Table of Contents

Advertisement

Quick Links

Ion Classic
User Manual
Version 3.1.1
4310M1210-3.1.1 RevA
2022-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ion Classic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ETC Ion Classic

Summary of Contents for ETC Ion Classic

  • Page 1 Ion Classic User Manual Version 3.1.1 4310M1210-3.1.1 RevA 2022-03...
  • Page 2 To view a list of ETC trademarks and patents, go to etcconnect.com/ip. All other trademarks, both marked and not marked, are the property of their respective owners. ETC intends this document, whether printed or electronic, to be provided in its entirety.

  • Page 3: Table Of Contents

    Table of Contents Introduction Using this Manual Register Your Console Online Eos Family User Forums Help from ETC Technical Services Other Reference Materials Important Concepts Console Overview Eos Apex 5 Overview Eos Apex 10 Overview Eos Apex 20 Overview Eos Ti Overview...
  • Page 4 Exporting a Show File Exporting Logs Deleting Show Files File Manager Patch About Patch Patch Main Display Patching Conventional Fixtures Patching Automated Fixtures, LEDs, and Accessories Patching Multicell Fixtures Labeling Using the Scroller/Wheel Picker and Editor Patch Section Ion Classic User Manual...
  • Page 5 Attribute Section Database Section Augment3d Section Using Device List Clearing the Patch Update Profile Fixture Editor Setup About Setup System Settings User Settings Device Settings Console Status Display Manual Control About Manual Control Selecting Channels Setting Intensity Manual Control of Non-intensity Parameters (NPs) Home Multiple Intensity Channels Multicell Fixtures...
  • Page 6 Mark About Mark AutoMark Referenced Marks Palettes About Palettes Palette Types Palette Options Storing Palettes Live Recalling Palettes Editing Palettes Live Editing Palettes in Blind Using By Type Palettes Removing Channels from a Palette Deleting Palettes Ion Classic User Manual...
  • Page 7 Presets About Presets Preset Options Storing Presets Live Recalling Presets Effects in Presets Editing Presets Live Using the Preset List Editing Presets in Blind Using By Type Presets Removing Channels from a Preset Deleting Presets Presets and Palettes Fader Properties Single Cue Lists About Single Cue List Basic Cueing...
  • Page 8 About Cue Playback Playback Controls Selected Cue Out-of-Sequence Cues Virtual Faders Assigning Faders Changing Fader Pages Playback Fader Controls Multipart Cues About Multipart Cues Record a Multipart Cue in Live Storing a Multipart Cue in Blind Ion Classic User Manual...
  • Page 9 Deleting Parts from Multipart Cues Effects About Effects The Effect List Effects Editor Effect Status Display Effect Channel Display Step Effects Absolute Effects Effect Background Value Modification Beats Per Minute Multiple Intensity HTP Effects Relative Effects Preprogrammed Rainbow Effects Apply an Existing Effect Editing Effects Live Stopping Effects Query and Group Effect...
  • Page 10 Releasing Content From a Submaster Updating a Submaster Deleting a Submaster Using About About [About] [About] {What's New} [About] System [About] Channel [About] Address [About] Cuelist [About] Cue [About] Curves [About] Effects [About] Groups [About] Submaster [About] Macro viii Ion Classic User Manual...
  • Page 11 [About] IFCB Palettes [About] Presets [About] Color Path [About] Live Curves About Curves Creating a Curve Editing Curves Applying a Curve To Channels In Patch Curves Applied to Cues Applying a Curve To Scroller Fans Deleting Curves Snapshots About Snapshots Recording Snapshots Recalling Snapshots Editing Snapshots...
  • Page 12 About Virtual Media Server Media Content Exporting Media Content Setting Up Pixel Maps Setting Pixel Map Features Working with the Virtual Media Server Effect Layers Pixel Mapping in a Multi-Console System Partitioned Control About Partitioned Control Ion Classic User Manual...
  • Page 13 How to Use Partitions Setting Up Partitioned Control Partition List Creating New Partitions Deleting Partitions Using Partitions Partitions in Playback Partitions on Cue Lists Flexichannel in Partitioned Control Multi-Console About Multi-Console Multi-Console Terms Multi-console Setup Synchronized Backup Mirror Mode Eos Configuration Utility About the Eos Configuration Utility ECU Welcome Screen Settings > General...
  • Page 14 Eos Family Show Control Capabilities Advanced OSC Eos OSC Keys Regulatory Apex 5, 10, and 20, Apex Remote Processor, Eos Remote Interface, and Windows 10- based Ion Xe, Ion Xe20, Ion Xe RPU, Gio@5, and Element 2 ETCnomad Puck Ion Classic User Manual...

  • Page 15: Introduction

    Introduction Using this Manual Register Your Console Online Eos Family User Forums Help from ETC Technical Services Other Reference Materials Important Concepts Introduction...

  • Page 16: Using This Manual

    Online Eos Family User Forums You are encouraged to visit and participate in the ETC Eos Family User Forum, accessible from the ETC website, etcconnect.com. This gives you access to an online community of Eos Family users where you can read about other users’ experiences, suggestions, and questions regarding the product as well as submit your own.

  • Page 17: Help From Etc Technical Services

    3. Follow the registration instructions provided by the community page. Help from ETC Technical Services If you are having difficulties and your problem is not addressed by this document, try the ETC support website at support.etcconnect.com or the main ETC website at etcconnect.com. If none of these resources are sufficient, contact ETC Technical Services directly at one of the offices identified below.

  • Page 18: Other Reference Materials

    The following resources are recommended: John Huntington, Show Networks and Control Systems, (Brooklyn, NY:Zircon Designs • Press, 2012) ETC Support Articles, available at support.etcconnect.com/ETC. • Important Concepts Before using your console, you should read and familiarize yourself with the concepts defined below.
  • Page 19 A fixture is defined as a group of related addresses that together control a device. An example of a fixture would be an ETC Revolution. This automated fixture contains 31 parameters that together allow you to perform various functions such as pan and tilt. Each of these attributes is addressed by a different output.
  • Page 20 Eos family consoles also have a [Q Only / Track] button that allows you to record or update a cue as an exception to the default setting. Therefore, if the console is set to Tracking, the button acts as Cue Only. If console is set to Cue Only, it behaves as a Track button. Ion Classic User Manual...
  • Page 21 Tracking Mode When you create a new cue, any unchanged channel parameter data from the previous cue is tracked into the new specified cue. Any changes in this new cue will also track forward into subsequent cues until a move instruction or a block flag is encountered. In the example below, the gray boxes indicate tracked values and the white boxes indicate move instructions.
  • Page 22 Move Instruction A move instruction is any change to a parameter from its previous stored value, such as changes to a channel’s intensity, pan or tilt, color mixing, etc. Manual Data Manual data is any value set for a channel via the command line. Manual data will remain at its value until a move instruction is provided for it.
  • Page 23 This rule is not followed when executing an out-of-sequence cue. An out-of-sequence cue is any cue that is recalled via [Go To Cue], a Link instruction, or manually changing the pending cue. In general applications, the entire contents of the cue (both moves and tracks) will be asserted on an out-of-sequence cue.
  • Page 24 Eos family consoles determine the LTP value for a channel, which is overridden by any HTP input values that are higher than the LTP instruction. This is then finally modified by manual control. Ion Classic User Manual...

  • Page 25: Console Overview

    Gio @5 Overview Ion Xe Overview Ion Xe 20 Overview Element 2 Overview Ion Classic Overview Element Classic Overview Cleaning Your Console Eos Apex 5 Overview This page provides an overview of the physical layout, components, and capacities of the Eos Apex 5 console.
  • Page 26 Displays > Power Off Device before disconnecting power from the console. CAUTION: Power cord must be connected using an earth ground connection. WARNING: Before servicing your console, you must switch off the power on the rear panel and disconnect the power cord completely. Ion Classic User Manual...
  • Page 27 Brightness Settings (on page 215) External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 28 Apex 20 - 50 target keys (5 banks of 10) • All Apex consoles also offer two target keys over the main playback faders for dedicated load functionality, as well as local status of playback content. For more information, see Target Keys (on page 119) Ion Classic User Manual...
  • Page 29 Main Playbacks The main playback fader pair, located to the left of the control keypad, is a split cross-fader pair. The button or buttons located directly above the playbacks load content to the playbacks. The two buttons below control the [Go] and [Stop/Back] functions. Motorized Faders In addition to the main playbacks, five, ten, or twenty slots of configurable motorized faders are provided.
  • Page 30 IO garage. Any ETC Gadget II or Response Show Control Gateway can be added to the garage and connected internally via USB for local input / output of DMX, MIDI, SMPTE, and other protocols.
  • Page 31 Book Lights Two independently-controlled, warm-white work lights are available on the left and right sides of Apex consoles for illumination of nearby work surfaces. Dimming Task Lights Task lights can be dimmed from within Eos, under Setup > Device > Brightness Settings. The {Desk Lamp} slider has a range of 0% (dimmest) to 100% (brightest).

  • Page 32: Eos Apex 10 Overview

    CAUTION: It is recommended that you safely power down the console via Displays > Power Off Device before disconnecting power from the console. CAUTION: Power cord must be connected using an earth ground connection. Ion Classic User Manual...
  • Page 33 Brightness Settings (on page 215) External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 34 Apex 20 - 50 target keys (5 banks of 10) • All Apex consoles also offer two target keys over the main playback faders for dedicated load functionality, as well as local status of playback content. For more information, see Target Keys (on page 119) Ion Classic User Manual...
  • Page 35 Main Playbacks The main playback fader pair, located to the left of the control keypad, is a split cross-fader pair. The button or buttons located directly above the playbacks load content to the playbacks. The two buttons below control the [Go] and [Stop/Back] functions. Motorized Faders In addition to the main playbacks, five, ten, or twenty slots of configurable motorized faders are provided.
  • Page 36 IO garage. Any ETC Gadget II or Response Show Control Gateway can be added to the garage and connected internally via USB for local input / output of DMX, MIDI, SMPTE, and other protocols.
  • Page 37 Book Lights Two independently-controlled, warm-white work lights are available on the left and right sides of Apex consoles for illumination of nearby work surfaces. Dimming Task Lights Task lights can be dimmed from within Eos, under Setup > Device > Brightness Settings. The {Desk Lamp} slider has a range of 0% (dimmest) to 100% (brightest).

  • Page 38: Eos Apex 20 Overview

    CAUTION: It is recommended that you safely power down the console via Displays > Power Off Device before disconnecting power from the console. CAUTION: Power cord must be connected using an earth ground connection. Ion Classic User Manual...
  • Page 39 Brightness Settings (on page 215) External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 40 Apex 20 - 50 target keys (5 banks of 10) • All Apex consoles also offer two target keys over the main playback faders for dedicated load functionality, as well as local status of playback content. For more information, see Target Keys (on page 119) Ion Classic User Manual...
  • Page 41 Main Playbacks The main playback fader pair, located to the left of the control keypad, is a split cross-fader pair. The button or buttons located directly above the playbacks load content to the playbacks. The two buttons below control the [Go] and [Stop/Back] functions. Motorized Faders In addition to the main playbacks, five, ten, or twenty slots of configurable motorized faders are provided.
  • Page 42 IO garage. Any ETC Gadget II or Response Show Control Gateway can be added to the garage and connected internally via USB for local input / output of DMX, MIDI, SMPTE, and other protocols.
  • Page 43 Book Lights Two independently-controlled, warm-white work lights are available on the left and right sides of Apex consoles for illumination of nearby work surfaces. Dimming Task Lights Task lights can be dimmed from within Eos, under Setup > Device > Brightness Settings. The {Desk Lamp} slider has a range of 0% (dimmest) to 100% (brightest).
  • Page 44 200 configurable cue playbacks, with Go and Stop /Back • 999 configurable submasters, with Bump and Assert/ channel select • Ion Classic User Manual...

  • Page 45: Eos Ti Overview

    Eos Ti Overview This page provides an overview of the physical layout, components, and capacities of the Eos Ti console. Eos Ti Layout Console Overview...
  • Page 46 Touchscreen brightness can be controlled via the External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 47 Display resolutions of 1920x1080 (minimum) to 3480x2160 (maximum) are supported • Each display may be utilized in landscape or portrait mode • Multi-touch display support requires the following: • Data connection via USB-A or USB-C cable per multi-touch monitor • Windows Human Interface Device (HID) compliant touch displays, utilizing Windows •...
  • Page 48 Six hardkeys are also available for encoder control. These encoder paging keys control intensity, focus, color, shutter, image, and form. Pressing any of these will change the parameters controlled by the encoders. To view other available encoder pages, simply press the encoder paging keys to advance the pages. Ion Classic User Manual...
  • Page 49 Level Wheel The level wheel adjusts intensity up or down for any selected channels. With channels selected, roll the wheel up to increase intensity, or down to decrease it. The level wheel can also provide additional functions when combined with various other console keys.
  • Page 50 10 motorized fader slots configurable as playbacks, submasters, grandmasters, timing • masters, effects masters, targets, or target lists 100 virtual pages of 10 faders each • 200 configurable cue playbacks, with Go and Stop/Back • 999 configurable submasters, with Bump and Assert/ channel select • Ion Classic User Manual...

  • Page 51: Gio Overview

    Gio Overview This page provides an overview of the physical layout, components, and capacities of the Gio console. Gio Layout Console Overview...
  • Page 52 Brightness Settings (on page 215) External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 53 Multi-touch display support requires the following: • Data connection via USB-A or USB-C cable per multi-touch monitor • Windows Human Interface Device (HID) compliant touch displays, utilizing Windows • standard driver Displays must process five or more points of simultaneous touch •...
  • Page 54 The level wheel can also provide additional functions when combined with various other console keys. See Face Panel Shortcuts (on page 132) for more information. Ion Classic User Manual...
  • Page 55 Rate Wheel The rate wheel can be used to provide dynamic rate adjustments for multiple playbacks. DMX Ports In order to output control levels from your console, you can use the DMX ports on the back of the console and/or you may connect a gateway or node. If your device receives sACN or Art- Net directly, no gateway or node is required.
  • Page 56 • masters, effects masters, targets, or target lists 100 virtual pages of 10 faders each • 200 configurable cue playbacks, with Go and Stop /Back • 999 configurable submasters, with Bump and Assert/ channel select • Ion Classic User Manual...

  • Page 57: Gio @5 Overview

    Gio @5 Overview This page provides an overview of the physical layout, components, and capacities of the Gio @5 console. Gio @5 Layout Console Overview...
  • Page 58 Brightness Settings (on page 215) External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 59 Multi-touch display support requires the following: • Data connection via USB-A or USB-C cable per multi-touch monitor • Windows Human Interface Device (HID) compliant touch displays, utilizing Windows • standard driver Displays must process five or more points of simultaneous touch •...
  • Page 60 The level wheel can also provide additional functions when combined with various other console keys. See Face Panel Shortcuts (on page 132) for more information. Rate Wheel The rate wheel can be used to provide dynamic rate adjustments for multiple playbacks. Ion Classic User Manual...
  • Page 61 DMX Ports In order to output control levels from your console, you can use the DMX ports on the back of the console and/or you may connect a gateway or node. If your device receives sACN or Art- Net directly, no gateway or node is required. To output, connect one 5 pin XLR cable per port.
  • Page 62 • masters, effects masters, targets, or target lists 100 virtual pages of 10 faders each • 200 configurable cue playbacks, with Go and Stop /Back • 999 configurable submasters, with Bump and Assert/ channel select • Ion Classic User Manual...

  • Page 63: Ion Xe Overview

    Ion Xe Overview This page provides an overview of the physical layout, components, and capacities of the Ion Xe console. Ion Xe Layout Ion Xe Components Power Button The power button on the front of the console is used to power up or power down. A separate hard power switch, located on the rear panel, can be used to disconnect power from the console’s internal components.
  • Page 64 External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 65 Hardkeys Backlit hardkeys are provided on the face panel. The brightness level for those keys can be Brightness Settings (on page 215) adjusted in the When your console has been idle for 10 minutes, the backlights will fade down by 10%. Any key press on the face panel keypad or an external keyboard, a move of the mouse, or an interaction with a touchscreen will return the keys to their set brightness level.
  • Page 66 Each port is on a separate NIC, and can be configured to directly output network- based lighting control protocols such as sACN or Art-Net. Output Protocols (on page 555) for more information. Note: Apex consoles, Windows 10 consoles, and ETCnomad software do not support draft sACN, Net2, or AVAB UDP output protocols. Ion Classic User Manual...
  • Page 67 USB Ports One USB port is provided on the front of the console to connect any USB storage device. Additional USB ports on the rear panel (and in the keyboard tray, when present) of the console connect peripherals such as an alphanumeric keyboard, pointing device, or touchscreen control for external monitors.

  • Page 68: Ion Xe 20 Overview

    999 configurable submasters, with Bump and Assert channel select • Ion Xe 20 Overview This page provides an overview of the physical layout, components, and capacities of the Ion Xe 20 console. Ion Xe 20 Layout Ion Classic User Manual...
  • Page 69 External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 70 The display and navigation keys provide quick access to common displays, formatting, paging, and navigation within displays. Encoder Categories (5) The encoder category buttons allow expanded control of a variety of fixture parameters, along with additional softkey options where applicable. Ion Classic User Manual...
  • Page 71 Additional Targets & Functions The remaining hardkeys provide options for a variety of common console functions and shortcuts to various Blind displays. Main Playbacks The main playback fader pair, located to the left of the control keypad, is a split cross-fader pair.
  • Page 72 Task lights can also be controlled by holding down [Displays] and rolling the level wheel. WARNING: This device contains a lithium battery. Battery may explode if mistreated. Do not recharge, disassemble or dispose of in fire. Ion Xe 20 Capacities Output Parameters 2,048 (Min) • 12,288 (Max) • Ion Classic User Manual...
  • Page 73 Channel Counts 32,768 channels (can be any number from 1 to 99,999) • Cues and Cue List 999 cue lists • 10,000 cues • Record Targets 10,000 Groups • 10,000 x 4 Palettes (Intensity, Focus, Color and Beam) • 10,000 Presets •...

  • Page 74: Element 2 Overview

    The power button on the front of the console is used to power up or power down. A separate hard power switch, located on the rear panel, can be used to disconnect power from the console’s internal components. Ion Classic User Manual...
  • Page 75 External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 76 The remaining hardkeys provide options for a variety of common console functions and shortcuts to various Blind displays. Main Playbacks The main playback fader pair, located to the left of the control keypad, is a split cross-fader pair. Ion Classic User Manual...
  • Page 77 The button or buttons located directly above the playbacks load content to the playbacks. The two buttons below control the [Go] and [Stop/Back] functions. Faders In addition to the master playbacks, banks of configurable faders are provided. The faders may be configured as playbacks, submasters, grandmasters, timing masters, effects masters, targets, or target lists.
  • Page 78 10,000 cues • Record Targets 1,000 Groups • 1,000 x 4 Palettes (Intensity, Focus, Color and Beam) • 1,000 Presets • 1,000 Effects • 99,999 Macros • 1,000 Snapshots • 1,000 Curves • 1,000 Color Paths • Ion Classic User Manual...
  • Page 79 Faders 1 dedicated main playback pair, with Go and Stop/Back • 40 faders with 80 configurable buttons • 999 configurable submasters, with Bump and Assert channel select • Console Overview...

  • Page 80: Ion Classic Overview

    Ion Classic Overview This page provides an overview of the physical layout, components, and capacities of the Ion Classic console. Ion Classic Layout Ion Classic User Manual...
  • Page 81 External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 82 The display and navigation keys provide quick access to common displays, formatting, paging, and navigation within displays. Encoder Categories (5) The encoder category buttons allow expanded control of a variety of fixture parameters, along with additional softkey options where applicable. Ion Classic User Manual...
  • Page 83 Softkeys (6) The softkey buttons allow physical control of the onscreen softkey options, which change dynamically based on the command line and active tab to offer additional commands not available on hardkeys. Additional Targets & Functions The remaining hardkeys provide options for a variety of common console functions and shortcuts to various Blind displays.
  • Page 84 This device contains a lithium battery. Battery may explode if mistreated. Do not recharge, disassemble or dispose of in fire. Ion Classic Capacities Output Parameters 1,024 (Min) • 6,144 (Max) • Channel Counts 16,000 channels (can be any number from 1 to 99,999) • Ion Classic User Manual...
  • Page 85 Cues and Cue List 999 cue lists • 10,000 cues • Record Targets 10,000 Groups • 10,000 x 4 Palettes (Intensity, Focus, Color and Beam) • 10,000 Presets • 10,000 Effects • 99,999 Macros • 10,000 Snapshots • 10,000 Curves •...

