Note:
A single empty direct select tile may remain if the adjacent direct select tiles
are not sequential. This is to allow an easy way to insert a new direct select between
the existing ones.
[Shift] & Direct Select
Selecting record targets from direct selects will terminate the command line. To post a control to
the command line without terminating it, hold down [Shift] while pressing the direct select. This
allows multiple commands to be selected and executed at once, and an optional sneak time to
be entered.

Moving Light Controls

A display tool for controlling the non-intensity parameters (NPs) of multiple parameter devices is
the ML Controls. The ML Controls are on Tab 5, or the display can be opened in the CIA by
pressing the [ML Controls] button.
Note:
A popup window version of the ML Controls can be opened for quick access of
these controls. See
You will need to have a multi-parameter device selected to properly view this display. The
display will change based on the device selected. If you have a device that only has intensity
and color parameters, the ML Control display will only show intensity and color parameters.
Note:
Controls available in this display will change based on the fixture selected.
When there is room, multiple rows of parameters will display, and you can scroll the display
vertically.
There are category shortcut keys on the left side of the ML Controls display. Press a key to
quickly access those controls.
1. Category button (Clicking this button will put the category on the command line.)
2. Parameter button (Clicking the button will put the parameter on the command line.)
3. Home button allows you to home a specific parameter or attribute of a parameter.
4. Parameter attributes
5. Selects the color picker.
6. Scroll through a fixture's available categories.
7. Collapses or expands categories.
8. Gives pan and tilt functionality to a mouse or trackball.
9. Virtual encoder (Click and hold close to the center line for slow movement, further away
for faster movement.)
10. Opens the gel picker.
System Basics
Popup ML Controls (on page 36)
