X2: ISA Bus
Pin Signal
1 GND
3 SD14
5 SD13
7 SD12
9 SD11
11 SD10
13 SD9
15 SD8
17 MEMW#
19 MEMR#
21 LA17
23 LA18
25 LA19
27 LA20
29 LA21
31 LA22
33 LA23
35 GND
37 SBHE#
39 SA0
41 SA1
43 SA2
45 SA3
47 SA4
49 SA5
1 IRQ12 is reserved for a PS/2 mouse.
Page 18
Pin Signal
2 GND
4 SD15
6 MASTER#
8 DREQ7
10 DACK7#
12 DREQ6
14 DACK6#
16 DREQ5
18 DACK5#
20 DREQ0
22 DACK0#
24 IRQ14
26 IRQ15
28 IRQ12
1
30 IRQ11
32 IRQ10
34 IO16#
36 GND
38 M16#
40 OSC
42 BALE
44 TC
46 DACK2#
48 IRQ3
50 IRQ4
X2
Pin Signal Pin
51 5VCC 52
53 SA6 54
55 SA7 56
57 SA8 58
59 SA9 60
61 SA10 62
63 SA11 64
65 SA12 66
67 GND 68
69 SA13 70
71 SA14 72
73 SA15 74
75 SA16 76
77 SA18 78
79 SA19 80
81 IOCHRDY 82
83 5VCC 84
85 SD0 86
87 SD2 88
89 SD3 90
91 DREQ2 92
93 SD5 94
95 SD6 96
97 IOCHK# 98
99 GND 100
ETX-CV User's Manual
99 100
1 2
Signal
5VCC
IRQ5
IRQ6
IRQ7
SYSCLK
REFSH#
DREQ1
DACK1#
GND
DREQ3
DACK3#
IOR#
IOW#
SA17
SMEMR#
AEN
5VCC
SMEMW#
SD1
NOWS#
SD4
IRQ9
SD7
RSTDRV
GND