  • Page 86: Element Classic Overview

    CAUTION: It is recommended that you safely power down the console via Displays > Power Off Device, before disconnecting power from the console. CAUTION: Power cord must be connected using an earth ground connection. Ion Classic User Manual...
  • Page 87 External Monitors Windows 7 Ion Classic can support up to 2 monitors, either 2 DVI monitors or 1 Display Port and 1 DVI. Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
  • Page 88 The level wheel can also provide additional functions when combined with various other console keys. See Face Panel Shortcuts (on page 132) for more information. Ion Classic User Manual...
  • Page 89 DMX Ports In order to output control levels from your console, you can use the DMX ports on the back of the console and/or you may connect a gateway or node. If your device receives sACN or Art- Net directly, no gateway or node is required. To output, connect one 5 pin XLR cable per port.
  • Page 90 1,000 Effects • 99,999 Macros • Faders 1 Grandmaster with Blackout • 1 Master Playback, with Go and Stop/Back • 40 or 60 faders with bump buttons • 999 configurable submasters • 120 channel faders • Ion Classic User Manual...

  • Page 91: Cleaning Your Console

    If this does not clean the console sufficiently, you may apply some window cleaner (containing ammonia is fine) to the cloth and repeat the process until clean. More information about cleaning your console is available at the ETC Support Site, support.etcconnect.com.
  • Page 92 Ion Classic User Manual...

  • Page 93: System Basics

    Chapter 2 System Basics About System Basics Power Up the Console Power Down the Console The Central Information Area (CIA) Browser Softkeys Displays Display Control and Navigation Live and Blind Displays Playback Status Display Direct Selects Encoders Moving Light Controls Fader Configuration Virtual Keyboard Face Panel Shortcuts...

  • Page 94: Power Down The Console

    It is possible to collapse the CIA from view. To do this, you can click the arrow icon above the CIA. The CIA will collapse from view, exposing a larger viewing area of whatever display is visible above the CIA. The arrow will move to the bottom of the screen. Ion Classic User Manual...
  • Page 95 To expand the CIA into view again, click the arrow at the bottom of the screen. The CIA will reopen. Lock the CIA You can lock the CIA in place to prevent it from being collapsed or viewed. To lock the CIA, click on the lock above the browser. The lock will “lock”. To unlock the CIA, click the sunken lock again.

  • Page 96: Browser

    Use the page arrow keys to move the selection bar up and down the list. You may also • use the level wheel to scroll through the list. When the bar highlights the desired menu, press [Page Right] to open the menu. • Ion Classic User Manual...
  • Page 97 Continue pressing [Page Right] to open submenus. • Scroll to the item you wish to open using [Page Up] or [Page Down], or select the item • by clicking or tapping. Press [Enter], [Select] , or double-click to open. If you wish to close a submenu scroll to that item and press [Page Left]. •...

  • Page 98: Softkeys

    The gray labels in the top row indicate the second page of available softkeys, available by pressing the [More SK] button. Those softkeys correspond to buttons [S1] - [S6] and [More SK] on the face panel. Ion Classic User Manual...

  • Page 99: Displays

    Example: With a channel on the command line, pressing [More SK] & [Intensity] will post Make Manual on the command line. Changing Softkey Pages When there are more relative softkeys than the six available buttons, both gray and white softkey labels will be visible. The white labels on the bottom row of the label window indicate the active softkeys.
  • Page 100 Controls Tab will bring it to the front and grab focus. Single clicking on a Display Tab will bring it to the front and grab focus. Tab Numbers 1. Live / Blind 2. Playback Status Display 3. Magic Sheet Ion Classic User Manual...
  • Page 101 4. Direct Selects 5. ML Controls 6. Effect Status 7. Virtual Keyboard 8. Effect Channels 9. Pixel Maps 10. Pixel Preview 11. Show Control 12. Patch 13. Effects 14. Magic Sheet List 15. Submaster List 16. Cue List 17. Groups 18. Macros 19.
  • Page 102 Close Tab - closes the selected tab. • Replace Tab - allows you to close the current tab and choose from the Home Screen • which display to replace it with. Pressing escape will return you to the previously selected tab. Ion Classic User Manual...

  • Page 103: Display Control And Navigation

    Close All Tabs But This - closes all of the tabs except the selected one. • Close All Tabs - closes all of the tabs including the selected one. • Reset Columns - resets all of the column widths in the selected tab to Eos defaults. This •...
  • Page 104 Menu. This screen will also display when a new tab is opened. This screen consists of four general areas, each offering different display-related options. Display and Control Icons Clicking on an icon will open the appropriate display or control in a new tab. Display Tabs Control Tabs Ion Classic User Manual...
  • Page 105 Layout Options These tools offer you greater flexibility in the number of tabs you can view in any given workspace. A workspace can have up to 16 frames. Selecting a layout icon will assign the frame layout identified in the icon. Once a layout is assigned, you can select which displays and controls will be in which frames.
  • Page 106 [Delete] [Snapshot] [n] [Enter] [Enter] will delete a monitor-only snapshot. All snapshots can be viewed on the snapshot list display, which can be opened by pressing [Snapshot] [Snapshot] or from the Workspace Layout Menu. Ion Classic User Manual...
  • Page 107 Updating a Single Monitor Snapshot A single monitor snapshot can be updated or deleted by right-clicking on its icon in the Snapshot area of the Workspace Layout Menu. Using Expand With Displays [Expand] allows you to quickly create additional frames on a monitor. To add frames, press [Expand] &...
  • Page 108 This option allows you to view a favorite magic sheet in a small pop-up window over your current display. The pop-up magic sheet functions just like a traditional magic sheet and is interactive. . Press the wand icon to close the display when opened. Ion Classic User Manual...

  • Page 109: Live And Blind Displays

    A pop-up magic sheet can be assigned in Setup>User>Displays>Popup Magic Sheet. If a magic sheet has not been assigned in Setup, when you first click the pop-up magic sheet icon, you will be able to select a default magic sheet from a list of the available ones. In Setup>User>Displays>Popup Nav Lock, you can enable or disable the zoom and scroll navigation for pop-up magic sheets.
  • Page 110 See Indicators in the Live / Blind Display (on page 100) for more information. To collapse the summary view, hold down [Data] and any of the encoder paging keys (Focus, Color, Image, Shutter, or Form). Ion Classic User Manual...
  • Page 111 When the summary view has been collapsed to show only intensity data, you may include focus, color, or beam data in the summary view by holding down [Data] and any of the encoder paging keys (Focus, Color, Image, Shutter, or Form) This displays all categories again. Table View Table view is available in Live or Blind.
  • Page 112 [Last] will behave the same as {Previous}. {Preview}<Cue>[5] will preview cue 5. • Channels in Use To open the Channels in Use display, click on the {CIU} icon in the home screen or press [Tab] &[3][2]. Ion Classic User Manual...
  • Page 113 A Channels in Use display shows the following information for each channel: Number of cue lists the channel appears in. • Number of cues the channel appears in. • Number of cue moves from zero. • Number of submasters that channel appears in. •...
  • Page 114 Most of the channels in the above image are conventional channels (intensity is the only available parameter). Several channels in the image are automated fixtures (possessing more parameters than just intensity). Conventionals Conventions display the channel number, intensity, and any additional data below. Automated Fixtures or Multi-parameter Devices Ion Classic User Manual...
  • Page 115 This view also has additional data fields beneath intensity (F, C, B). This information can be suppressed by pressing and holding [Data] and any of the encoder paging keys (Focus, Color, Image, Shutter, or Form). Doing so will leave only the intensity field and FCB indicators at the bottom of the channel.
  • Page 116 MK Indicates the channel is marked for a later cue. The cue number is indicated in the • other categories (see “Q” below). ND Indicates that a channel has been patched as a non-dim fixture type. • Ion Classic User Manual...
  • Page 117 N Indicates the value is null (from either {Make Null} or a filter). • P Indicates the channel is parked. • Ph Indicates the channel is at a preheat level. • Pr Indicates that the value is referenced to a preset. This text is followed by a number, •...
  • Page 118 "." after the channel number to indicate that they have cells hidden.) Masters Off (displays only the cells for multicell fixtures) • Partitioned (displays only those channels defined in the current partition) • Ion Classic User Manual...
  • Page 119 Note: The multicell fixture views can be used in combination with other flexichannel states. Note: You can use [Flexi] & [.] to quickly toggle cells on and off. In flexi, selected channels (including the last channel selection) are always included in the view.

  • Page 120: Playback Status Display

    Pressing [Format] with the playback status display active will access this format. In expanded cue list, the view of the active cue list increases to the full size of the display. The current fader page is visible at the bottom of the screen. Ion Classic User Manual...
  • Page 121 Fader Display Format Pressing [Format] with the playback status display active will access this format, which shows a view of the fader configurations for 10 pages of 10 faders each (for a total of 100 visible faders. Each fader is color coded based on its assigned target type. Grandmasters and inhibitive submasters are in red, additive submasters are yellow ,playback faders display in green ,and presets and palettes are orange.
  • Page 122 Gold - Any item (cue, list, page) highlighted in gold indicates “current”.Outlined in gold • indicates “selected”. Red - Cue fade is in progress • Fader Ribbon / Display Red - Grandmasters and inhibitive submasters • Yellow - Additive submasters • Ion Classic User Manual...
  • Page 123 Green - Playback faders • Orange - Presets and palettes • Text Indicators + (see cue 6) - Indicates that there is discrete timing within the associated cue. Found in • the cue display “Timing” area. * (see cue 4) - Indicates the cue has an allfade command. Found in the cue display •...
  • Page 124 Display Fader Ribbon - displays the fader ribbon, which shows the current fader page • under the Master Playback Status. Display Notes - displays the Cue Notes in a horizontal bar at the bottom of the PSD. • Ion Classic User Manual...

  • Page 125: Direct Selects

    Cue Notes Display Pending Cue Notes - displays the for the pending cue in a horizontal • bar at the bottom of the PSD. Break Link to Live/ Blind - When selecting the Live/ Blind display, the PSD will also come •...
  • Page 126 This allows multiple commands to be selected and executed at once, and an optional sneak time to be entered. Channels and groups selected via direct selects will post an unterminated command by default. Ion Classic User Manual...
  • Page 127 Recording to Targets Using Direct Selects You may store a command line selection directly to a target's direct selects by pressing [Record] and the desired direct select key. You can record decimal inserts to a direct select, which will add additional buttons to your direct select grid.
  • Page 128 Asterisks next to any of the additional configuration options indicate functions that are only enabled for specific banks. Layout This section allows you to configure the layout of the direct selects grid. Ion Classic User Manual...
  • Page 129 Note: If the frame or window is resized, the direct selects grid layout will responsively change size to fit onscreen. {25} / {50} / {100} / {200} - quick-select options to easily set the grid size. • Rows - allows you to select the number of rows in the banks. •...
  • Page 130 Target Selection Menu (2) This section allows you to configure which direct select targets are assigned to your custom direct select buttons. All buttons default to empty. Ion Classic User Manual...
  • Page 131 Custom Direct Selects (3) This section displays an index of all the custom direct select lists in your show file. These lists can be assigned a label, as well as an icon. Note: Custom direct selects created in Eos software prior to v3.1.0 and stored in snapshots will be automatically converted to a custom direct select list, labeled with the relevant snapshot number.
  • Page 132 OK. SHIFT or CTRL can be held to select multiple consecutive or nonconsecutive images. Accepted image formats for import are .bmp, .gif, .ico, .jpg, .pbm, .pgm, .png, .ppm, .svg, .svgz, .tga, .tiff, .xbm, and .xpm. The maximum image size is 1920 x 1920. Ion Classic User Manual...
  • Page 133 Organizing Icons Select the Organize button to enable the following additional button options: Add Folder - adds a folder to the current icon library directory. • Delete Unused - deletes any unused icon images across all icon library folders. You can •...

  • Page 134: Encoders

    (if any) and also a {Home} button which allows you to set that parameter to its default position. The encoder controls display allows you to cycle through parameter steps (if available). You can also home any parameter. Some buttons that may be available are: • • Ion Classic User Manual...
  • Page 135 Next • Last • Mode • Expand • XYZ Format Enable / Disable • Buttons like {Next} and {Last} are used to step through ranges (such as colors in a color scroller) one step at a time. {Min} and {Max} allow you to send a parameter to its minimum or maximum limit with one press.
  • Page 136 Creating Custom Maps Create a map by entering the map number and pressing [Enter], and select a parameter category (Intensity, Focus, etc) to customize. Add parameters to the category by selecting an open encoder slot, and choosing a parameter from the list to assign to it. You can also search for specific parameters.
  • Page 137 Each parameter category can be given up to 25 pages of custom encoder layouts. If a parameter category is not assigned any custom encoder layouts, the default Eos parameter mapping for that category will be used instead. Defaults These parameter slots assign default parameters to each encoder in the specified parameter category.

  • Page 138: Moving Light Controls

    6. Collapses or expands categories. 7. Gives pan and tilt functionality to a mouse or trackball. 8. Virtual encoder (Click and hold close to the center line for slow movement, further away for faster movement.) 9. Opens the gel picker. Ion Classic User Manual...

  • Page 139: Fader Configuration

    Fader Configuration The fader configuration display is found on Tab 36 .The Fader List (on the next page) , which shows all of the faders and their assignments, can be found in Tab 35. At the top of the fader configuration display, you can select the fader page, which has 100 pages of 10 faders each page.
  • Page 140 Presets and Palettes Fader Properties (on page 289) • Global Effects Fader (on page 394) • Manual Time Master (on page 128) • Fader List The Fader List, which shows all of the faders and their assignments, can be found in Tab 35. Ion Classic User Manual...
  • Page 141 You can also make changes to a fader's configuration while in the fader list display by clicking on a column. A virtual fader will be displayed. Click on the appropriate area of the fader to access the configuration options. Selection can be done by clicking in the column or from the command line.
  • Page 142 The third button can be configured as a blackout button or disabled. When configured as a blackout, both buttons must be pressed to set the grandmaster to blackout. Manual Time Master A fader can be mapped as a manual time master. Ion Classic User Manual...
  • Page 143 Note: Manual Time Master applies to changes made manually, not to playback. A manual time master can be used to impact any manual control timing. For a manual time master, you need to assign a minimum and maximum time setting to the fader. By default, the minimum is set to 0 seconds when the fader is completely down, and maximum is 5 seconds when the fader is at full.
  • Page 144 Slider Format - choose between the following options: • Buttons - configurable buttons • Faders - sliders and configurable buttons • Apex Faders - Apex endless fader wheels, sliders, and configurable buttons • Ion Classic User Manual...

  • Page 145: Virtual Keyboard

    Display Master Fader Pair - check this box to display the virtual master fader pair. • Unchecked by default. For information about configuring your faders, see Fader Configuration (on page 125) Copying Faders Using Attributes Only When copying faders, you can use {Attrs Only} to copy over all of the fader properties except levels, effects, and labels.

  • Page 146: Face Panel Shortcuts

    [About] & [Mark] - displays the mark cue used by the channels. • [About] & [Next]/[Last] - displays the next cue that the channels move in or the last cue • that the channels moved in. [About] & [Park] - displays the parked levels. • Ion Classic User Manual...
  • Page 147 [About] & [Part] - displays the cue part number for each parameter. • [Expand] & [Effect] - opens the Effect Status Display (Tab 8). • Face Panel [Shift] & [Escape] - to lock and unlock face panel. • Encoder Paging Keys & [Number] - pages to the desired encoder control page. •...
  • Page 148 [.] - posts cells or cells only to the command line when used after channel number(s). • This is for use with multicell fixtures. [Shift] & [Int Palette] - posts preset on the command line (Element & Element 2). • [Displays] & [Record] - puts a marker in the log file. • Ion Classic User Manual...

  • Page 149: Hotkeys

    Hotkeys The following is a list of common Eos functions and their associated Windows keyboard shortcuts. Console Function Windows Keyboard Shortcut Shortcut List Alt / . (decimal) . (decimal) - (minus) - (minus) + (plus) Shift = Control Alt = Shift - Control Alt - A3D Camera Up Up Arrow...
  • Page 150 Encoder Page Image ^ Control Alt ] Encoder Page Intensity ^ Alt . Encoder Page Shutter ^ Alt , Enter Enter Escape Escape Expand Control 5 Fader Page FlexiChannel Control 3 Focus Filter Control F Focus Palette Alt F Ion Classic User Manual...
  • Page 151 Follow / Hang Shift D Control Alt D Format Control 4 (Scroller) Frame Control Alt C Freeze Control Alt F Full Spacebar Go To Cue Control G Go To Cue Zero Control Alt G Group Help Alt / Highlight Control Alt H Home Home Control H...
  • Page 152 Control Enter Select (ECU) Return Select Active Control A Select Last Control L Select Manual Control M Setup Alt S Shift Snapshot Control S Sneak Softkey 1 Alt 1 Softkey 2 Alt 2 Softkey 3 Alt 3 Ion Classic User Manual...

  • Page 153: Sacn Output Viewer

    To enable Eos functions on macOS Function keys: 1. Navigate to System Preferences > Keyboard 2. Enable the “Use all F1, F2,etc... keys as standard function keys” setting. Note: Some international keyboards require “Use Shift Key As Eos Shift” to be disabled in Setup > Device > Face Panel > Input Devices.
  • Page 154 This is enabled by default. Press {About} to open the About Address display in the CIA. Press the left and right arrows to scroll through the available universes, or enter a specific universe number in the box. Ion Classic User Manual...

  • Page 155: Managing Show Files

    Chapter 3 Managing Show Files About Managing Show Files Create a New Show File Open an Existing Show File Merging Show Files Printing a Show File Saving the Current Show File Importing Show Files Exporting a Show File Exporting Logs Deleting Show Files File Manager Managing Show Files...

  • Page 156: About Managing Show Files

    To open a show file from the network drive, navigate within the Browser to: File > • Open> Name of Network Drive> and press [Select]. To open a show file from a USB device, navigate within the Browser to: File> Open> • Name of Drive and press [Select]. Ion Classic User Manual...
  • Page 157 Select the specific show file Navigate within the specified storage location and select the show file you wish to open, • press [Select]. If the selected show has multiple time stamps and you wish to load an older version, • navigate to the desired revision and press [Select].
  • Page 158 Target - The desired location of the components in the new show file (for ranges, this • will be the location in the new show of the first component in the range, the others will follow in order). Ion Classic User Manual...

  • Page 159: Merging Show Files

    Show File Advisory If the loaded show file exceeds the console’s output capacity, an advisory will display in the CIA. You will need to dismiss the advisory by pressing {Ok} before continuing. To see the capacity of the console, press [About]. Park Buffer The contents of the Park buffer are saved with show files.
  • Page 160 Checking the "Only Merge Augment3d XYZ Location" box will merge only the Augment3d position information of the selected range without merging any additional patch data. Ion Classic User Manual...

  • Page 161: Printing A Show File

    Partial Show File Channel Merge When Merge Channels is selected, channels from cues, submasters, groups, and other channel targets will be added to any existing channel targets of that same type. With Merge Channels not selected, those channels will override any existing channels in the channel targets of the same type.
  • Page 162 It also gives the Eos Family software version information. If multiple aspects were selected to save to the file, there will be hyperlinks at the top of the PDF so you can quickly jump to a section. Ion Classic User Manual...

  • Page 163: Saving The Current Show File

    Note: If you have cues selected, cue notes and scenes will display along with additional cue information. Saving the Current Show File To save the current show data, navigate within the browser to: File>Save> and press [Select]. A green "Success" message should appear when the file has finished saving. If a red "Failed" error appears, attempt to save to a different location, or exit and / or restart Eos as soon as possible.
  • Page 164 Save into the Show File Archive to remove these indicators and update the file name displayed. Show File Formats The Save and Save As dialogs include a variety of options for saving show files. Ion Classic User Manual...

  • Page 165: Importing Show Files

    ESF3D This format includes your show data and your Augment3d model, and is only compatible with Eos versions 3.0.0 and higher. ESF2 This format excludes Augment3d model, and is only compatible with Eos versions 2.9.0 and higher. This is a legacy format for compatibility with Eos versions prior to 2.9.0. Importing Show Files Eos supports the import of a variety of files.
  • Page 166 Eos will accept mulitple address formats for importing. Examples of those formats are 2/3, 2.3, 2,3, 2-3. Eos will convert all formats to n/n. Device Mapping Devices can also be mapped. Click {Map Devices} to open the following display. Ion Classic User Manual...

