X4: IDE1, IDE2, Ethernet, & Miscellaneous
Pin Signal
1 GND
3 5V_SB
5 PS_ON
7 PWRBTN#
9 KBINH
11 RSMRST#
1
13 ROMKBCS#
15 EXT_PRG
2
17 5VCC
19 OVCR#
21 EXTSMI#
23 SMBCLK
3
25 S_CS3#
27 S_CS1#
29 S_A2
31 S_A0
33 GND
35 PDIAG_S
37 S_A1
39 S_INTRQ
41 BATLOW#
2
43 S_AK#
45 S_RDY
47 S_IOR#
49 5VCC
May be affected by external circuitry to reset the power management logic of the ETX
1
module. Most designs do not use and pin is not connected.
Reserved, do not connect
2
See also: section 7.7 System Management Bus (I2C-compatible)
3
ETX-CV User's Manual
ETX-CV User's Manual
Pin Signal
2 GND
4 PWGIN
6 SPEAKER
8 BATT
10 LILED#
12 ACTLED#
14 SPDLED#
2
16 I2CLK
3
18 5VCC
20 NC
22 I2DAT 3
24 SMBDATA
3
26 SMBALRT#
28 NC
30 P_CS3#
32 P_CS1#
34 GND
36 P_A2
38 P_A0
40 P_A1
42 GPE1#
2
44 P_INTRQ
46 P_AK#
48 P_RDY
50 5VCC
X4
Pin Signal Pin
51 S_IOW# 52
53 S_DRQ 54
55 S_D15 56
57 S_D0 58
59 S_D14 60
61 S_D1 62
63 S_D13 64
65 GND 66
67 S_D2 68
69 S_D12 70
71 S_D3 72
73 S_D11 74
75 S_D4 76
77 S_D10 78
79 S_D5 80
81 5VCC 82
83 S_D9 84
85 S_D6 86
87 S_D8 88
89 GPE2# 90
2
91 RXD# 92
93 RXD 94
95 TXD# 96
97 TXD 98
99 GND 100
99 100
1 2
Signal
P_IOR#
P_IOW#
P_DRQ
P_D15
P_D0
P_D14
P_D1
GND
P_D13
P_D2
P_D12
P_D3
P_D11
P_D4
P_D10
5VCC
P_D5
P_D9
P_D6
CBLID_P#
P_D8
S_D7
P_D7
HDRST#
GND
