4 via SERIRQ
IRQ5 via SERIRQ
IRQ6 via SERIRQ
IRQ7 via SERIRQ
N/A No
IRQ9 via SERIRQ
IRQ10 via SERIRQ
IRQ11 via SERIRQ
IRQ12 via SERIRQ
N/A
IRQ14 via SERIRQ
ETX-CV User's Manual
Available
No
No
No
Note (1)
Note (1)
Note (1)
No
Note (1)
No
Note (1)
Note (1)
Note (1)
Note (1)
No
Note (1)
Note (1)
Available
No
No
No
Note (1)
Note (1)
Note (1)
No
Note (1)
Note (1),
Note (1)
Note (1)
Note (1)
No
Note (1)