  • Page 167: Exporting A Show File

    Select the Lightwright device and the match from the Eos column. Multiple Lightwright devices can be selected at a time. Then click {Link Devices}. The link will appear in the Mapping column. To unlink a device, select it from the Mapping column, and then press {Unlink Device}.

  • Page 168: Exporting Logs

    {Ok}. You will be prompted to name the file. A .csv file will be created. Exporting Logs Logs are useful tools for diagnosing issues. ETC Technical Services may request that you email Help from ETC Technical Services (on page 3) logs if they are assisting you with an issue.

  • Page 169: Patch

    Chapter 4 Patch About Patch Patch Main Display Patching Conventional Fixtures Patching Automated Fixtures, LEDs, and Accessories Patching Multicell Fixtures Labeling Using the Scroller/Wheel Picker and Editor Patch Section Attribute Section Database Section Augment3d Section Using Device List Clearing the Patch Update Profile Fixture Editor Patch...

  • Page 170: About Patch

    For patching fixtures, there are two different patch modes: patch by channel patch by address. Eos defaults to patch by channel mode. Pressing [Format] while in the Patch display will toggle the mode between patch by channel and patch by address. Ion Classic User Manual...
  • Page 171 The patch screen will display the following information if available: Channel - the patched channel number. In patch by address mode, channel will appear • blank if not currently patched. Address - the patched output address. In patch by channel mode, address will appear •...

  • Page 172: Patching Conventional Fixtures

    If you try to patch a channel or address that exceeds the console's output, an error message will display on the command line. Patching By Address Pressing [Format] while in the patch display will toggle the mode between patch by channel and patch by address. Ion Classic User Manual...
  • Page 173 [2] [0] [At] [1] [Enter] patches address 20 to channel 1. Pressing [At] will post channel to the command line while patching by address. Additional examples of patch by address: [5] [At] [1][0][0] [Enter] - patches address 5 to channel 100. •...
  • Page 174 System Settings > Output. See Output (on page 207). Note: There is also a Dimmer Doubling setting for Net3 Gateways with DMX outputs. This is used with Sensor racks that are connected via DMX. The Gateway must be properly configured. Ion Classic User Manual...
  • Page 175 Moving and Copying Channels Channels can be moved from one location to another within patch. [1] [Copy To] [Copy To] [2] - moves channel 1's data to channel 2. Channel 2's data is • replaced by channel 1's. Channel 1 is unpatched. [1][Copy To] [Copy To] [2][Part][2] - creates a part 2 for channel 2 and moves channel •...
  • Page 176 Note: On non-Apex Eos Family consoles, {Offset} is a softkey. Note: For multiple parameter devices, Eos will automatically offset the addresses based on the fixture type. For more information about using offset, see Offset (on page 221) Ion Classic User Manual...

  • Page 177: Patching Automated Fixtures, Leds, And Accessories

    Creating Multipart and Compound Channels A multipart channel is any channel that has more than one dimmer patched to it. A compound channel has multiple profiles patched to it that make up one channel, an example would be a dimmer with a scroller and auto-yoke. By default, Eos will add a part if you are trying to patch to a channel that has already been assigned an address.
  • Page 178 {Add Show} to add to your show list. If you want to delete a fixture or device from the show list, click {Edit} while in the show display. Select the device you wish to remove and click {Delete}. To select a device interface (optional), click {Interface}. See Output Protocols (on page 555) Ion Classic User Manual...

  • Page 179: Patching Multicell Fixtures

    Click the {Attributes} softkey to set detailed automated fixture attributes. The following buttons may be available on this page depending on the device selected: {Preheat}, {Proportion}, {Curve}, {Fan Curve}, {LD Flags}, {GM Exempt}, {Invert Pan}, {Invert Tilt}, {Swap P/T}, {Color Path}, {Scrollers}, {Gobo Wheels}, {Color Wheels}, and {Effect Wheels}. Additional buttons maybe available based off of your fixture type.
  • Page 180 You will need to select the master or cell profile to edit parameters. In this view, you'll be able Creating a New Fixture (on to edit parameters, DMX, Home, Snap, and ranges/modes. See page 184) Range Editing a Parameter (on page 186) for more information. Ion Classic User Manual...

  • Page 181: Labeling

    To change specific cell data such as DMX offset, you will need to use {Edit Multicell}. With a multicell fixture or a master cell selected in the fixture editor, press {Edit Multicell}. In the Edit Multicell window, you can edit cell numbers, DMX offset, and mastered cells for each cell. Once you are finished editing, press {Save Fixture} to save your changes or {Cancel Edit} to remove the changes and exit the edit mode.
  • Page 182 In the above image, {ETC Scroll} is the default scroll for the selected ETC Source Four Revolution. The list of gel colors as they are installed in the scroll are displayed to the left with a color chip for easy reference.
  • Page 183 The editor does not limit how many frames you can add to the scroll or wheel for the selected fixtures. Keep in mind that any fixture has its own limitations. For example, if you have created a custom color scroll with 30 frames, your selected fixture type may only provide you access to the first 24 frames that you created.
  • Page 184 When a specific catalog is selected, the selected media will display. When you make a media selection, the display returns to the new wheel frame list where additional frames can be edited in the scroll or wheel. Ion Classic User Manual...
  • Page 185 Scroller Fan Curves Curves can be applied to the scroller fan parameter allowing for the output of the fan to be controlled by the intensity of the channel. The curves available for this are the same used for intensity parameters and cues. See Applying a Curve To Scroller Fans (on page 429) To set a curve to a scroller fan, go to Displays>Patch>Attributes>Fan Curve for each scroller.
  • Page 186 [1] {Copy Scroller} [2] [Enter] - copies the scroller and calibration data from channel 1 to • channel 2. Scrollers that have calibrated data will display a “~” after their name. The {Calibrate} button will now only appear on scroller parameters that are currently not at the center of a frame. Ion Classic User Manual...

  • Page 187: Patch Section

    Reordering Shutters Shutters can be reordered in the Patch {Attributes} page. Press the {Shutter Order} button to open the shutter order display. The {Shutter Order} button will only display if a channel with shutters is currently selected. In this display, you can invert the {Shutter Order} or rotate the order using the arrow buttons. After you have created the order needed, press {Apply} for your changes to take effect.

  • Page 188: Attribute Section

    {Fan Curve}, {LD Flags}, {GM Exempt}, {Invert Pan}, {Invert Tilt}, {Swap P/T}, and {Color Path}. With one or more channels selected, Scrollers / Wheels will display only the parameters that apply to those fixtures will appear. Press the desired attribute button and use the keypad to set the attribute value. Ion Classic User Manual...
  • Page 189 {Preheat} - This field allows you to specify an intensity value to preheat incandescent • filaments. When a preheat flag is applied to a cue, any channels that are fading from zero to an active intensity and have been assigned a preheat value in patch will preheat in the immediately preceding cue.

  • Page 190: Database Section

    It will display keywords that were already created as well as showing an option for creating new keywords. Clicking on {New Keyword} will display an alphanumeric keyboard for entering in a new keyword. Ion Classic User Manual...
  • Page 191 {Text} - Text fields are used to provide up to ten keywords about any channel or group of • channels. These fields can be anything that you think is important about a channel, such as its location (FOH), an attribute of it (wash, spot) or other characteristics of the channel (such as gel R80).

  • Page 192: Augment3D Section

    CEM3 v1.3.1 and newer, and FDX v3.4.0 and newer. To use the Dimmer Feedback area of the Device List, you must first enable feedback. In the network tab of the ECU, when using CEM+ or CEM3, make sure {Sensor/ FDX3000 Feedback} Ion Classic User Manual...
  • Page 193 is enabled, or when using FDX 2000/ 3000, make sure that {Sensor/ FDX3000 Feedback} or {FDX2000 Feeback} is enabled. The default setting is disabled for both. See Interface Protocols (on page 557) Open the Dimmer Feedback display while in the Patch display by pressing {Device List}> {Dimmers}.
  • Page 194 Interface Protocols (on page 557) If using Network RDM, this must be done via an ETC Net3 Gateway and RDM must also be enabled on the DMX ports of the Gateway. The Gateway needs to be running version 5.1 or newer.
  • Page 195 Manufacturer • Model • Footprint • Eos will also display what personality from the library the device matches in the Eos Type column. This information will not display until you first select the device. Once the device has been selected for the first time, Eos will extract the type information from the device and display it.
  • Page 196 Patched fixture address mismatch • Offline • Detaching Devices Pressing {Attach} twice will post the {Detach} command. <Chan> [X] {Attach} {Attach} or <Address> [X] {Attach} {Attach} will remove the link between that channel/address and the device at that address. Ion Classic User Manual...

  • Page 197: Clearing The Patch

    When a new library is installed on Eos either from a software update or a separate fixture library file from the ETC website, changes in library data will not automatically update your show files. This is to prevent library changes from affecting a functional show file.
  • Page 198 16-bit channel. If used in Coarse/ Fine determination, the DMX channel defines the “Coarse” adjustment and the LDMX defines the “Fine” adjustment. Do not count 16-bit parameters as two parameters, this will be done in a later step. To add parameters to a new fixture: Ion Classic User Manual...
  • Page 199 1. Use the [Page] keys, mouse, or touchscreen to select the new fixture. 2. Select the parameter list by clicking on it or touching it. 3. Determine the total number of parameters that your fixture has. Do not count 16-bit parameters as two parameters, this will be done in a later step.
  • Page 200 You can enter the operational ranges for specific slots within any specific parameter (such as color scroller, color wheel, gobo wheel, and so on). You can do this by either defining each range individually or you can use the quick action tools to define multiple ranges at once. Ion Classic User Manual...
  • Page 201 If a parameter has only one range, the values for that range will display in the range column. If that parameter has multiple ranges, the number of ranges will be displayed. If a range is used in a mode, the range will not be in bold. For example, if the parameter were “Gobo Wheel”, and the fixture included a four-slot gobo wheel, you can use ranges to determine the minimum/ maximum values for each of those slots.
  • Page 202 • ranges. The console then distributes the DMX values and assigns a user range exactly as any of the wheel or frame parameters are automatically created. (Frames 1, 2, 3, etc would be represented as 0.5-1.4, 1.5-2.4, 2.5-3.4, etc) Matched - The user values are set to match the DMX values. This is required for a •...
  • Page 203 Labels • Open • Open/Color N • Blackout • Animation • Animation N • Color • Color N • Color M/N • Color N/Open • Effect • Effect N • Gobo • Gobo N • (clear) • Units are used to add a degree or percentage symbol to the end of a label when it displays in the encoder display or ML controls.
  • Page 204 Once a parameter is used as a condition, it becomes read only. Only the labels for the ranges can be added/ edited. Ion Classic User Manual...
  • Page 205 Note: A single range parameter is not useful as a condition so those will not be available for selection. Note: Some fixtures use virtual modes. Those are modes without a DMX address assigned to them. Creating Modes Let's take a look at how to create modes for a gobo wheel. This gobo wheel can be indexed or rotated.
  • Page 206 The range editor for gobo wheel mode will give an advisory saying which mode the ranges are used in. If changes are needed to those ranges, press {Remove as Mode} in the range editor. After the changes are made, you will need to reassign the modes. Ion Classic User Manual...
  • Page 207 After patching the new fixture, you will be able to check your modes in the encoder display and ML controls. There are now buttons for the modes, and for index, the degree symbol is displayed with the user value. Fixture Lamp Controls For many devices, their lamp and motor control functions can be controlled remotely using DMX.
  • Page 208 Press {Save Fixture} to store the new profile, or {Cancel Edit} to exit out and not save your changes. Note: If you leave the patch display without saving or using {Cancel Edit}, an advisory will display above the command line letting you know that you have unsaved data. Ion Classic User Manual...
  • Page 209 Color Calibration The fixture editor also offers the option to disable generic fixture color calibration by unchecking the "Use Calibration" box in the fixture editor. This disables generic color calibration, and simplifies the color calculations being used for that fixture profile. This can greatly improve fixture performance and speed for use in pixel maps. Note: Disabling a fixture's generic color calibration may affect its color matching, fades, or other functionality.
  • Page 210 You can now add or edit parameters as needed. See Editing Multicell Fixtures (on page 166) for more information. Editing Fixtures You can view and edit existing fixtures in the Fixture Editor. Edited fixtures will display with an "*" beside their name. Ion Classic User Manual...
  • Page 211 With the fixture selected, you can change the name by pressing [Label] or tapping on the fixture. You can press [Label] twice to clear the name. The virtual keyboard will open in the CIA. The fixture's name as it is in the library will still display by the new name. Note: Using [Update Profile] will remove any edits made to existing fixtures.
  • Page 212 Ion Classic User Manual...

  • Page 213: Setup

    Chapter 5 Setup About Setup System Settings User Settings Device Settings Console Status Display Setup...

  • Page 214: About Setup

    Table view. You will not be able to record just the Hue or Saturation values into a cue, submaster, preset, or palette, and you cannot apply an effect to Hue and Saturation. You will still be able to control Hue and Saturation from the encoders, ML Controls, Color Picker, and the command line. Ion Classic User Manual...
  • Page 215 Display Colors in D65 Displays colors of gels and current light output on the encoder display, color picker, pixel map, and magic sheet link to channel color using a D65 white point. Enabled by default. Disabling this option switches Eos back to using a D50 white point, as in software versions prior to v3.0.0.
  • Page 216 A device ID can be from 0-126. MSC commands can be sent to ID 127, which is the All Call device ID. While Eos cannot be set to ID 127, it will respond to commands sent to the All Call device ID. Example: MSC Rx Device ID [5] [0] [Enter] • Ion Classic User Manual...
  • Page 217 MSC Tx Device ID This setting allows you to choose the devices through which the console will send MIDI data. When set, the console will transmit MIDI data to any Net3 Show Control or Response MIDI gateway that has a matching “ACN MIDI Tx ID.” The console will send the MIDI data over an ACN connection to the gateways.
  • Page 218 The contact closures require DC voltage, which is supplied by the console on pins 14 and 15. See the diagram below. Local Relay Controls > Relay Out Allows you to assign the Relay Out Source ID and the Relay Out Address. Ion Classic User Manual...
  • Page 219 A space needs to be used to separate the addresses. Note: ETC recommends using 8000 and 8001 respectively for port numbers. Remember that when setting port numbers on your external device that they should be set to the opposite of what Eos is set. For example, if {OSC UDP TX Port} on Eos is set to 8000, then the RX (incoming) port on your external device needs to be set to 8000, and vice versa.
  • Page 220 (for use with Paradigm, for example). String RX Port This setting specifies the UDP port that the console will listen to for receiving strings. String TX Port Setting for the UDP destination port that the console will send strings to. Ion Classic User Manual...
  • Page 221 String TX IP Address Sets the destination IP address that the console will send UDP strings to. Multiple IP addresses can be entered, separated by either a space, comma, or semicolon. Port numbers can also be appended to IP addresses with a colon to send UDP strings specifically to that port (10.101.2.99:8001, for example).
  • Page 222 • Gel Match Type (Color Picker Setting) • Gel Swatch Type (Color Picker Setting) • Pop-up Magic Sheet • Pop-up Nav Lock • Augment3d The table displays the status of running Augment3d instances, and associated information. Ion Classic User Manual...

  • Page 223: User Settings

    To select which instance of Augment3d the console uses, highlight the desired instance and click the {Connect to Server} button. To switch from a tethered computer back to the console, highlight the instance with address "Local" and select {Connect to Server}. For more information on Augment3d Tether, see PC / Mac (Tether Mode) (on page 468) Metric/Imperial...
  • Page 224 High/Low. An intensity level or a preset can be assigned in this field. Channels not in highlight or lowlight that are not included in the preset are not affected. Ion Classic User Manual...

  • Page 225: Device Settings

    Default Times In this section you may change the default times for sneak commands and the respective feature response times based upon parameter category. The default for these is 5 seconds, except for back time, which uses a default of 1 second. You can assign separate timing values to the Release and Off functions.
  • Page 226 How much any associated parameters change in one full revolution of a mini encoder. Defaults to 35. Scroll Percent Per Rev Note: This option is only applicable to Eos Apex consoles. How much any associated parameters change in one full revolution of an endless fader wheel. Defaults to 125. Ion Classic User Manual...
  • Page 227 Input Devices Swap Pan/Tilt Trackball settings to swap the pan and tilt parameters. Disabled by default. Reverse Pan Reverses the range of the pan parameter. Disabled by default. Reverse Tilt Reverses the range of the tilt parameter. Disabled by default. Spacebar [Go] Allows you to enable the spacebar on an external keyboard as the hotkey for [Go].
  • Page 228 {Show Reference Labels} can be enabled at the individual tab level by accessing the tab's configuration menu. This will override the setting in Setup. Default Display Order Determines the appearance of the Workspace Layout Menu (on page 90) Ion Classic User Manual...
  • Page 229 In-Cell Editing When disabled, this setting prevents changes to be made to the cells in the Live/Blind and Playback Status Displays. {In-Cell Editing} is enabled by default. Note: Options in the CIA are not affected by this setting. DirSel.Dbl Clk When enabled, double clicking a direct select button will act as [Recall From] [Record Target] to place the entire contents of that preset, palette, or step-based effect on stage.
  • Page 230 These sliders control the brightness, backlight level, and contrast of the displays of any connected USB fader wings. Selecting {Invert} will invert the LCD. All sliders default to 55%. Note: Additional sliders may appear to control brightness settings for any additional detected displays. Ion Classic User Manual...

  • Page 231: Console Status Display

    PDF Settings Paper Orientation Choose a portrait or landscape PDF orientation. Paper Type Choose a PDF page size from Letter, 11x17, A2, A3, and A4. Recall Device Settings This option is not currently enabled in Eos software. Console Status Display The Console Status Display (CSD) shows informational, advisory, or warning messages about your console.
  • Page 232 Largest Free Block is under a certain amount. • RAM usage is at or above a certain amount. • Application memory usage is at or above a certain amount, which is close to • exhausting addressable memory space. Ion Classic User Manual...

  • Page 233: Manual Control

    Chapter 6 Manual Control About Manual Control Selecting Channels Setting Intensity Manual Control of Non-intensity Parameters (NPs) Home Multiple Intensity Channels Multicell Fixtures Lamp Controls Using [+%] and [-%] Remainder Dim Highlight and Lowlight Sneak Staging Mode Select Keys Channel Check Address at Level Address Check Flash...

  • Page 234: About Manual Control

    Channels are deselected when any action is taken on the keypad that is unrelated to manual control, such as recording groups and cues, or updating a record target, etc. You can also press [Clear] after a terminated command line to clear the channel selection.
  • Page 235 Using Groups as a Channel Collector [Group] can be used as a quick way to collect channels from submasters, cues, palettes, or presets. See About Groups (on page 252) for more information. The following actions are possible: [Group] [Cue] [1] - selects all the channels in cue 1. •...
  • Page 236 {InterLeave} [Enter] would create these 5 subgroups: (1,11,21) (2,12,22) (3,13,23) (4,14,24) (5,15,25). {Num Groups} creates a specified number of subgroups. • [1] [Thru] [1][2]{Num Groups} [3] [Enter] would create these 3 subgroups: (1,2,3,4) • (5,6,7,8) (9,10,11,12). Ion Classic User Manual...
  • Page 237 [1] [Thru] [2] [4] [Offset] [4] [/] [4] [Enter] - selects channels 4, 8, 12, • 16, 20, and 24. You can select to offset by 2/2, 4/4, 3/3 etc. [Offset] can also be used more than once to apply different offset commands to different channel selections on one command line.
  • Page 238 Channels are deselected when any action is taken on the keypad that is unrelated to manual control, such as recording groups and cues, or updating a record target, etc. You can also press [Clear] after a terminated command line to clear the channel selection.

  • Page 239: Setting Intensity

    Note: [Select Last] is a fast way to regain your last channel selection. See Select Last (on page 247) Any manual control action taken while record or update is on the command line will automatically reselect your last channel selection. Setting Intensity Channel intensity may be manually entered from the keypad, set with an intensity palette (if programmed) or set with a level wheel.

