6.3 Pin Definitions

X1: PCI-bus, USB, & Audio
Pin Signal
1 GND
3 PCICLK3
5 GND
7 PCICLK1
9 REQ3#
11 GNT2#
13 REQ2#
15 REQ1#
17 GNT0#
19 5VCC
21 SERIRQ
23 AD0
25 AD1
27 AD4
29 AD6
31 CBE0#
33 AD8
35 GND
37 AD10
39 AD11
41 AD12
43 AD13
45 AD14
47 AD15
49 CBE1#
The 3V (3.3 V ±5%) is generated onboard. Pins may be used to power devices on the
carrier board up to a maximum load of 500 mA.
Do not connect the 3V pin to external 3.3V supply power.
ETX-CV User's Manual
ETX-CV User's Manual
Pin Signal
2 GND
4 PCICLK4
6 GND
8 PCICLK2
10 GNT3#
12 3V
1
14 GNT1#
16 3V
1
18 RSV
20 5VCC
22 REQ0#
24 3V
1
26 AD2
28 AD3
30 AD5
32 AD7
34 AD9
36 GND
38 AUXAL
40 MIC
42 AUXAR
44 ASVCC
46 SDNL
48 ASSGND
50 SNDR
X1
Pin Signal Pin
51 5VCC 52
53 PAR 54
55 GPERR 56
57 PME# 58
59 LOCK# 60
61 TRDY# 62
63 IRDY# 64
65 FRAME# 66
67 GND 68
69 AD16 70
71 AD17 72
73 AD19 74
75 AD20 76
77 AD22 78
79 AD23 80
81 AD24 82
83 5VCC 84
85 AD25 86
87 AD28 88
89 AD27 90
91 AD30 92
93 PCIRST# 94
95 INTC# 96
97 INTA# 98
99 GND 100
99 100
1 2
Signal
5VCC
SERR#
RSV
USB2-
DEVSEL#
USB3-
STOP#
USB2+
GND
CBE2#
USB3+
AD18
USB0N
AD21
USB1-
CBE3#
5VCC
AD26
USB0+
AD29
USB1+
AD31
INTD#
INTB#
GND
