Note:
Changes to these settings may require a restart. When required, a warning
message indicating a needed restart will display.
Local DMX
The following settings are available:
Enable - enables DMX output from the local DMX ports.
•
Default Output Protocol - enables DMX as a default output.
•
Output in Client Mode - allows for output in offline mode for use with a visualization
•
program.
Dimmer Doubled Offset - this offset matches the default offset in CEM+ / CEM3 when
•
configuring your Sensor dimmer rack for dimmer doubling. The default offset is 20,000.
Sensor Classic racks should be set to an offset of 256.
The following settings can be edited within the table by clicking on a cell:
Address - sets the starting address for the port.
•
RDM - enables RDM on the port.
•
Doubled - enables dimmer doubling on the port.
•
Speed - sets the speed for the ports. Options are: maximum, fast, medium, and slow. The
•
speed may need to be adjusted for certain devices. The default speed is maximum.
Note:
In-cell editing must be enabled to be able to make changes to the table. See
In-Cell Editing (on page 144)
Remotes
The {Allow Remotes} button is for allowing Net3 RFR, iRFR, and aRFR connections. The default
setting is "Enabled". For more information see
Partitions
Pressing the {Partitions} button in system setup opens the partition display in the CIA. This
display shows any recorded partitions, including the four pre-existing partitions. For more
information, see
Users
In this display, you can set the User ID for the console by selecting the {User ID} button and
entering a number from the keypad. You can also add or delete users from this display.
For more information on User ID see
Recall User Settings
When multiple users are in a system, this option allows you to select a user to recall their
settings.
The following settings will be recalled:
Manual Time
•
Sneak Time
•
Go to Cue Time
•
Back Time
•
Assert Time
•
Timing Disable Time
•
Setup
Using Partitions (on page 391)
About User ID (on page 396)
RFR (on page 423)
.
.
.