  • Page 240: Manual Control Of Non-Intensity Parameters (Nps)

    If channels are selected that have different device types, such as spot and wash lights, the CIA will show all of the available parameters. The following examples illustrate how to set parameter values with the keypad: Ion Classic User Manual...
  • Page 241 Form- includes parameters that affect the quality or size of the light output, such as • edge, zoom, iris, IMF, frost, etc. Image - includes anything that drops into the gate, such as gobos, effects wheels, etc. • Shutter - includes all of the framing devices for the luminaire.
  • Page 242 See Using the Editor (on page 168) When you access a parameter page, the encoders will automatically load and display the first page that has a valid parameter for the selected channels. Ion Classic User Manual...
  • Page 243 Encoder Softkeys A series of buttons are included in each of the four encoders sections of the display including {Home}, {Last}, and {Next} or {Min} and {Max}, and depending on the type of parameter, a {Mode}, {Expand}, or {Calibrate} button. Note: To access these softkeys at any time, press down on an encoder.
  • Page 244 Form Control Form (a subcategory of Beam) collects the parameters that affect the quality of the beam, including the iris, edge, frost, etc. ‘Shutter’ and ‘Image’ are the other two subcategories of Beam When the form encoder page button is selected, the LED will illuminate and the encoders automatically populate with the “Form”...
  • Page 245 Encoder Buttons Note: The encoder buttons are used with the encoders for shutter control. These buttons do not work with the shutter graphic control. The following buttons are available for shutter control: Angle Home - sets the angle of all of the shutters to their home position. •...
  • Page 246 Color scroller data will display on the encoders and displays as frame numbers, F1, which would be frame 1, F2 for frame 2, etc. F1.5 is halfway between 1 and 2. F2+ will display if the frame is less than 2.5 and F2- if the frame is greater than 1.5.
  • Page 247 Note: Multiple color picker tabs with different color spaces can be opened at the same time. Multiple color spaces can be opened on the same tab. The available color spaces are: Note: When a fixture is in HS mode, the brightness control is not provided. Intensity controls the brightness.
  • Page 248 {Brightest} - determines the color match used. This is helpful when working with fixtures • that have more than three color components, such as RGBA, RGBWm or ETC's fixtures. Pressing {Brightest} or {Shift} +a gel from the picker will cycle through the three modes.
  • Page 249 {Similar} - will show gels that are in the same selected area of the color picker. Only gels • in the same selected gel book will display. You can switch to another gel book though to discover gels in that area. {Show Gels as Gel Against White Background} displays the raw gel color as it would •...
  • Page 250 7 has additional controls for Hue, Saturation, and Brightness. You can move those controls to adjust the fade, and you'll see a representation of those changes in both the color path preview bar and in the color space. Ion Classic User Manual...
  • Page 251 Changes can be stored in the destination cue as absolute data by using [Update] or [Record]. When there's a change to the color path information, a red c will display next to the channel number and the color path's name will display in red in the color path display. When that data has been saved, a blue c will display.

  • Page 252: Home

    When a fixture with multiple intensity parameters is patched, Eos assigns it a master intensity. The master intensity can be used to control the multiple intensities together. The master intensity is handled in the same way as the intensity of a single intensity channel. Ion Classic User Manual...

  • Page 253: Multicell Fixtures

    Levels can be set via the level wheel, from the keypad, and the encoders. The other intensities will default to 100%. Control of the individual intensities of a multiple intensity channel is handled using the parameter buttons in the CIA (see Manual Control of Non-intensity Parameters (NPs) (on page 226) ) or the encoders (see...
  • Page 254 [5] [.] [1] [Thru] [Enter] or [5] [.] [1] [Thru] [At] - automatically puts the last cell's • number on the command line before a [Enter] or [At] command. [5] [.] [-] [4] [Enter] - selects all of the cells except cell 4. • Ion Classic User Manual...

  • Page 255: Lamp Controls

    [1] [+] [+] [2] [.] [3] [Enter] - selects all of channel 1, and only cell 3 of channel 2. • [1] [+] [3] [.] [2] [Shift] & [.] - appending [Shift] & [.] after a cell number will post [All •...

  • Page 256: Remainder Dim

    Using the [Next] and [Last] buttons releases the current selected channel from remainder dim mode and sets its intensity to zero, while selecting the next or last channel and continuing rem dim operation. Ion Classic User Manual...
  • Page 257 Example: Assume channels 5 through 9 are selected and set at an intensity level of 50% and channels 10 through 15 are selected and set at an intensity level of 70%. Select channel 9 and dim the remaining channels. [9] [Rem Dim] [Enter] •...

  • Page 258: Highlight And Lowlight

    1. [Group] [1] {Highlight} [Enter] - places channels 1 through 5 in highlight. 2. [Next] - specifies channel 1. 1 is in the highlight value. • 2 - 5 are in the lowlight value. • All other channels go to the defined rem dim level. • Ion Classic User Manual...

  • Page 259: Sneak

    You may assign both a highlight and a lowlight preset in setup (see Manual Control (on page 210) ). Any preset may be used. Channels with only one parameter included in the preset assigned to Highlight and Lowlight will not reset other parameters back to their default highlight values (see above).

  • Page 260: Staging Mode

    When used with a channel selection, only those channels will be affected. Staging Mode Staging Mode allows you to preview changes temporarily, and then either commit them to Live or Blind, or revert them. Ion Classic User Manual...

  • Page 261: Select Keys

    The [Select Last] key allows you to reselect whatever the previous channel selection was. This includes multiple channel selections, groups, etc. Using [Select Last] , Eos will recall your last selection and leave it unterminated for further operation. This will work for a loop of the last five selections.
  • Page 262 [Enter] [Select Last] will put channels 10 through 20 onto the command line. Note: On Ion Classic and Element Classic, {Select Active} is a softkey. Select Manual The [Select Manual] key is used to select all channels that currently have manual data. You may use [Select Manual] combined with the parameter control keys to capture only certain parameters of a channel with manual data.

  • Page 263: Channel Check

    • target group. Note: On Ion Classic and Element Classic, {Select Manual} is a softkey. [-] Select Manual or Select Active [-] [Select Manual] or [-] [Select Active] can be used to modify channel selections. Using [-] [Select Manual] will select all of the channels in the list except those that have manual data.

  • Page 264: Address Check

    Pressing [Shift] & [Out] together will put all the selected channels to out and “Flash Off” will be posted to the command line. Releasing the keys will return the channels to their previous state. Ion Classic User Manual...

  • Page 265: Groups

    Chapter 7 Groups About Groups Recording Groups Live Selecting Groups Opening the Group List Using Groups as a Channel Collector Groups...

  • Page 266: About Groups

    If new channels are added to an ordered group using an update command, those channels are added to the end of the channel list from an ordering perspective. Ion Classic User Manual...
  • Page 267 When a group is previewed using the Group List, the display defaults to showing the ordered view. Channels can be reordered as needed from this list. Use the [Format] key to change to a numeric listing of channels. Example: [1] [0] [Thru] [2] [Record] [Group] [1] [Enter] •...

  • Page 268: Selecting Groups

    Pressing it again accesses the second ordered channel in that group, and so on. [Next] - used after the last channel in the group - accesses the first channel in the group again. [Last] may be used with group selects similar to [Next]. Press [Select Last] to reselect the entire group. Ion Classic User Manual...

  • Page 269: Opening The Group List

    Deleting Groups When you delete a group, the group number and all contents from the Group List Index and Direct Selects are deleted. Delete commands require a confirmation by default. This can be altered in the default settings. If you disable confirmations, the second enter is not required in the following examples: Group deletion features include: [Delete] [Group] [5] [Enter] [Enter] - deletes group 5.

  • Page 270: Using Groups As A Channel Collector

    [Group] [Cue] [1] - selects all the channels in cue 1. • [Group] [Sub] [3] - selects all the channels in submaster 3. • [Group] [Int Palette] [5] - selects all the channels in intensity palette 5. • Ion Classic User Manual...

  • Page 271: Fan

    Chapter 8 About Fan Fanning Parameter Data Fan From the Command Line Fanning References Fanning Timing and Delays Using Subgroups with Fan...

  • Page 272: About Fan

    [1] [Thru] [5] [At] [1] <0> [Thru] [5] <0> [Enter] - sets channel 1 to 10%, 2 to 20%, 3 to • 30%, 4 to 40%, and 5 to 50%. This is the default fan adjustment and the {Fan} command is not necessary. Ion Classic User Manual...

  • Page 273: Fanning References

    [1] [Thru] [5] [At] [1] <0> [Thru] [3] <0> {Fan} {Mirror} [Enter] - sets channel 1 to 30%, • 2 to 20%, 3 to 10%, 4 to 20%, and 5 to 30%. Fanning References When fanning references, such as palettes, if there are more than 2 reference lists are used then the data will be referenced data.
  • Page 274 Ion Classic User Manual...

  • Page 275: Mark

    Chapter 9 Mark About Mark AutoMark Referenced Marks Mark...

  • Page 276: About Mark

    When enabled, the cue that executes the mark will have an “M” in the flags field. If AutoMark is disabled, allowing a live move, a “D” is displayed in the flags field of the cue or cue part where the data is stored. Ion Classic User Manual...

  • Page 277: Referenced Marks

    By using AutoMark with multipart cues, it is possible to have some parameters mark and others move live. AutoMark and Timing An AutoMark will happen in the time of the cue in which is moving (the “M” cue), unless the channel has discrete timing or the mark time has been changed in setup.
  • Page 278 As long as intensity is at zero within the cue range, if there are any non-intensity move instructions for these channels between these two cues, they will be removed. Ion Classic User Manual...
  • Page 279 It is also possible to mark only certain parameters for marked moves, while allowing live moves for other parameters. Example: If you wanted to mark only focus, and allow all other parameters to transition while the light is fading up, you can press: [1] [Thru] [10] [Focus] [Mark] [Enter] •...
  • Page 280 If no discrete timing is used for non-intensity parameters or mark time is disabled: When channels execute a mark, the moves will use the time recorded in the marked cue. Ion Classic User Manual...
  • Page 281 Example: Cue 5 is recorded with a time of 10 seconds. [Record] <Cue> [5] [Time] [1] [0] [Enter] • A mark is applied to Cue 5 as above. [Cue] [5] [Mark] [Enter] • Later, channels 1-10 are assigned a mark instruction and then recorded into Cue 10 with no discrete timing: [1] [Thru] [1] [0] [Mark] [Enter] •...
  • Page 282 Eos will attempt to repair the mark. This is done by automatically marking in the cue previous to intensity fading up, if possible. This will be indicated in the cue list by a “*” in the cue immediately proceeding the “R” cue. Ion Classic User Manual...

  • Page 283: Palettes

    Chapter 10 Palettes About Palettes Palette Types Palette Options Storing Palettes Live Recalling Palettes Editing Palettes Live Editing Palettes in Blind Using By Type Palettes Removing Channels from a Palette Deleting Palettes Palettes...

  • Page 284: About Palettes

    XYZ Format} to toggle the format of data stored. Color Palettes Color palettes can be created for all channels that have any color parameter data. Color palettes store any combination of color data, including CMY, RGB, and HS settings, color scrollers and color wheels. Ion Classic User Manual...

  • Page 285: Palette Options

    You will find that [Record Only], filter settings and selective store commands will be very useful when storing color palettes. Beam Palettes Beam palettes can be created for all channels that have any beam parameter data. It is rare when storing beam palettes that you will wish to include all of the beam parameters for channels.
  • Page 286 1 through 9 to beam palette 5. [-] [5] [Record] [Beam Palette] [Next] [Label] <name> [Enter] - stores to the next • sequential beam palette, withholding the group or channels specified and adds a label. Ion Classic User Manual...
  • Page 287 Note: When using a selective store, you must specify the channel list to be included or excluded, identified by the [+] [-] modifier, as part of the [Record] command. Otherwise all channels with appropriate non-default data will be stored in the new palette.

  • Page 288: Recalling Palettes

    Show Ref Labels (on page 214) ). To see the numeric values behind any palette (or other referenced value), press and hold the [Data] key. To see the palette number behind the label, press [About] + [Label]. Ion Classic User Manual...

  • Page 289: Editing Palettes Live

    When palettes are recalled, channels with stored data in the palette will follow that data according to manual time settings. A manual time master fader can also affect the timing. See Manual Time Master (on page 128) for more information. Palettes may also be recalled using a time specified using [Sneak] [Time]. For examples on using [Sneak] [Time], see Sneak (on page 245) You may also use groups to recall palettes.

  • Page 290: Editing Palettes In Blind

    Palettes can be viewed and edited in blind in the table and spreadsheet views. In Blind, the following softkeys are available when editing palettes: By Type • Absolute • Lock • Cleanup • Discrete • Offset • Make Null • Make Absolute • Ion Classic User Manual...
  • Page 291 Replace With • Query • Entering Blind Palette from Live [Blind] [Palette] [Enter] - pressing this will display the first recorded palette of the • selected type (Intensity, Focus, Color or Beam) in blind or return to the last palette of this type viewed in blind.
  • Page 292 You can change the blind display to spreadsheet or table view by pressing the [Format] key. To copy a specific palette to a new palette: Ion Classic User Manual...

  • Page 293: Using By Type Palettes

    You can copy palettes within the list to another location in the list using [Copy To]. <Color Palette> [2] [Copy To] [9] [Enter] [Enter] - copies the contents of color palette 2 • to color palette 9. Color palette 2 will remain in the list. The second [Enter] is not required if you have disabled confirmations in setup.

  • Page 294: Removing Channels From A Palette

    [channel list] [Delete] [Color Palette] [2] [Enter] • Deleting Palettes To delete color palette 1, press [Delete] [Color Palette] [1] [Enter] [Enter]. When palettes are deleted, any references in cues will be converted to absolute data. Ion Classic User Manual...

  • Page 295: Presets

    Chapter 11 Presets About Presets Preset Options Storing Presets Live Recalling Presets Effects in Presets Editing Presets Live Using the Preset List Editing Presets in Blind Using By Type Presets Removing Channels from a Preset Deleting Presets Presets and Palettes Fader Properties Presets...

  • Page 296: About Presets

    (such as follow, delay, or cue overrides). When recorded or re-recorded, presets are automatically recalled on stage. Presets may be individually labeled. Ion Classic User Manual...
  • Page 297 Storing Presets Using [Record] The [Record] key will store all parameter data for channels with one or more parameters not at their home values, as modified by the filter settings in the CIA. If filters are used, only the parameters enabled by the filters are stored. When you record data to a preset live, the channels involved in that preset will then actually be in that preset.

  • Page 298: Recalling Presets

    Effects can be stored in a preset, and those presets can be used to create submasters and cues. However, the effect's data is only copied to the submaster or cue, it is no longer referenced through the preset. Ion Classic User Manual...

  • Page 299: Editing Presets Live

    Note: If used with submasters and cues, the data is not referenced. So if changes are made to the effect in the preset, the effect saved to the submasters and cues will remain unchanged. The preset list display has a column for effects. For more information, see Recording an Effect to a Preset (on page 392) Editing Presets Live...

  • Page 300: Editing Presets In Blind

    {By Type} Presets (on page 282) • {Absolute} Presets (on page 282) • {Locked} Presets (on page 282) • Cleanup ( Using By Type Presets (on page 288) • Discrete ( Using By Type Presets (on page 288) • Offset (on page 221) • Ion Classic User Manual...
  • Page 301 Make Null ( Editing in Table View (below) • Make Absolute ( Editing in Table View (below) • Editing in Table View (below) Replace With ( • Presets can be assigned an icon, which can be configured to appear on the direct select button in Direct Selects (Tab 4) or Custom Direct Selects (Tab 39).

  • Page 302: Using By Type Presets

    [Preset] [3] {Cleanup} [Enter] - converts presets created in earlier versions of Eos Family • software to by type presets. This command will use the first channel of each type as the default, and allow other channels of the same type to use that value upon recall. Ion Classic User Manual...

  • Page 303: Removing Channels From A Preset

    {Make Null} can be used with by type preset when you wish to withhold a channel from responding to a by type preset recall. The data will still display but will be in gray with a “N”. Updating By Type Presets Pressing {By Type} after an [Update] command, with a channel tracking but no default channel included in the update, will cause the lowest numbered tracking channel's level to be updated into the default channel.
  • Page 304 Faders can have their background states disabled. Background states are enabled by default. When enabled, the content of the fader will act as a background or previous state for other cues and faders. Background Priority Background can have a priority assigned to it. Ion Classic User Manual...
  • Page 305 In previous software releases, when content was released, it always returned to the last fader that owned it. Background priority releases to the highest priority content that previously had ownership, provided that content has not be turned off or released. There are 10 levels of background priority for faders.
  • Page 306 See Only (on page 129) for more information. Effect Master - masters the entry/exit mode of the effects (size, rate or both). • Levels Only - masters the levels without mastering the effect. • Ion Classic User Manual...
  • Page 307 Temporary Fader Mapping Presets and palettes can be used to create a temporary list of content that can be played back on a fader. Note: This list is not recorded. If the fader is unloaded, the list cannot be recalled. To create a list, press the [Load] button of an unmapped fader.
  • Page 308 Ion Classic User Manual...

  • Page 309: Single Cue Lists

    Chapter 12 Single Cue Lists About Single Cue List Basic Cueing Recording Cues in Live Using [Cue Only / Track] Selective Storing Cues in Live Timing Assigning Cue Attributes Flags Using External Links Modifying Cues Live [Update] Recording and Editing Cues from Blind Deleting Cues Using the Cue List Index Single Cue Lists...

  • Page 310: About Single Cue List

    Channels that have all home values, meaning they have never been changed, are not included in the record action, unless you specifically select the channel and press {Make Manual}. See Using {Make Manual} (on page 344) for more information. Ion Classic User Manual...
  • Page 311 Possible exclusions are parameters categories or individual channel parameters withheld by use of filters (see About Filters (on page 330) ). You can also select individual parameters of individual channels (such as Cyan and Iris) and place them in a null state using the {Make Null} Using {Make Null} (on button if the values are not needed in the cue you are recording.

  • Page 312: Using [Cue Only / Track]

    For clarity, only the contextual function of the button is used in the examples. With system set to Track [Record] <Cue> [5] [Q Only] [Enter] - records cue 5. New values or changes will not • track into the subsequent cue. Ion Classic User Manual...

  • Page 313: Selective Storing Cues In Live

    [-] [Color] [Record] <Cue> [5] [Q Only] [Enter] - as above the recorded data will not • track forward and all color data is excluded from the record operation. [Record Only] <Cue> [5] [Q Only] [Enter] - records all manual data, but doesn’t allow it •...

  • Page 314: Timing

    99:59 ( 99 minutes and 59 seconds), or seconds and tenths of seconds (example 1.3), or 100ths of seconds (example 1.35) with valid fade times from zero to 99.99. When no time is applied at a cue level, the defaults established in Setup are used. See Cue Settings (on page 201) Ion Classic User Manual...
  • Page 315 Example: You want the time for cue 1 to be 10 minutes and 15 seconds. [Cue] [1] [Time] [1][0][1][5] [Enter] • The command line will show the time as Cue 1 Time 10:15. If you want the time for cue 1 to be in seconds and tenths of a second, like 1.3 seconds, you will type using a decimal.
  • Page 316 {Select Manual} {Beam} [Time] [7] [Enter] - selects channels with manual data and • applies a time of 7 to any manual beam values. Discrete delay times can also be placed on a channel parameter. Ion Classic User Manual...

  • Page 317: Assigning Cue Attributes

    Note: Any conditions placed on channel /parameter in live (such as discrete timing, asserts, blocks, etc) must be stored or updated to the cue. Discrete Time as a Percentage Discrete times can be entered as a percentage of the cue time.
  • Page 318 Loop is provided as a method to link a series of cues and loop them a number of times in a sequence. Once the sequence of cues has played back the first time, the system recognizes the loop command and plays the sequence again, provided the target of the link is a previous cue. Ion Classic User Manual...
  • Page 319 If the first cue in the sequence is a cue with an assert attribute or has move instructions for channels, values from the last cue are not allowed to track through into the first cue when it is looped back. But without a move or assert in the first cue, values from the last cue will track into the first cue when it loops back.
  • Page 320 To add a note to the currently selected cue, you can use [Shift] & [Label]. You can use the virtual alphanumeric keyboard or an external keyboard to enter the desired text. Copy To and Move To for Labels, Scenes, and Notes (on page 341) for more information. Ion Classic User Manual...
  • Page 321 Scenes Scenes are a cue organization tool that provide a visual identifier for breaks in your show. Scenes allow for quick cue list navigation without needing to remember a cue's number. Scenes display in the cue list index and the playback status display as a green bar above the cue they are associated with in the list.

