Setting Parameters with the Keypad
When the CIA is placed in parameter mode, all parameters of selected channels may be given
numeric values through the keypad.
When no channels are selected, the CIA shows all of the parameters that are available in the
lighting system. When channels are selected, the CIA condenses to show only the parameters
that are appropriate to the selection set. If channels are selected that have different device
types, such as spot and wash lights, the CIA will show all of the available parameters.
The following examples illustrate how to set parameter values with the keypad:
[5] {Iris} [5] {Zoom} [6] [5] {Edge} [5] [Enter] - sets channel 5 to an iris value of 50%, a
•
zoom value of 65%, and an edge value of 50%.
Using [At] [/] [/] will place the direct DMX value on the command line. For example, [1] [At] [/]
[/] [2][3][9] [Enter] would put channel 1 at DMX value 239.
You can also set a channel's parameter levels with the DMX value by using [/][/].
[1] {Pan} [/][/] [2][5] [Enter]
•
You can add or subtract from the DMX value by using [+] or [-].
[1] {Pan} [/][/] [+] [5] [Enter]
•
[1] {Pan} [/][/] [-] [7][5] [Enter]
•
Adjusting Parameters Using + and -
[+] and [-] can be used to adjust parameters from the command line. When using [-], you will
need to preface the command with [+] if you want to remove from the current value.
Example:
[Channel List] {Pan} [1][0] - sets to 10 degrees.
•
[Channel List] {Pan} [+] [1][0] - adds 10 degrees.
•
[Channel List] {Pan} [-] [1][0] - sets to -10 degrees.
•
[Channel List] {Pan} [+] [-] [1][0] - removes 10 degrees.
•
Using the Color Picker
The color picker can be opened from the
[Tab] [2][7].
With the color picker open, you have the choice between six different
Picker , Color Path
These options are found by right clicking on Color Picker Tab.
156
, Tinting Tools , and Spectrum Tools
Workspace Layout Menu (on page 31)
.
or by using
Color Spaces , a Gel