  • Page 322: Flags

    [Cue] [6] {Intensity} [Block] [Enter] - “I” is displayed in the flags field, indicating a cue • level intensity block. You could also use [Shift] & [Block] to put Intensity Block on the command line. Ion Classic User Manual...
  • Page 323 At a Channel / Parameter level Blocks can also be applied to a channel or a channel parameter. This can be done in live or blind. When applied in live, the block instruction must be stored or updated to the appropriate cue.

  • Page 324: Using External Links

    For example, assume that the last instruction above was applied to cue list 1, cue 1. When cue 1/1 is executed, any cues numbered “1” in cue list 2 will be executed Ion Classic User Manual...

  • Page 325: Modifying Cues Live

    accordingly. If there is not a cue 1 in that list, no action is taken. If there are cue numbers on secondary cue lists that are not in cue list 1, those cues are skipped and the subsequent cue taken as an “out-of-sequence” cue when triggered. When cues are taken on the primary list out of sequence, only like-numbered cues on the secondary lists will be replayed.

  • Page 326: [Update]

    Update is a powerful feature, and also very versatile. Using a combination of [Q Only], [Track], [Trace], and {Make Absolute}, the number of ways you can update specific information and manual data is virtually endless. Data can be updated to various record targets either at once, or individually. Ion Classic User Manual...
  • Page 327 Update Dialogue Box When you press [Update], a dialogue box will open in the CIA. Update styles and modifiers for those styles will be divided in the Update Dialogue Box. Note: Default Update Modes are set in Setup>User>Record Defaults. See Record Defaults (on page 209) for more information.
  • Page 328 [5] [Thru] [9] [Update] {Make Absolute} [Enter] - this will break only the references for • channels 5-9 and record their manual values to the cue. Other manual values will not be included in this update. You may also use [Record Only] to break references. Ion Classic User Manual...
  • Page 329 Example: Cue 5 is active and onstage. Channels 5 through 20 are currently referencing preset 1. You make changes to channels 5 through 9. The data for these changes is now manual. Press: [Record Only] [Enter] [Enter] • If there were other changes on stage, you could have used: [5] [Thru] [9] [Record Only] [Enter] [Enter] •...
  • Page 330 (indicating tracked) when the update is completed. Update [Thru] Using [Update] [Thru] allows you to update from a current cue to a destination cue without first entering the current cue's number. Ion Classic User Manual...

  • Page 331: Recording And Editing Cues From Blind

    Example: If you are currently in cue 5 and you want to update through cue 10, you would use the following syntax: [Update] [Thru] <Cue> [10] <CueOnly/Track> [Enter] • Update [+] [+] can be used to specify a range of cues for updating. [+] can also be used with [Record] and [Record Only].
  • Page 332 You can also deselect the parameters you do not wish to see. This is remembered the next time you go to table view. The table view is useful for viewing and editing all parameters for a smaller number of channels. Ion Classic User Manual...
  • Page 333 Both summary and table views allow you to make changes to channels/parameters. Editing From the Blind Spreadsheet The blind spreadsheet is another useful blind view of cue data. While in blind, press [Format] to access the spreadsheet. See Spreadsheet (Blind Only) (on page 99) for more information.

  • Page 334: Deleting Cues

    In the example above, deleting cue 5 (in cue only mode) would result in any tracked values in cue 6, that originated in cue 5, being converted to move instructions. Ion Classic User Manual...

  • Page 335: Using The Cue List Index

    If you apply the [Track] button to the delete instruction, the move instructions from cue 5 are deleted and the values from cue 4 would then track into cue 6 and beyond. Using the Cue List Index The cue list index is a blind display list which shows the cue list you are working with, the cue status, cue list properties, any other stored cue lists, and what (if any) faders the lists are loaded onto.
  • Page 336 Index tab and then double clicking on the tab to open the menu. With the Cue List Index selected, you can also select the gear icon, which is located by the tabs, to open the configuration menu. Ion Classic User Manual...
  • Page 337 The following options are available in this configuration menu: Display Cue Parts - displays the individual parts of a part cue. When not enabled, the • number of parts for that cue will display as a superscript number beside the cue's number.
  • Page 338 All non-intensity parameters are unaffected by the fader. Once the fader has reached full, control of intensity is retained. If the fader is moved toward zero, intensity will proportionally fade toward zero (not the previous state as per proportional faders). Ion Classic User Manual...
  • Page 339 In Manual Master mode, cues are triggered manually by faders without using the [Go] • button. With a cue list on a fader set to manual master, a cue will fire in manual time when the fader is moved from 0% or from Full. Timing is scaled. So, if color has a 5 count delay, and the duration of the cue is 10, the color transition will not begin until the faders manually reach 50%.
  • Page 340 Tap or click on {Chan Filter} to assign channels or groups. Tap or click on {Param Filter} to open a list of available parameters that you can filter. Note: Filters will travel with their assigned cue lists wherever they are mapped. Ion Classic User Manual...
  • Page 341 When a filter has been applied, an indicator will display in the fader ribbon. C will display for channel filter, and F is for parameter filter. Press the red [X] to clear the channel or parameter filters listed. Fader and Button Configuration Click or tap on the virtual buttons or fader to see a list of available configuration options.
  • Page 342 See Master Only (on page 129) for more information. Effect Master - masters the entry/exit mode of the effects (size, rate or both). • Levels Only - masters the levels without mastering the effect. • Ion Classic User Manual...

  • Page 343: Filters

    Chapter 13 Filters About Filters Record Filters Partial Filters Clearing Filters Storing Data with Record Filters Filters...

  • Page 344: About Filters

    1. Press and hold {Filter}. The parameter buttons change to display filter selection. 2. Press the parameter button (for example {Zoom}) for the parameter you want to include in the record target. That parameter will be highlighted and “Filter On” will appear Ion Classic User Manual...

  • Page 345: Clearing Filters

    above the softkey. 3. Release {Filter}. The buttons return to their normal appearance. In subsequent record functions, only the filtered parameters will be recorded. You may apply as many partial filters at once, as you wish. Any unfiltered parameters will not be included in record actions.
  • Page 346 Ion Classic User Manual...

  • Page 347: Multiple Cue Lists

    Chapter 14 Multiple Cue Lists About Working With Multiple Cue Lists Recording to a New Cue List Using [Go To Cue] with Multiple Cue Lists Multiple Cue Lists...

  • Page 348: About Working With Multiple Cue Lists

    [Record] [Cue] [Load] will create a cue 1 in a new cue list and will map that cue list to the fader. Subsequent cues can also be recorded with [Record] [Load], which will record to the next available cue within that cue list Ion Classic User Manual...
  • Page 349 Using Record Only [Record Only] can be used to create a new cue list instead of [Record]. [Record Only] stores only manual data to the specified cue. To record to a new cue list press: [Record Only] <Cue> [2] [/] [5] [Enter] - this will create cue list 2 and will record all •...
  • Page 350 This view is changed by the following actions: Recalling another cue list in the command line - [Cue] [3] [/] [Enter] • Recording a cue to another cue list - [Record] <Cue> [3] [/] [8] [Enter] • Ion Classic User Manual...

  • Page 351: Using [Go To Cue] With Multiple Cue Lists

    Playing back a cue from the fader of another cue list - press [Go] for the associated • fader. Note: The split Playback Status Display allows detail for two cue lists. Both or either of these can be locked. Playback Status Display (on page 106) Note: For information on using out of sequence sync, {OOS Sync}, see OOS Sync (on...
  • Page 352 [Go To Cue] [Out] [Enter] • Note: The [Go to Cue] [Out] command will not affect a cue list that is in Solo Mode (on page 322) Ion Classic User Manual...

  • Page 353: Advanced Manual Control

    Chapter 15 Advanced Manual Control About Advanced Manual Control Using [Copy To] Using [Recall From] Using {Make Null} Using {Make Manual} Using {Make Absolute} Using [Capture] Using Query Using [Undo] Advanced Manual Control...

  • Page 354: About Advanced Manual Control

    [1] [Copy To] [2] {From Absolute} [Enter] - sets channel 2 to channel 1's absolute level. • [1] [Copy To] {Live} [Enter] - copies channel 1's level to the live output. • In Live, you can use [Sneak] with [Copy To] to fade in the change. Ion Classic User Manual...

  • Page 355: Using [Recall From]

    Example: [1][2] [Copy To] [2] [Sneak] <Time> 7 [Enter] • Copies the recorded data from channel 12 to channel 2 and sneaks it in 7 seconds. Using the {HTP} softkey with [Copy To] will cause any intensity levels to be ignored if they are less than or equal to the copied value.
  • Page 356 Channels 1 through 5 are parked at 55. To recall that level to channels in live or blind, use the following syntax: [1] [Thru] [1][5] [Recall From] [Park] [Enter] • Channels 1 through 5 will be set to 55 and channels 6 through 15 will be unaffected. Ion Classic User Manual...

  • Page 357: Using {Make Null

    For more information about using Park, see About Park (on page 398) Note: This does not release the Park buffer. Using {Make Null} The {Make Null} softkey can be used to withhold parameter data from record or update actions in live, and remove parameter data from record targets in Blind. {Make Null} is applied using channel selection and can impact entire channels, individual parameters, or parameter categories.

  • Page 358: Using {Make Manual

    The following examples illustrate how to change referenced data into absolute data. [4] {Make Absolute} [Enter] - selects channel 4 and makes any referenced data for that • channel absolute data. [7] {Color} {Make Absolute} [Enter] - selects channel 7 and makes its color data • absolute. Ion Classic User Manual...

  • Page 359: Using [Capture]

    [3] [Thru] [9] {Color} {Intensity} {Make Absolute} [Enter] - selects channels 3 through 9 • and makes their color and intensity data absolute. In each of these examples, the channel display will change to show the result of the command. Wherever the reference was previously indicated (IP, FP, CP, BP, Pr), an absolute value (numerical) will be seen.

  • Page 360: Using Query

    Unless otherwise specified, Eos assumes that a query will apply to current output. Therefore use of the {Is In} softkey is optional. The CIA also repaints to display all of the available softkeys by which you can search. These can be used in defining your query criteria. Ion Classic User Manual...
  • Page 361 Default Includes the query softkeys along with additional query conditions. Text {Keywords} - displays buttons for all the text used in the text 1 through 10 fields and all • of the default keywords in Patch. {Gel} - displays all of the gels used in the current show file. •...

  • Page 362: Using [Undo]

    [Enter] and the last undo will be “redone” to reinstate the removed commands In a multiple user environment, each user is only able to undo the changes that they made. In the undo command history, the user will only see the commands that they used. Ion Classic User Manual...
  • Page 363 Note: Not all commands can be undone including playback actions, manual attributes placed on channels or encoder actions, and Augment3d model edits. Command History Command histories are kept for each editing session, which begins when: a console logs on to the network •...
  • Page 364 Ion Classic User Manual...

  • Page 365: Cue Playback

    Chapter 16 Cue Playback About Cue Playback Playback Controls Selected Cue Out-of-Sequence Cues Virtual Faders Assigning Faders Changing Fader Pages Playback Fader Controls Cue Playback...

  • Page 366: About Cue Playback

    It is important to familiarize yourself with the playback controls and their locations on your console. see the Ion Classic Overview (on page 66) for more information. Selected Cue When in Live or Blind, if you press [Live] or [Blind] respectively, the selected cue will be the last executed cue.

  • Page 367: Out-Of-Sequence Cues

    In Live To load a new cue to the pending file of the playback fader, press [Cue] [#] [Load]. When the [Go] button is pressed, the activated cue will be the selected cue. Example: Assume you have cue list 1 already loaded to the master playback faders. Now you want to load cue 2/1 to a fader.
  • Page 368 When [Go to Cue] is pressed, the softkeys in the CIA change to provide Go to Cue modifiers to enhance your playback ability. From these softkeys, you can specify that when going to a cue, only some elements of that cue will be played back. Specifically you can choose to play back: Ion Classic User Manual...
  • Page 369 Manual control using a fader • [Go to Cue] [6] {Manual} [Enter] • Scenes (on page 307) Scenes opens the selection display. • [Go To Cue] {Scenes} - press or select a scene to go to that cue. • Move instructions only •...

  • Page 370: Virtual Faders

    Cue List Index. Changes made to a cue list in the cue list index will be shared with any default mapping faders loaded with that Ion Classic User Manual...

  • Page 371: Changing Fader Pages

    cue list. If changes are made to a fader set to default mapping in the fader configuration display, those changes will also happen in the Cue List Index. If set to Local, any changes made in the fader configuration display will impact only that instance of the content. To load a new cue into the pending file of a playback fader, when auto playback is disabled in setup, or when you want to move a cue list to a different fader, first place that cue or list number on the command line then press the associated [Load] button for the destination...

  • Page 372: Playback Fader Controls

    In Ion Classic and Element Classic, many of the buttons mentioned below exist as softkeys. In order to have access to some of these keys, press [Fader Control] (Ion Classic) or [Live] {Fader Control} (Element Classic). The softkeys will change to display the fader control keys. You may press [More SK] if the green LED is illuminated, to view additional fader control buttons.
  • Page 373 Note: Ion Classic and Element Classic have physical grandmasters. If a grandmaster is set to a value other than 100%, a grandmaster button with the set value will be shown at the top of each display. If blackout is currently on, a blackout button will be shown at the top of the displays.
  • Page 374 [Fader Controls] {Freeze} &[Load] again for the specific faders to unfreeze the • activity. press {Assert} & [Load] or [Go] or [Stop/Back] for the specific faders to resume the • activity. You may freeze and unfreeze effects from the command line. Ion Classic User Manual...
  • Page 375 [Effect] [2] [Fader Controls] {Freeze} [Enter] - to freeze effect 2. Freezing a specific • effect is different from stopping an effect. Freeze will stop the effect exactly where it is. [Effect] [6] [Thru] [9] [Fader Controls] {Freeze} [Enter] - to freeze a specified range of •...
  • Page 376 If a pending cue has any manual control properties, you may either preset the fader to zero or the console will automatically set the fader to zero when the [Go] button is pressed. Ion Classic User Manual...
  • Page 377 Manual intensity override is not possible if there is any manual timing in the cue, as the fader is already occupied with that control. Manual Override Manual override allows the associated fader to control all parameters in a transition state on that fader.
  • Page 378 Ion Classic User Manual...

  • Page 379: Multipart Cues

    Chapter 17 Multipart Cues About Multipart Cues Record a Multipart Cue in Live Storing a Multipart Cue in Blind Deleting Parts from Multipart Cues Multipart Cues...

  • Page 380: About Multipart Cues

    Each part can contain its own cue level timing and other attributes. Follow/Hang, Link and Loop, and Allfade commands can be placed at the cue level only - they cannot be placed on a part. Also, through the channel selection, you can put channel parameters into different parts. Ion Classic User Manual...
  • Page 381 Labels, and Scenes. They are stored and function exactly as they do in single part cues. Flags can be set for Block, Assert, AllFade, Mark, and Preheat. On Ion Classic, flags can be set for Block, Assert, AllFade, Mark, and Preheat. On Element Classic, flags can be set for Block, Preheat, and Moves.

  • Page 382: Storing A Multipart Cue In Blind

    [Thru] [Thru] can be used in blind to create multiple cue parts in a range. [Cue] [1] [Part] [1] [Thru] [Thru] [4] [Enter] will create parts 1 through 4. • If you were to use just [Thru] instead of [Thru] [Thru], you would create parts 1 and 4. Ion Classic User Manual...

  • Page 383: Deleting Parts From Multipart Cues

    Deleting Parts from Multipart Cues When you delete parts of a multipart cue, any move instructions in the deleted part are moved to the first available part. If you want to delete move instructions out of a cue part, you have to select the channels and [At] [Enter] or null them.
  • Page 384 Ion Classic User Manual...

  • Page 385: Effects

    Chapter 18 Effects About Effects The Effect List Effects Editor Effect Status Display Effect Channel Display Step Effects Absolute Effects Effect Background Value Modification Beats Per Minute Multiple Intensity HTP Effects Relative Effects Preprogrammed Rainbow Effects Apply an Existing Effect Editing Effects Live Stopping Effects Query and Group Effect...

  • Page 386: About Effects

    Command Line Search (on page 81) for more information. Notice that there are effects existing in this list prior to any being recorded. Effects 901-918 are preprogrammed relative effects that are automatically available to you (see Relative Effects (on page 388) Ion Classic User Manual...

  • Page 387: Effects Editor

    To navigate this list use the navigation keys as described in Display Control and Navigation (on page 89) or select the effect number you wish to work with. Notice that when you select the effect list, the CIA changes to display the information for the currently selected effect. Effects can be assigned an icon, which can be configured to appear on the direct select button in Direct Selects (Tab 4) or Custom Direct Selects (Tab 39).
  • Page 388 This allows you to select which parameters will be involved in the selected effect, by default. By entering a value here, you do not need to specify the required parameter when placing an effect on a channel group. Ion Classic User Manual...
  • Page 389 To add/ remove parameters to the effect, press {Parameters} and then select the desired parameters from the buttons that appear to the left. {Parameters} {Iris} [Enter] • Attributes These determine the basic behavior of the effect. Attributes include behaviors such as forward, reverse, bounce, positive, negative, and random grouping/ random rate.
  • Page 390 0-200%, even, or solo. The default is even. For example: {Even} - The groups will be distributed evenly throughout the pattern. This is calculated • by dividing the cycle time of the effect by the number of groups of channels. Ion Classic User Manual...

  • Page 391: Effect Status Display

    {10%}-{200%} - When the first group is 10% through the effect, the second group will • start the effect, and so on through the remaining groups. Therefore, the groups will trail n% behind each other, as a percentage of the cycle time. {Solo} - The first group will execute the entire pattern.
  • Page 392 Grey - property is drawn directly from the effect. • Red - property has been manually modified but not stored. • Blue - property is an override to the saved effect. • Magenta - property is tracking from a previous cue. • Ion Classic User Manual...

  • Page 393: Effect Channel Display

    Clicking on the Attributes column will open the Effect Attribute Override display. From that display, you can access most of the same properties as those found in the Effect Editor. This display allows you to make modifications to properties, and store those modifications in a cue or submaster.

  • Page 394: Step Effects

    Off State - the parameter level (in%) or referenced data to be used for the steps off- • state. If you want the “off-state” to be the background state from playback, select the column and press [At] [Enter]. All times are entered from the keypad in minutes and seconds, tenths and hundredths. Ion Classic User Manual...
  • Page 395 If an effect step is on the command line or indicated in the blue text to the left of the command line, entering a number on the command line will default to selecting a step for the current selected effect. If no step is displayed, the command line will default to an effect number.
  • Page 396 Range for On State and Off State You can apply a range of levels to the on state and off state for the steps. You can either apply a range using the percentage or by using a palette. Ion Classic User Manual...

  • Page 397: Absolute Effects

    Example: Using the above example, select steps 1 through 6. {Steps} [1] [Thru] [6] [Enter] • Page arrow to the On State column and enter the on state range: [1][0] [Thru] [1][0][0] - assigns the range starting at 10 and ending at •...
  • Page 398 You can also define specific parameters for Absolute effect actions. To apply a parameter to a specific action, click in the Param column and select the desired parameter. Programming an Absolute Effect Below is the process used to program an absolute effect. Ion Classic User Manual...
  • Page 399 Example: To open the effects list press: [Effect] [Effect] • Establish the number of the effect by pressing: [Effect] [8] [Enter] • The CIA will repaint with unpopulated fields for the new effect. Assign the effect as absolute by pressing: <Type>...

  • Page 400: Effect Background Value Modification

    [Effect] [1] {BPM} [1][9][0] [Enter] - sets the BPM of effect 1 to 190. The step times will • be adjusted for step-based effects, or the time/ dwell will be adjusted for absolute effects. Ion Classic User Manual...
  • Page 401 The BPM will display on the right side of the effect editor beside the effect number/ label. Editing the cycle time, the step time for a step-based effect, or the time/ dwell for an absolute effect will remove the BPM. Learning BPM If you don't know the desired BPM, you can learn the BPM.

  • Page 402: Multiple Intensity Htp Effects

    Other pre-made focus effects can be modified in the same manner. The green arrow indicates default direction of motion, which can be modified in attributes. When adjusting the form of a focus effect, you can hold down [Shift] while using the horizontal encoder to change the vertical form. Ion Classic User Manual...
  • Page 403 Color Effects Color effects impact only color parameters. Hue and saturation offsets can be used which are represented in the horizontal and vertical axes of the graph in the effects editor. The {Parameters} key within a color effect displays the various color mechanisms used in any patched channels.
  • Page 404 The effect will appear in the effect list and the CIA will repaint with the effect details visible. Manipulate the effect using the encoders, effect graph, and / or property fields so that the effect meets your needs (see Effects Editor (on page 373) for details on effect properties and encoders). Ion Classic User Manual...

  • Page 405: Preprogrammed Rainbow Effects

    Preprogrammed Rainbow Effects Two preprogrammed rainbow linear effects are available in the effect list. Effect 917 is a Rainbow RGB effect, and effect 918 is a Rainbow CMY effect. These effects are for a rainbow on native color parameters that will fade hue from 0 to 360 with saturation at full, when the parameters are at their default levels.

  • Page 406: Query And Group Effect

    For more information, see Effects in Presets (on page 284) To apply an existing effect, press: [Select Channels] [Effect] [x] [Enter] • Recording to a preset, press: [Record] [Preset] [x] {Plus FX} [Enter] • Ion Classic User Manual...

  • Page 407: Recording An Effect In A Cue

    Pressing [Effect] after [Record] [Preset] [x] will append {Plus FX} to the command line. [Record] [Preset] [x] [Effects] [Enter] • Recording an Effect in a Cue To apply an existing effect, press: [Select Channels] [Effect] [x] [Enter] • Recording to a cue, press: [Record] [Cue] [x] [Enter] •...
  • Page 408 • behavior as using rate via the Effect Status Display). Min is 0, and Max is 200. Effect Size - similar to Effect Rate but for effect size. Min is 0, and Max is 200. • Ion Classic User Manual...

  • Page 409: Delaying Effects

    Fader Disabled - no action is assigned to the fader. • Effect Master - masters the entry/ exit mode of the effects (size, rate or both). • Button Options The following options are available for global effect buttons: Bump - plays back the effect at 100% of the recorded level. It will continue to do so until •...
  • Page 410 Select {Attributes} to define or redefine variables. If variables are redefined in an already- running effect, the ESD will show the effect in red, with an asterisk (*) next to the effect number to indicate that it was modified. Store any manual changes using [Record] or [Update] as normal. Ion Classic User Manual...

  • Page 411: Park

    Chapter 19 Park About Park Park Display Parked Values in Live Scaled Parked Values in Live Parked Addresses in Live Park Values from the Park Display Park...

  • Page 412: About Park

    Channels and parameters may be parked and unparked from the live display. Following are some examples: Note: To park a channel to a specific dimmer intensity level must be accomplished from the Parked Channel display. Access the Parked Channel display by pressing [Tab] [2][0] or {Park}[Park][Park] twice. Ion Classic User Manual...

  • Page 413: Scaled Parked Values In Live

    Note: Parked values will be displayed in the park display and in [About] & [Park]. To park a channel, parameter, or group from live: [2] [At] [5] [0] [Park] [Enter] - parks channel 2 intensity at 50% • [2] {Intensity} [Park] [Enter] - parks the intensity of channel 2 at its current value •...

  • Page 414: Park Values From The Park Display

    When parking a range of addresses in Park, using [Thru] will only park the intensities. If you want to park all of the addresses and parameters within the selected range, you will need to use [Thru] [Thru]. Ion Classic User Manual...

  • Page 415: Submasters

    Chapter 20 Submasters About Submasters Recording a Submaster Submaster List Editing Submasters Submaster Properties Submaster Fader and Button Configuration Submaster Information Labeling a Submaster Loading Submasters Using Bump Button Timing With Submasters Controlling Subfades Manually Execute List [Freeze] and [Stop Effect] on Submasters Moving and Copying Submasters Releasing Content From a Submaster Updating a Submaster...

  • Page 416: About Submasters

    Submasters can also be recorded using selective storing, which allows you to specify only the channels that you want stored. [6] [Thru] [1][0] [Record] [Sub] [3] [Enter] - records only channels 6 through 10 to • submaster 3. Ion Classic User Manual...

  • Page 417: Submaster List

    [1] [Thru] [5] {Blue} [Record] [Sub] [6] [Enter] - records only the blue color for channels 1 • through 5. [1] [Thru] [1][0] {Offset} {Odd} [Record] [Sub] [4] [Enter] - records channels 1, 3, 5, 7, 9 • into submaster 4. For more information on using {Offset}, see Offset (on page 221) If a submaster already has data stored to it, selective store will act as a merge function.
  • Page 418 Intensity playback behavior can be set to HTP (highest takes precedence) or LTP (latest takes precedence). Non-intensity parameters are always LTP. Eos defaults all submasters to HTP. For more information on HTP and LTP see HTP vs. LTP (on page 9) Ion Classic User Manual...
  • Page 419 Restore Submasters can be placed into restore modes of minimum or background, which is the default. When a submaster is in the restore to background mode, the restore column of the submaster list display will be blank. When in minimum mode, 'Min' will display in the restore column.
  • Page 420 Exclude From Inhibitive Sub - content cannot be mastered by an inhibitive submaster • Exclude From Solo - content will ignore solo. See Submaster Fader and Button • Configuration (on the facing page) for more information on solo. Ion Classic User Manual...

  • Page 421: Submaster Fader And Button Configuration

    Channel and Parameter Filters Channel and Parameter Filters can be used to allow only specified data to be played back. These are playback filters, and do not impact how data is recorded. For submasters, channel and parameter filters can be set in the following areas: Submaster List •...

  • Page 422: Submaster Information

    [Sub] [6] [Label] [xxxx] [Enter] - labels submaster 6. • [Sub] [6] [Label] [Label [Enter] - removes the label. • Note: If you would like your label to word wrap, use || to create a line break between words. Ion Classic User Manual...

  • Page 423: Loading Submasters

    Loading Submasters Faders can also be loaded with cues, presets, or palettes. You can convert an empty fader to a submaster without configuring it in fader configuration display. Any fader can be configured and loaded with a submaster if: the fader is not configured •...

  • Page 424: Execute List

    When an effect is stopped, all impact of the effect is removed and the stage output is as though the effect had never been activated. Moving and Copying Submasters You can move a submaster using Move To. Press [Copy To] twice to put Move To on the command line. Ion Classic User Manual...

  • Page 425: Releasing Content From A Submaster

    Example: [Sub] [2] Move To [Sub 9] [Enter][Enter] - moves the contents, label, • and timing data from submaster 2 and places it in submaster 9. Submaster 2 is removed. You can copy the contents of a submaster by using the [Copy To] button. [Sub] [2] [Copy To] [Sub 9] [Enter][Enter] - copies the contents, label, and timing data •...
  • Page 426 Ion Classic User Manual...

  • Page 427: Using About

    Chapter 21 Using About About [About] [About] {What's New} [About] System [About] Channel [About] Address [About] Cuelist [About] Cue [About] Curves [About] Effects [About] Groups [About] Submaster [About] Macro [About] IFCB Palettes [About] Presets [About] Color Path [About] Live Using About...

  • Page 428: About [About]

    • Fixture library version • Copyright notifications • Device name • Assigned as (Primary/Backup/Client/Offline) • User ID • Priority (ACN and Net2) • IP Address(es) • Number of defined parameters • Number of patched addresses • Ion Classic User Manual...

  • Page 429: What's New

    Number of unpatched defined parameters • Number of pixel mapping addresses • Number of patched channels • Number of cues (The number of cues is a count across all cue lists. Multipart cues are • only counted once.) Allowed output addresses •...

  • Page 430: [About] Channel

    Press [About] to put the CIA into About mode. When a channel is selected, the information below is displayed. You can select the information you wish to view from the buttons located on the right side of the CIA. The buttons are: {Current Value} displays information that indicates: Ion Classic User Manual...
  • Page 431 Channel number • Device Type • Most recent intensity move (cue number) • Next intensity move • What the channel is inhibited by (if anything) • Keywords • Notes • A list of all parameters on the channel showing the current value and its source, the •...

  • Page 432: [About] Address

    {Go To Patch} is a shortcut to edit the patch for the address selected. This will open up the patch display. {Fixture Notes} displays the following information: Revision number • Release date • Ion Classic User Manual...
  • Page 433 {Next/ Last Unpatched} will allow you to see what addresses closest to the current address are currently unpatched. {Dimmer Feedback} - appears when the current address is patched to a dimmer in an ETC Interface Protocols Sensor rack with a CEM+ or CEM3. Sensor feedback must be enabled. See (on page 557)

  • Page 434: [About] Cuelist

    The number of cues in the list (Multipart cues are only counted once) • First cue in the list • Last cue in the list • Partition • Playback number and physical fader location of the cue list • Ion Classic User Manual...

  • Page 435: [About] Cue

    Channels currently controlled in live by the cue list • Channels with any intensities above 0 in the cue list • Channels with Parameters stored in the cue list but no intensities • [About] Cue The following information will be displayed when a cue is selected: the cue number •...

  • Page 436: [About] Groups

    List of channels stored in the palette that are not used in a cue • List of cues in which the palette have a move instruction • List of effects that use the palette • List of presets that the palette is stored in • Ion Classic User Manual...

  • Page 437: [About] Presets

    [About] Presets When a preset is selected, the following information will be displayed: the number of channels • the first cue the preset is used in • the last cue the preset is used in • the number of cue lists that use the preset •...
  • Page 438 Ion Classic User Manual...

  • Page 439: Curves

    Chapter 22 Curves About Curves Creating a Curve Editing Curves Applying a Curve To Channels In Patch Curves Applied to Cues Applying a Curve To Scroller Fans Deleting Curves Curves...

  • Page 440: About Curves

    You can scroll through the list using the [Next] and [Last] keys, or you can specify a curve in the command line. {Curve} [9] [0] [4] [Enter] - selects curve 904 from the list and displays its shape in the • CIA. Ion Classic User Manual...

  • Page 441: Creating A Curve

    Creating a Curve When you have opened the curves display (see About Curves (on the previous page) ), you can select a curve or create a new curve by pressing: {Curve} [x] [Enter] • If the curve is already stored, the contents are displayed in the CIA. If this is a new curve, a linear curve is displayed.

  • Page 442: Applying A Curve To Channels In Patch

    4/6 through 4/9. [Cue] [5] {Attributes} {Curve} [At] [Enter] - removes any curve from cue 5. • [Cue] [8] [Part] [3] {Attributes} {Curve} [6] [Enter] - applies curve 6 to part 3 of cue 8. • Ion Classic User Manual...

  • Page 443: Applying A Curve To Scroller Fans

    Applying a Curve To Scroller Fans Curves can also be applied to a scroller fan. When applied to a scroller fan, the output of the fan will be controlled by the intensity of the channel. To apply a curve to a scroller fan, go to Patch>Attributes>{Fan Curve}.
  • Page 444 Ion Classic User Manual...

  • Page 445: Snapshots

    Chapter 23 Snapshots About Snapshots Recording Snapshots Recalling Snapshots Editing Snapshots Deleting Snapshots Snapshots...

  • Page 446: About Snapshots

    When recording a snapshot, you will see a preview of all of the displays as they will be recorded in the snapshot. You can choose to select/ deselect various components, monitors, frames, etc from your snapshot. From the snapshot menu, the following options are available:...
  • Page 447 Visible Workspaces - includes only the visible workspaces. • All Workspaces - include all workspaces, including those not visible at the time of • recording. Faders - captures the current content or state of the faders including: fader page • mapping, position of all submasters, and pending cues based on configuration.

  • Page 448: Recalling Snapshots

    CIA. If an element is added to the command line using the softkeys, it will be enabled when [Enter] is pressed. All other elements will be disabled. Snapshots can be labeled in the snapshot list by selecting the snapshot and pressing [Label] or by selecting the Label column. Ion Classic User Manual...

  • Page 449: Deleting Snapshots

    Example: <Snapshots> [3] {Monitors} [Enter] • This command will enable the monitors for snapshot 3 and disable any other elements. Snapshots can be assigned an icon, which can be configured to appear on the direct select button in Direct Selects (Tab 4) or Custom Direct Selects (Tab 39). See Icons (on page 118) more information.
  • Page 450 Ion Classic User Manual...

  • Page 451: Macros

    Chapter 24 Macros About Macros Store a Macro from Live Using the [Learn] Key Macro Editor Display Create a New Macro from the Display Edit an Existing Macro Play a Macro Stop a Macro Deleting Macros Macros...

  • Page 452: About Macros

    [Learn] [4] [Enter] [-] [Sub] [Record] [Learn] - records macro 4 with instructions to • record a target excluding all submaster data. [Learn] [2] [Enter] [-] [Group] [6] {Color} [Record] [Learn] - records macro 2 with • instructions to record a target excluding the color data from group 6. Ion Classic User Manual...

  • Page 453: Macro Editor Display

    You can also create a macro in live that bumps submasters across fader pages but first you must have content assigned to the submasters. Example: Write submasters 1 through 5 and 15 through 17, each with its own channel selections at 100%. Then press: [Learn] [1] [Enter] [Bump1] [Bump2] [Bump3] [Bump4] [Bump5] [Fader Page] [Bump15] [Bump16] [Bump17] [Learn]...
  • Page 454 [Go] on the cue’s playback but not the playback that triggered the executed cue. {Target Device} - A macro can have a Target Device assigned to it. This allows a cue to • execute a macro only on a certain console. Ion Classic User Manual...

  • Page 455: Create A New Macro From The Display

    The Target Device can be a device name or User ID. These are assigned to a macro in the • Macro Display by using the {Target} softkey and either selecting {Device} and {User}. Pressing {Target} will also display a list of connected devices and additional target options.

  • Page 456: Play A Macro

    Create a New Macro from the Display (on the previous page) Stop a Macro If you need to stop a Macro while running (for example, during an infinite loop) you may press [Escape] and the macro will stop. Ion Classic User Manual...

  • Page 457: Deleting Macros

    Deleting Macros You can delete a macro from the Macro Editor display by selecting the macro and pressing [Delete] [Enter]. You will be prompted to confirm the deletion. Confirm by pressing [Enter] again, or abort by pressing [Clear]. Example: Delete macro 5 from the macro list. [5] [Enter] •...
  • Page 458 Ion Classic User Manual...

  • Page 459: Magic Sheets

    Chapter 25 Magic Sheets About Magic Sheets Magic Sheet Browser Magic Sheet List Display Tools Navigating a Magic Sheet Creating and Editing Magic Sheets Limited Expand Mode Examples of Magic Sheets Magic Sheets...

  • Page 460: About Magic Sheets

    If no magic sheets exist in the show file, the magic sheet browser will be blank except for the New Magic Sheet icon. Click on the icon to open the magic sheet editor. Ion Classic User Manual...

  • Page 461: Magic Sheet List

    After you have created a magic sheet, you can recall a specific magic sheet, by pressing [Displays] {Magic Sheet} [#] [Enter] or you can navigate to Displays> Record Targets>Magic Sheet and press [Select] to open the magic sheet list (see Magic Sheet List (below) All available magic sheets will also be shown in the magic sheet browser.

  • Page 462: Display Tools

    Show Reference Labels - when enabled, channel objects that reference record targets • (such as presets or palettes) with labels will have their labels displayed in the Magic Sheet rather than their target type and number. [About] & [Label] can be used to temporally toggle between views. Ion Classic User Manual...

  • Page 463: Navigating A Magic Sheet

    Limited Limited Expand Mode - allows a magic sheet to be displayed at fullscreen. See • Expand Mode (on page 463) for more information. The following options are only available while in Limited Expand Mode: Disable Keyboard Input - disables input from the face panel and an external keyboard. •...

  • Page 464: Creating And Editing Magic Sheets

    DELETE - delete • ESC - finish line/polygon creator or close tab. • Creating and Editing Magic Sheets Pressing the edit button on the right hand side of the magic sheet display will open the editing tools. Ion Classic User Manual...
  • Page 465 The main area of the magic sheet will display a grid to aid with layout. The editing tools will be displayed on the right side of the magic sheet. The editing tool window is divided up into three areas: layout tools, the MS Object Library, which is made up of four tabs that contain the MS Objects, and the MS Object Properties.
  • Page 466 Zoom to Selection - zooms to show all selected objects. • Center on Selection -centers the display on the selected objects without changing the • zoom level. Alignment Clicking on the alignment icon will open the alignment options menu. Ion Classic User Manual...
  • Page 467 Create Array Allows you to create arrays of objects. After placing one object of your choice, click on {Create Array} to open an additional window for choosing what array type you want to use. Rectangle Lays out a rectangle array of objects. You can define the rows, columns, and spacing. Circle Lays out a circle array of the objects.
  • Page 468 (including the first and last ones you positioned), click the {Distribute Rotation} button. Flip Allows you to flip objects horizontally or vertically. You have the option of also flipping the text position and / or the target field positions. Ion Classic User Manual...
  • Page 469 Ordering The objects can either be placed on their own or stacked on top or beneath of each other. Clicking on the order icon will open the ordering options, which include: Group - allows you to group objects together so they can be moved and rotated like a •...
  • Page 470 Truss places truss. draws shapes that can have a target assigned to them or Shapes could be used to represent set pieces. allows for free form creation Points of objects. Ion Classic User Manual...
  • Page 471 Fixture Symbols From the second tab, fixture symbols can be placed on a magic sheet. The symbols can be tied to a channel number. Information about that channel can be displayed with the symbol, such as intensity, FCB data, and error indicators. See MS Object Properties (on page 460) for more information on the customizing options available.
  • Page 472 Background images are set and configured in the background settings tab. See Background Settings (below) Background Settings In the fourth tab, you can adjust the settings for the magic sheet background. Backgrounds can be a solid color, a gradient of two colors, or an image. Ion Classic User Manual...
  • Page 473 Interactive Toggles interactivity on or off for the entire magic sheet. If toggled on, all objects will respect their per-object settings for interactivity. If toggled off, no objects will be interactive, regardless of their per-object settings. High Quality Toggles high quality rendering of the selected magic sheet. If unchecked, optimizations will be made to the scaling and display of images in the magic sheet, which may improve performance and reduce lag, but at the expense of image quality.
  • Page 474 The font used for a text object can be changed and adjusted as needed here. You can select font type, size, color, bold, italic, underline, and justification. Change Type Allows you to quickly change the type of one or more selected objects. Ion Classic User Manual...
  • Page 475 Target Selects the target of the object. Most objects default to a target type, but that can be changed. The targets available are: None • Address • Beam Palette • Channel • Channel (by Address) • Color Palette • • Cue - Active •...
  • Page 476 Text Gel • Intensity • Intensity Bar • Color Swatch • Summary • Focus • Color • Beam • Status • Prev Move • Next Move • Channel • Address • Port/ Offset • • DMX Bar • Ion Classic User Manual...

  • Page 477: Limited Expand Mode

    Interactive This checkbox toggles whether or not the object is interactive. Interactive objects can be selected in the same way as a direct select or virtual fader. Objects set to not-interactive cannot be selected, and will only display information.This checkbox is unavailable for any inherently non-interactive objects (such as a command line).

  • Page 478: Examples Of Magic Sheets

    Green - master or backup has reconnected. • Examples of Magic Sheets The following are examples of magic sheets created using the magic sheets feature. These examples use a variety of objects provided in the software along with user-generated images. Ion Classic User Manual...
  • Page 479 Magic Sheets...
  • Page 480 Ion Classic User Manual...

  • Page 481: Augment3D

    Chapter 26 Augment3d About Augment3d Hardware and Software Requirements Running Augment3d Augment3d Key Terms Navigation in Augment3d Augment3d Control Mode Augment3d Edit Mode Augment3d Toolbar Fixtures in Augment3d Augment3d with Magic Sheets & Pixel Maps Augment3d Objects Vectorworks Augment3d Plug-in Augment3d...

  • Page 482: About Augment3D

    Augment3d tether is an extension of the console it is connected to, rather than a standalone client. The setup for this mode is identical to that of an ETCnomad client computer in a networked system of consoles. An ETCnomad dongle is not required for Augment3d tether. Ion Classic User Manual...

  • Page 483: Augment3D Key Terms

    Note: ETCnomad Puck is considered a console, and is subject to the console restrictions above. 1. Ensure the computer is running the version of ETCnomad that matches the software version installed on the connected console. 2. On the console, enable Augment3d for your user number. In the CIA, navigate to Setup > System Settings > Users.
  • Page 484 Pan / Tilt Kinematics - an aspect of a fixture profile that turns DMX values into a • direction the beam is pointing. Model - the Augment3d virtual 3D space. • XYZ Programming - telling the console to aim a fixture's beam through a particular • point in virtual space. Ion Classic User Manual...

  • Page 485: Navigation In Augment3D

    Navigation in Augment3d Keyboard Augment3d Control Mode (on the next page) , use the standard arrow keys to move the Augment3d Edit Mode (on page 473) camera around the Augment3d space. In , both the standard arrow keys and WASD keys may be used. W / UP - moves the camera up.

  • Page 486: Augment3D Control Mode

    Limited toolbar options are available in Control Mode: Camera Tool (on page 488) • Focus Tool (on page 489) • Labels Tool (on page 489) • Sticks Tool (on page 490) • Light Tool (on page 490) • Options Tool (on page 490) • Ion Classic User Manual...

  • Page 487: Augment3D Edit Mode

    Augment3d Edit Mode Edit Mode is the secondary Augment3d view, allowing for editing and configuration of your space, fixtures, and objects. Surrounding the central workspace are primary windows to assist in fixture and object manipulation: the Library, Materials, Preferences, Hierarchy, and Inspector. These windows can be freely dragged, rearranged, re-sized, and closed.
  • Page 488 Do not use Eos Undo operations via the command line while editing an Augment3d model, as it can alter your show data unexpectedly. Full Undo options for Augment3d will be implemented in a future Eos software release. Ion Classic User Manual...
  • Page 489 XYZ & Origin In Edit Mode, Augment3d models are arranged around three axes; horizontal X (red) and Y (green), and vertical Z (blue). The point at the intersection of these axes (0,0,0) is the origin. This virtual point in Augment3d must correspond to a real point in your space, ideally on the floor. This could be in the center of your stage, in a corner, or any convenient point.
  • Page 490 This allows those objects to be controlled together; for example, as patched scenic elements (for more information, see Scenic Elements (on page 509) Scenic elements can be given intensity values, moved, rotated, etc. This allows you to change the visibility and position of Augment3d objects using cues, submasters, and so on. Groups A group is an Augment3d object designed to be the parent of other objects which have their own unique coordinates.
  • Page 491 Materials Library Navigating to Window > Materials will open a window with the materials library, containing all stock materials, along with any you have created or imported. Note: Stock materials cannot be edited or deleted. To alter a stock material, duplicate it and make changes to the copy. Search for materials using the search bar.
  • Page 492 To save changes and close the materials list, use the checkmark button. To discard changes, use the trashcan button. Custom Materials Custom materials can be created by adding JPG or PNG images to a zipped folder. The images must match the following naming conventions: Ion Classic User Manual...
  • Page 493 If a tether and a console are connected, materials can also be imported from the tether device by entering Edit Mode, navigating to File > Import to Library > Materials, and Additional materials resources are also available on the ETC website, etcconnect.com. CAUTION: Custom materials must be applied to an object in order to be saved with the show file.
  • Page 494 Sets the angle increment for object placement snapping (in degrees). Focus Height Sets the Focus Height offset. Also available in Toolbar > Focus. Origin Toggles the origin point marker on or off. Show Refresh Rate Toggles visible frame rate monitoring on or off. Graphics Ion Classic User Manual...
  • Page 495 Quality The following graphics quality options are available: Low - no realtime lighting, simple beam indicator, low-texture resolution, no anti- • aliasing, no shadows Medium - realtime lighting, low beam quality, medium-texture resolution, no anti- • aliasing, no shadows High - realtime lighting, medium beam quality, high-texture resolution, anti-aliasing, •...
  • Page 496 Toggles animation while moving between camera presets. Animate Pan/Tilt Movement Toggles animation of automated fixtures. Also available in Toolbar > Focus. Fixture Labels Toggles labels over the fixture body for all, automated, selected, and / or active fixtures. Also available in Toolbar > Labels. Ion Classic User Manual...
  • Page 497 Beam Center Labels Toggles labels in the center of the simulated beam for all, automated, selected, and / or active fixtures. Also available in Toolbar > Labels. Focus Handles Toggles beam-end handles for all, automated, selected, and / or active fixtures, and text labels for each handle.
  • Page 498 Include Types (Fixture, Group, Model, FPE Calibration Point, Label, Dynamic, • Reference Point) - toggling any combination of these options will include all objects of that type in the folder. Dynamic objects (currently Pipes, Trusses, and Curtains) proportionally adjust to • scaling. Ion Classic User Manual...
  • Page 499 Include Names - includes all objects of a specific name in the folder. • Include Tags - includes all objects with a specific tag in the folder. • Refining Query Folders You can further refine the Names and Tags options using wildcards. An asterisk (*) will replace multiple characters, and a question mark (?) will replace single characters.
  • Page 500 Selective Focus - object is used as the point for click-to-focus. If CTRL is held while • clicking, the object is ignored. Rotation These icons rotate the selected object counterclockwise (CCW / left) or clockwise (CW / right) about the X, Y, and Z axes respectively. Ion Classic User Manual...
  • Page 501 Move to Ground Plane Aligns the selected object with the ground plane of the Augment3d model. Position, Rotation, & Scale Allows you to manually enter the position, rotation, and scale data for the selected object. Values can be adjusted by typing in the corresponding box, or by dragging left or right on the box labels.

  • Page 502: Augment3D Toolbar

    Positions the camera from the point of view (POV) of the gate of the first selected fixture. Exiting POV mode returns the camera to its previous position. When enabled, a Fixture POV symbol will overlay the Camera icon. Also available in Preferences. Ion Classic User Manual...
  • Page 503 Mode Toggles between Perspective and Orthographic camera modes. In Perspective mode, objects that are further away are smaller than nearby objects. In Orthographic mode, all objects are the same scale. Also available in Preferences. Move Toggles between Fly and Orbit camera modes. In Fly mode (indicated by a Fly symbol overlaying the Camera icon), the mouse alters the angle of the camera.
  • Page 504 Toggles between no, low, medium, and high overall ambient light levels in the Augment3d model. Options Tool Pending Cue Mode This mode allows Augment3d to display a virtual preview of the look used in the next upcoming cue. Ion Classic User Manual...
  • Page 505 Reset Cue Preview by clicking Cue Preview Mode Defaults. An eye will appear on the Options icon when in Cue Preview mode. Also available in Preferences. Quality Allows you to adjust the quality of the Augment3d render, the Refresh Rate, and the Lighting mode.
  • Page 506 High - 25 FPS and higher • Medium - 20 to 24 FPS • - 15 to 19 FPS • Very Low - 10 to 14 FPS • Poor - 10 FPS and lower • Ion Classic User Manual...

  • Page 507: Fixtures In Augment3D

    Fixtures in Augment3d Fixtures must be patched in Eos and then added to an Augment3d model before they can be displayed and controlled. Adding Fixtures Manually If fixture position and orientation data is already known, fixtures can be manually added via the Augment3d tab in the Eos Patch screen.
  • Page 508 The above left example shows the default orientation of 0/0/0, or pointing straight down. The center shows a rotation of 180° about the X axis, pointing the fixture straight up. The final example shows a rotation of 90° about the Y axis, pointing the fixture to the side. Ion Classic User Manual...
  • Page 509 Adding Fixtures Manually Under the Augment3d section in Patch, fixtures have fields for XYZ Position and Orientation. If the fixture is nested, this data is relative to the parent. World Position and Orientation are absolute, relative to the scene overall. If nested, an arrow indicator will apear next to the position and orientation fields.
  • Page 510 The fixtures will light up to indicate their selection. Note: You do not need to enter Augment3d Edit Mode to select fixtures. 3. Aim the fixtures at their intended target using a long selection, or SHIFT + left mouse. Ion Classic User Manual...
  • Page 511 Fixture Position Estimation (FPE) Eos can automatically configure the location and orientation of automated fixtures in Augment3d using a process called Fixture Position Estimation (FPE). Setting Up FPE FPE associates four or more points in your space with corresponding Focus Palettes in order to estimate the location and rotation of your automated fixtures.
  • Page 512 Selective FPE With nothing selected in the command line, FPE will recalculate positions for all patched fixtures in a show file. If specific fixtures or ranges of fixtures are selected, the FPE calculation will only affect the selection. Ion Classic User Manual...
  • Page 513 Troubleshooting FPE Accuracy There are several ways to calculate the positions and rotations of the fixtures in your show. There are several factors that can also impact the accuracy of this estimation, including: Fixture profile inaccuracy • Poor FPE point selection •...
  • Page 514 Ensure the measured ground points in your space match how they were entered in Eos, • and that the X and Y coordinates were not accidentally swapped. Verify you are using the correct units of measurement. • Ion Classic User Manual...
  • Page 515 (see Note: If you correct inaccuracies in a fixture profile, please report the necessary updates via the ETC Augment3d forums at community.etcconnect.com. When possible, please include a copy of the fixture manual . Pan / Tilt Inversion If a fixture in Augment3d pans and / or tilts in the opposite direction as it does in the real world, either parameter may be inverted.
  • Page 516 Using About (on page 413) , find the raw DMX values for pan (including course and fine), and note them. d. Set this new raw DMX level as your pan DMX home value in the Fixture Editor (on page 183) Ion Classic User Manual...
  • Page 517 2. Then, using the new DMX home value, calculate the maximum. a. Set your pan value to the minimum DMX value (likely 0) and select a tilt value that targets a point in your venue. b. Increase your pan value 360° until the fixture is pointing at the same point again and note this DMX value as your found pan value.
  • Page 518 Unless a custom profile is created that matches the specifications of the fixture, it will not work correctly with FPE. For more information, see Creating a New Fixture (on page 184) Ion Classic User Manual...
  • Page 519 Working with Fixtures Once fixtures are added to your model, you can begin using Augment3d to focus and control them. There are a variety of tools available to help with this. Fixture Selection & Focus Selecting Fixtures To select fixtures in Augment3d, either select them via the Eos command line or use a mouse. Click on a fixture to select it.

  • Page 520: Augment3D With Magic Sheets & Pixel Maps

    Specify the pixel map number and any X/Y/Z constraints. Select {Confirm} to place fixtures in your show at the same locations they exist in the pixel map. Create Pixel Map From Channel Locations This option allows you to use your existing Augment3d fixture locations to create a pixel map. Ion Classic User Manual...
  • Page 521 Specify the camera direction that the fixture locations will be pulled from and a pixel map number. Select {Confirm} to create a pixel map with fixtures at the same locations they exist in the Augment3d model. Note: This option is governed by fixture selection. If no fixtures are selected, all fixtures in the Augment3d model will be added to the pixel map.

  • Page 522: Augment3D Objects

    Select the Move tool. Drag on any of the X/Y/Z axes to move the object in that direction. Objects that have been moved away from their 0,0,0 default position will display a trail and distance measurement back to the Origin. Ion Classic User Manual...
  • Page 523 You may wish to change the visibility and position of Augment3d objects using cues, submasters, and so on. Two new profiles are available in Patch in order to accomplish this, under {Type} > {Manufctr} > {ETC Fixtures} > {Scenic Element}. Scenic Element Objects nested to a channel and patched as Scenic Element can be given intensity values to show or hide them on a cue-by-cue basis.
  • Page 524 Augment3d. Scale Select the desired units to use for the size of the object being imported. Origin Position Determines the position of the object relative to the origin when added to the model from the Library. Ion Classic User Manual...
  • Page 525 As Model - the object will be placed using the origin point defined in the object model. • Center - the object will be centered on the origin. • Ground - the object's base will be aligned with the origin. •...

  • Page 526: Vectorworks Augment3D Plug-In

    This installation guide provides information on the installation and setup of the Augment3d Plug-in for Vectorworks 2019-2022, intended for use with Eos v3.0.0 and later. This is an ETC-made plug-in for the Vectorworks program intended to export fixtures from Vectorworks for import into Augment3d.
  • Page 527 2. Configure your Vectorworks workspace. a. Open the Workspace Editor. Navigate to Tools > Workspaces > Edit Current Workspace. b. Expand the ETC node in the Commands panel: c. Drag "Export to ETC Augment3d" to the Spotlight node. d. Select {OK} to close the Workspace Editor.
  • Page 528 Select Edit Visualizer Data Mapping. Recommended mapping below: b. Select {OK} to close the Data Mapping window. 4. Navigate to Spotlight > Export to ETC Augment3d and follow the prompt. Vectorworks will export a .a3d file containing your information for import into Augment3d.
  • Page 529 6. When complete, click {Done}, then {OK}.Your devices and their associated position information will now appear in Patch and Augment3d. Options The following options are available before import: Starting / Ending Channel - defines a specific range of channels to be imported •...
  • Page 530 Ion Classic User Manual...

  • Page 531: Virtual Media Server

    Chapter 27 Virtual Media Server About Virtual Media Server Media Content Exporting Media Content Setting Up Pixel Maps Setting Pixel Map Features Working with the Virtual Media Server Effect Layers Pixel Mapping in a Multi-Console System Virtual Media Server...

  • Page 532: About Virtual Media Server

    .gif • .jpg • .png • .svg • .tiff • Video The following video formats are recommended: .gif • .mov (.H264 encoding) • .mp4 • For a full list of supported video formats, please consult etcconnect.com. Ion Classic User Manual...
  • Page 533 HTML & Text .htm • .html • .txt • Using Import All Pixel Map Media To import go to Browser>File>Import> Pixel Map Media>All Pixel Map Media and select the device with the media on it. Options in this display include: {Library (1-255)} - selects the library to import media. •...

  • Page 534: Exporting Media Content

    This is an automatic method of exporting all the media used in the current show file. This includes any pixel map media stored in cues, presets, submasters, etc. To export, go to Browser>File>Export>Show Pixel Map Media. Select the device you want to export the media content to.

  • Page 535: Setting Pixel Map Features

    If you prefer to assign Pixel Map layers in Patch first, profiles are available under {Type} > {Manufctr} > {ETC Fixtures} > {Virtual}. Note: No addresses need to be assigned in Patch for the pixel map layers.

  • Page 536: Working With The Virtual Media Server

    Let Layers Play - media continues playing with 0 intensity • {Scale} - adjusts scale of all layers. • {Aspect Ratio} - adjusts aspect ratio of all layers. • {XYZ Rotation Controls} - rotation control for all layers • Ion Classic User Manual...
  • Page 537 Layer Channel Controls When working with the Layer Channels, the following controls will be available: {Intensity} • {Pan} and {Tilt} - used to adjust the image of the individual layer within the frame. • {Color} - filters the color of the content. For example, if all the colors are set to full, the •...
  • Page 538 {Atop} layer and then blended with bottom layer Top and bottom layers color and {Add} opacity added together Top and bottom layers color and {Subtract} opacity subtracted from each other Ion Classic User Manual...
  • Page 539 Mode Description Result Top and bottom layers color and {Multiply} opacity multiplied together Top and bottom layers colors inverted {Screen} and then multiplied together Does a multiply or screen effect based {Overlay} on the lightness or darkness of the bottom layer Top layer’s color merges with bottom {Lighten}...
  • Page 540 {Aspect Ratio} - stretches or shrinks the content only along the X axis, making it wide or • squished looking. Z Rotate can be used to modify the aspect ratio along the Y axis. {XYZ Rotation Controls} - rotation control for all layers. • Ion Classic User Manual...

  • Page 541: Effect Layers

    Effect Layers The Virtual Media Server allows you to use procedurally generated content. This is content that is created algorithmically in real time, instead of rendering file based media. In order to use procedurally generated content, you must patch the pixel map layer as a virtual effect layer instead of a virtual media layer.

  • Page 542: Pixel Mapping In A Multi-Console System

    For clients, synchronizing the media is optional but useful if you wish to see the media playing back in the Pixel Map Preview display. Ion Classic User Manual...
  • Page 543 Steps for Configuring a Multi-Console System Once the Eos Family Pixel Mapping Installer has been installed on all consoles, follow these steps to configure your multi-console system: Setting up the Primary 1. On the primary console, exit to the Eos Configuration Utility (ECU). 2.
  • Page 544 5. A progress bar will appear to indicate the status of the import process. When finished, click {Done}. You will now be able to see the media playing in the Pixel Map Preview display on the backup and / or clients. Ion Classic User Manual...

  • Page 545: Partitioned Control

    Chapter 28 Partitioned Control About Partitioned Control How to Use Partitions Setting Up Partitioned Control Partition List Creating New Partitions Deleting Partitions Using Partitions Partitions in Playback Partitions on Cue Lists Flexichannel in Partitioned Control Partitioned Control...

  • Page 546: About Partitioned Control

    This will create a new partition, highlight it in the list, and (if partition is enabled) assign it as your partition. To assign channels to that partition, enter them in the command line: [1] [Thru] [9] [6] [Enter] • Ion Classic User Manual...

  • Page 547: Deleting Partitions

    You can also use [+], [-], and [Group] to further modify the channels in the partition. When adding/ subtracting channels to a partition, if you do not use [+] or [-] before channel numbers, the numbers will replace the channels in the partition, rather than adding to or subtracting from them.

  • Page 548: Flexichannel In Partitioned Control

    This mode may be further modified by use of the remaining flexi states. See Using Flexichannel (on page 104) Flexichannel Views in Patch (on page 157) for more information. Ion Classic User Manual...

  • Page 549: Multi-Console

    Chapter 29 Multi-Console About Multi-Console Multi-Console Terms Multi-console Setup Synchronized Backup Mirror Mode Multi-Console...

  • Page 550: About Multi-Console

    Dongles are also provided as external USB keys for use with ETCnomad systems. Multi-console Setup When using multiple Eos devices on the network, you should adjust some of the settings to ensure optimal functionality. Additional requirements for multi-console setup include: Ion Classic User Manual...
  • Page 551 Software versions must match exactly between all devices. • All devices have to use the same fixture library. See Update Profile (on page 183) • Language (on page 548) The language settings in the ECU must match. See • The keyboard language setting in the ECU must match. See Keyboard (on page 548) •...
  • Page 552 Devices sharing User IDs will share certain data, while those with different IDs will not. Below are the differences in multi-console data depending on User ID. Data shared between Eos Family devices with the same User ID command line • null channels in live • selected channels • filters • Ion Classic User Manual...

  • Page 553: Synchronized Backup

    selected cue • live/ blind mode • Setup>User • Data specific to the Eos Family device, regardless of User ID current fader page • current encoder page • focus on displays without command line • display configuration (layout, format, visible parameters, flexichannel) •...
  • Page 554 Two consoles can be used to provide backup. Either can be configured as the primary or the backup. If the primary console fails, the second console will take control with full show data intact. This is a useful scenario for touring multi-user applications. Ion Classic User Manual...

  • Page 555: Mirror Mode

    RPU and console One RPU and one console can be used as a backup option. In this configuration, it is recommended that you set the RPU as the primary and the console as the backup. In this scenario, should the RPU go offline, you will still have the full functionality of the console user- interface at your disposal.
  • Page 556 When left unlocked, the CIA will expand and close as normal. Not all CIA displays shown on the device in mirror mode. The following CIA displays are synchronized: About • Effects • Effects Status • Color Picker • Curves • Undo • Ion Classic User Manual...
  • Page 557 The CIA can be completely hidden when locked by pressing the [Displays] key. Pressing [Displays] again will display and unlock the CIA. Exiting Mirror Mode Exiting mirror mode can be done by selecting {Stop Mirroring} in the mirror display or using the keyboard shortcut ALT + F2.
  • Page 558 Ion Classic User Manual...

  • Page 559: Eos Configuration Utility

    Chapter 30 Eos Configuration Utility About the Eos Configuration Utility ECU Welcome Screen Settings > General Settings > Network Settings > Maintenance Buttons Eos Configuration Utility...

  • Page 560: About The Eos Configuration Utility

    When the primary remains in control, the backup will behave as a client would. For more information on backup systems, see About Multi-Console (on page 536) Client Assigns the console as a client to a console in primary mode. Ion Classic User Manual...

  • Page 561: Settings > General

    Setup > System > Outputs. Click on {Output in Client Mode} to enable the ability to output. CAUTION: ETC does not recommend the use of wireless networking for show critical functions. Mirror Client mode requires a dongle. When a dongle is not detected, the option to connect in mirror mode becomes available instead.
  • Page 562 When unchecked, the console will boot into the mode in which it was last used in (i.e. Backup, Client, Primary). Automatically Update Software When this is checked, the console will receive software updates from the primary if used in a multi-console system. Ion Classic User Manual...
  • Page 563 Windows format. If you decide to change this setting, it is recommended that you keep this location on the D: drive. The {Restore Default} buttons will return a changed location to the ETC default. Share Show / Media / Model Archive Enables you to share the show, media, or Augment3d model archive folders on the console with another console via Windows File Sharing (SMB).
  • Page 564 {Elo Monitor Settings} - opens the properties window for the monitor. See • External Touch Screen} (above) Settings {ETC Monitor Settings} - opens the properties window for the monitor. See • > General (on page 547) Note: Only supported options will display. Monitor options may vary. While it is possible to assign a resolution lower than the minimum (1920x1080), it is recommended to be at 1920x1080 or higher.
  • Page 565 On new consoles, some versions are preselected to be archived when initially shipped from ETC. This includes the version of software that is currently installed from the factory as well as any patches to that version (if available). For future releases, you will need to download the Eos Family software from the ETC website, etcconnect.com.

  • Page 566: Settings > Network

    On ETCnomad, these settings pull from the Windows or macOS operating system, and cannot be edited here. Note: The number of ports varies depending on how many Network Interface Controllers (NICs) your console has. For more information, refer to the Console Overview (on page 11) chapter. Ion Classic User Manual...
  • Page 567 Obtain an IP Automatically Note: ETC recommends the use of a static IP address for compatibility with other ETC devices, though the needs of your particular installation may vary. Clicking in the enable box will set the console to get its IP address dynamically from a DHCP server.
  • Page 568 • {Cancel} - remains in start-up without launching into the Eos application. • {Disable All ETC Protocols} CAUTION: This button will uncheck all boxes for currently-enabled output, interface, DHCP, and SNTP protocols for the selected network port. Ion Classic User Manual...
  • Page 569 CAUTION: This button will restore all network settings on the selected port to their ETC defaults. This includes factory-default IP addresses and settings. Remote Startup / Shutdown It is possible to remotely power on and off some Eos devices, such as RVIs, RPUs, and client consoles.
  • Page 570 Limited Broadcast - The limited broadcast address is 255.255.255.255. It is limited • because routers will never forward datagrams with that destination address. This means that datagrams with the limited broadcast address are confined to the particular network segment on which they originate. Ion Classic User Manual...
  • Page 571 Backup Takes Over At Higher Priority This enables the backup device in a multi-console system to take over at one priority higher than the primary if the primary goes offline. Backup Automatically Takes Control Switches to the backup automatically if the primary should go offline. Allowed Output Addresses A range or ranges of addresses that can be assigned to limit the number of output addresses.
  • Page 572 500 means it will give out IP addresses to the first 500 devices that ask for an IP address. Subnet Mask - This sets the logical network size vs. the device address. ETC’s default is • 255.255.000.000 (class B). This is the subnet mask that the DHCP server will give to network devices.

  • Page 573: Settings > Maintenance

    When configured as a server, a console will serve out time to other devices on the network. ETC Net2 Time - With ETC Net2 Time enabled, the time server will periodically broadcast • (as a server) or receive (as a client) the current time, which is required by devices running the ETCNet2 protocol, for example, Legacy Unison systems.
  • Page 574 USB drive. If you experience software problems with your system that we are unable to reproduce, Help from ETC Technical Services (on sending these log files to ETC Technical Services (see page 3) ) can help us isolate the issue.
  • Page 575 The file manager display will show the ShowArchive folder on your console as well as any external USB drives that are detected. The display is split into two windows, so you can see two different folders at the same time for copying or moving data between them. {Gateway Configuration Editor (GCE)...} Launches the GCE software.
  • Page 576 This includes devices that do not currently need to be updated. If the button is grayed out, the device can not be updated using this window. Note: Windows 7 consoles must be power-cycled after a firmware update. This is not necessary for consoles running Windows 10. Ion Classic User Manual...

  • Page 577: Buttons

    Buttons RPU Face Panel Buttons This area is for configuring the buttons on the front of a RPU or RVI. Clicking on a button will open a dialog window for selecting what type of button, macro, hardkey, or none, you wish to assign.
  • Page 578 Ion Classic User Manual...

  • Page 579: Show Control

    Chapter 31 Show Control About Eos Family Show Control Show Control Settings Show Control Display Time Code Real Time Clock (RTC) Analog Inputs sACN Input MIDI Show Control String Interface MIDI Raw Open Sound Control (OSC) Eos Family Show Control Capabilities Advanced OSC Eos OSC Keys Show Control...

  • Page 580: About Eos Family Show Control

    Most protocols that are received need to be configured in a Show Control list in the show control display. These include MTC, SMPTE, Analog Inputs, RTC, MIDI Notes, Serial Strings, and sACN Input. The Show Control list is accessed by pressing [Displays]>{Show Control}. See Show Control Display for more information. Ion Classic User Manual...

  • Page 581: Show Control Settings

    Show Control Settings In [Setup] > {System} > {Show Control}, you can adjust settings for MIDI Show Control, time code (MIDI or SMPTE), analog, and serial functions. See Show Control (on page 202) Port Setup Options Eos Ti, Gio, Eos RPU3, Gio @5, Ion Xe, Element 2, Ion, Ion RPU, Element, and Eos Programming Wing have additional ports and connectors located on the rear panel for show control.
  • Page 582 Interface Protocols Additional settings are found in the ECU>Settings>Network. Open Sound Control (OSC) for more information. Ion Classic User Manual...

  • Page 583: Show Control Display

    Show Control Display The Show Control Display allows for the creation of event lists, which are comprised of events. An event list defines how incoming show control events are processed by the console – any protocol that can be received by the console is handled here. Each event list is assigned a type of show control (time code, analog inputs, RTC, or network).
  • Page 584 Gateway, or the built-in ports (when available). Internal - enables the list to use internal timing sources. See Internal vs. External Time • Internal vs. External Time External - enables the list to use external timing sources. See • Ion Classic User Manual...
  • Page 585 First Time - sets the first time that the console will use when using internal timing. • Last Time - sets the last time that the console will use when using internal timing. • FPS - sets how many frames per second (FPS) will be used; 30, 25, 24. •...

  • Page 586: Time Code

    Gray - No timecode is being received from internal or external sources. • Time Code Indicator You will see an indicator in the upper portion of the main display if valid internal or external time is seen. Ion Classic User Manual...
  • Page 587 Select the indicator to see a dropdown menu of all active time code sources. The menu shows the List number, list label (if any), current time (if any), a symbol for MIDI/SMPTE, subscript for framerate, and the list group ID. Selecting {Show Last Active Source} will display the last active time code source in the upper portion of the main display after the dropdown is closed.
  • Page 588 <Event> [1] [/] [Enter] • Specify a new event number. <Event> [1] [Enter] • Add the action that the event should execute. <Event> <1> [Cue] [1] [Enter] • Define the time code position of the event. Ion Classic User Manual...
  • Page 589 <Event> <1> [Time] [2][0][1][5] [Enter] • It is possible to enter multiple commands in the same command line. This can speed up your programming. <Event> [2] [Cue] [1.5] [Time] [2][4][1][3] [Enter] • Event timing can also be modified within a range. Let's say an additional 5 frames needs to be added to multiple events.
  • Page 590 Silent Mode When a time code list is in silent mode, its clock can run without firing its events. This can be useful when learning event without firing exisiting events. Ion Classic User Manual...

  • Page 591: Real Time Clock (Rtc)

    Real Time Clock (RTC) Eos Family consoles have the ability to run Real Time Clock (RTC) events. RTC events are used to run a cue, submaster, or macro at a specific time on specific days. RTC events can run at a certain time of day, like 5:00pm on Tuesdays, a certain date, or at a time based off of astronomical events, such as sunrise and sunset.
  • Page 592 <Event> [1] {Date} [2] [1] {Month} [1] [0] {Year} [2] [0] [1] [5] [Enter] - sets the date to • October 21, 2015. Creating the action for each event is the same as time code. Select the event and specify either cue, submaster, or macro. <Event> [1] [Cue] [1][2] [Enter] • Ion Classic User Manual...

  • Page 593: Analog Inputs

    Analog Inputs Eos Family consoles can accept analog input through a variety of interfaces. 0-10VDC inputs are received through a Net3 I/O Gateway. Contact closures can be received through the built- in remote trigger port on the console (when available) and through a Net3 I/O Gateway. The I/O Gateway can be set up through the Net3 Concert software.
  • Page 594 Create an event where an input on address 5 will set Sub 1 back Off. Analog input: <Event> [4] [/] [1] {Address} [5] [Sub] [1] {Off} [Enter] • sACN input: <Event> [4] [/] [1] {sACN} [5] [Sub] [1] {Off} [Enter] • Ion Classic User Manual...
  • Page 595 Bump Acts as if the input is directly controlling the bump button. If the submaster is set to have a dwell time of Man (manual), then it will instantly flash and turn back off. It is generally recommended to set the submaster to have a dwell time of Hold or a specified time. The first trigger will turn the submaster On.
  • Page 596 Group ID of the I/O Gateway or built-in relay output and the 2 is the relay output address. Note: You enter relay information in the live or blind displays. This is not a Show Control display function. Ion Classic User Manual...

  • Page 597: Sacn Input

    sACN Input Eos Family consoles can receive streaming sACN level information from itself and other devices on the lighting control network. Similar to Analog Inputs, these received sACN input levels can then be used in Show Control events to execute certain actions. sACN allows for multiple sources to be present on the network.
  • Page 598 <Event> [2] [Enter] • Assign the sACN address using universe/address format {sACN} [4] [/] [2] [Enter] • Add the action to execute. Actions can be either a cue, submaster, or macro {Action} {Sub} [1] {Fader} [Enter] • Ion Classic User Manual...

  • Page 599: Midi Show Control

    MIDI Show Control Eos Family consoles can receive MIDI Show Control (MSC) data from Net3 Show Control Gateways and the built-in MIDI ports on a console or programming wing (when available). There can be up to 32 sources, and these sources can be assigned Group IDs between 1 and 32.
  • Page 600 MIDI messages. Fire This command fires a macro. MSC supports macros 1 through 127 only. Therefore a numeric value of 1 through 127 followed by 00 (in hex) would accompany this command. Ion Classic User Manual...
  • Page 601 Sending MIDI Show Control Show Control Settings When MSC Transmit is enabled in Setup (see ), the console will send MIDI Show Control commands to the specified MSC Transmit Channel (or Device ID) that correspond to the console’s current action. For example, if Cue 1 in List 2 is executed, the console will send a MSC Go command for Cue 1 List 2. ...
  • Page 602 F0 7F 03 02 01 06 04 00 00 00 7F As a second example, sending Device ID 10 a SET command for the playback master “up” fader to 100% would be formatted as follows: F0 7F 0A 02 01 06 00 01 00 64 7F Ion Classic User Manual...
  • Page 603 Firing Macros Macros are relatively simple. Only macros 1-127 can be triggered, represented by one hexadecimal byte. Eos - Macro 12 • MSC Formatted - 0C • For example, sending Device ID 5 a FIRE command for macro 17 would be formatted as follows: F0 7F 05 02 01 07 11 F7 Show Control...

  • Page 604: String Interface

    It is best practice to place spaces after both the <UX> and the $ symbol to ensure the command is interpreted properly. Note: Command line text needs to use the same language as your console. Language settings are found in ECU>General. Ion Classic User Manual...
  • Page 605 Event Handler (Non-Command Line) All other text that doesn’t start with a “$” will be sent to the console’s event handler. Here are a few examples: Go 1 - fire cue list 1 • Cue 1 2 - run cue 2 from list 1, on the appropriate fader •...
  • Page 606 [Displays]><More SK>>{Show Control} or [Tab] + [1][1] • Create a new event list. <Event> [9] [/] [Enter] • Specify the event list as Network. <Event> [9] [/] {Type} {Network} [Enter] • Enable the list (External only). Ion Classic User Manual...
  • Page 607 <Event> [9] [/] {External} [Enter] • Select Input String and type the appropriate UDP or OSC command {Input String} Hello [Enter] • Example: Type in the command you want the console to listen for. The sending device needs to start the command with /eos/sc/ in order •...
  • Page 608 • Cue 1/2 is triggered. The console will send Cue 1 2. • A cue is stopped. • Cue 3/1 is stopped. The console will send Stop Cue 3 1. • A cue is resumed. • Ion Classic User Manual...
  • Page 609 Cue 3/1 is resumed. The console will send Resume Cue 3 1. • A sub’s bump button is held down. • Sub 5’s bump button is pressed down. The console will send SubDown 5. • A sub’s bump button is released. •...

  • Page 610: Midi Raw

    {OK} to store the event. Otherwise, press {Cancel} to undo the changes. Message Structure Note On has a structure of 9A CC DD, where 9 represents the Note On command, A represents the channel number, CC represents the note value, and DD represents the velocity. Ion Classic User Manual...
  • Page 611 Note Off has a structure of 8A CC DD, where 8 represents the Note Off command, A represents the channel number, CC represents the note value, and DD represents the velocity. Options The following options are available: {Note} You can choose any musical note name (C-B, chromatic), or use Raw MIDI to manually enter a value.
  • Page 612 Otherwise, press {Cancel} to undo the changes. Message Structure Program change messages have the structure BN XX YYY, where N represents the MIDI channel number, XX represents the controller number, and YY represents the data byte. Ion Classic User Manual...
  • Page 613 Options The following options are available: {Channel} This should match the MIDI Channel for the note command (1-16, 0-F). If set to Any, the console will respond when any MIDI channel is sent a note command. {Controller Number} The controller number is any value between 0-127 (00-7F). Many devices will display this as 1- 128 –...
  • Page 614 Optionally, select the velocity threshold so that the event will be triggered if the message is above this level. To disable velocity threshold, leave it at zero. <Velocity Threshold> {0} • Press {OK} to save the event {OK} • Specify the action for the event <Event> [1] [Macro] [1] [Enter] • Ion Classic User Manual...
  • Page 615 Creating a Note Off Event Create a new event and open the MIDI String configuration screen <Event> [2] [More SK] {MIDI String} • Select the {Note Off} type {Note Off} • Select the MIDI Note value, for example, Bb (B-flat) {A#/Bb} •...
  • Page 616 [Cue] [1] {Execute} {MIDI Raw} 91 3C 7F [Enter] • Decimal Format Select a cue or sub. [Sub] [1] • Press the {Execute} softkey. [Sub] [1] {Execute} • New softkeys will appear, press the {MIDI Raw} softkey. Ion Classic User Manual...
  • Page 617 [Sub] [1] {Execute} {MIDI Raw} • Define the MIDI string, in this case we will use decimal to send the same command as before - a Note On command for note C3 to channel 1 with a velocity of 127. [Sub] [1] {Execute} {MIDI Raw} D 145 60 127 [Enter] •...

  • Page 618: Open Sound Control (Osc)

    For OSC commands that are intended to be processed by the Show Control display, the sending device needs to start the string with /eos/sc/ in order for the console to correctly process it. Example: /eos/sc/Hello – sends the string “Hello” to the show control display via • Ion Classic User Manual...
  • Page 619 When using UDP, the appropriate IP address and ports must be configured in the Show Control section of Setup. For systems without specific networking requirements, ETC recommends UDP port assignments in the range 4703 to 4727 or 8000 and 8001.
  • Page 620 /eos/chan/<number>/home /eos/chan/1/home 1.0=down, 0.0=up (optional) number for button edge: /eos/chan/<number>/remdim /eos/chan/1/remdim 1.0=down, 0.0=up (optional) number for button edge: /eos/chan/<number>/level /eos/chan/1/level 1.0=down, 0.0=up (optional) number for button edge: /eos/chan/<number>/full /eos/chan/1/full 1.0=down, 0.0=up (optional) Ion Classic User Manual...
  • Page 621 OSC Method Arguments Examples/Comments number for button edge: /eos/chan/<number>/min /eos/chan/1/min 1.0=down, 0.0=up (optional) number for button edge: /eos/chan/<number>/max /eos/chan/1/max 1.0=down, 0.0=up (optional) number for button edge: /eos/chan/<number>/+% /eos/chan/1/+% 1.0=down, 0.0=up (optional) number for button edge: /eos/chan/<number>/-% /eos/chan/1/-% 1.0=down, 0.0=up (optional) Set parameter or DMX information /eos/chan/<number>/dmx number for channel DMX level /eos/chan/1/dmx=255...
  • Page 622 /eos/param/<parameter>/max edge 1.0=down, 0.0=up /eos/param/pan/max (optional) number for the button /eos/param/<parameter>/+% edge 1.0=down, 0.0=up /eos/param/pan/+% (optional) number for the button /eos/param/<parameter>/-% edge 1.0=down, 0.0=up /eos/param/pan/-% (optional) number for all parameter /eos/param/pan/tilt=45 (set /eos/param/<parameter 1>/ Ion Classic User Manual...
  • Page 623 OSC Method Arguments Examples/Comments pan & tilt to 45) levels <parameter 2> multiple numbers for each /eos/param/pan/tilt=45,90 parameter level (set pan to 45 & tilt to 90) OSC Color OSC Method Arguments Examples/Comments Argument 1: Hue (0.0- /eos/color/hs=330.0, 75.0 (pink color with 75% /eos/color/hs 360.0) Argument 2: saturation)
  • Page 624 /eos/wheel/fine/<parameter 1>/ ticks (positive or /eos/wheel/fine/pan/tilt=1.0 <parameter 2>/... negative) number for coarse /eos/wheel/course/<parameter> wheel ticks (positive or /eos/wheel/coarse/pan=1.0 nega tive) /eos/wheel/course/<parameter number for coarse 1>/ wheel ticks (positive or /eos/wheel/coarse/pan/ tilt=1.0 negative) <parameter 2>/... Ion Classic User Manual...
  • Page 625 OSC Switch Note: Switch is a variant of Wheel with the added functionality of continuously repeating wheel ticks until a subsequent OSC switch command sets the wheel ticks to zero.This may be used to continuously tick a wheel while a button is held down, for example.
  • Page 626 /eos/out/active/wheel/1=”Intensity”, /eos/out/active/wheel<number> name and current value from first channel OSC Subscribe to Specific Parameters Once subscribed, Eos will reply with an OSC packet per parameter as they change. For example: /eos/out/param/pan • Ion Classic User Manual...
  • Page 627 Implicit OSC Output (on page 624) for more information. OSC Method Arguments Examples/Comments 1=subscribe, /eos/subscribe/param/<parameter> /eos/subscribe/param/red=1 0=unsubscribe /eos/subscribe/param/<parameter 1=subscribe, /eos/subscribe/param/pan/tilt=1 1>/<parameter 2>/... 0=unsubscribe OSC Direct Selects OSC direct selects are virtual buttons and are mapped separately than direct selects visible on the console. To use direct selects, you must first send one of the direct select creation commands.
  • Page 628 Create an OSC fader bank with 10 faders per page /eos/fader/1/config/10 • OSC Fader 1/1 is the same as console fader 1/1. • OSC Fader 2/1 (Fader 11) is the same as console fader 2/1. • Ion Classic User Manual...
  • Page 629 Another example: Create an OSC fader bank with 5 faders per page /eos/fader/1/config/5 • OSC Fader 2/1 (Fader 6) is the same as console fader 1/6 (Fader 6) • OSC Fader 3/1 (Fader 11) is the same as console fader 2/1 (Fader 11) •...
  • Page 630 Set Levels (Parks address while on the OSC command line) number for level to set /eos/addr/513=100 (useful for /eos/addr/<address> address to (0-100) mapping to an OSC slider) number for DMX level to /eos/addr/513/dmx=255 (useful for /eos/addr/<address>/dmx set address to (0-255) mapping to an OSC slider) Ion Classic User Manual...
  • Page 631 OSC Magic Sheet OSC Method Arguments Examples/Comments /eos/ms number of the magic sheet to open /eos/ms=1 /eos/ms/<ms number of the magic sheet view to open /eos/ms/1=2 number> (optional) OSC Group Selects and controls channels in groups. Note: Same syntax and behavior as Channel. OSC Method Arguments Examples/Comments...
  • Page 632 /eos/sub/fire=1 /eos/sub/1/fire=1.0 (bump sub 1 on) number for button edge: /eos/sub/<number>/fire 1.0=down, 0.0=up (optional) /eos/sub/1/fire=0.0 (bump sub 1 off) OSC Preset OSC Method Arguments Examples/Comments Select Preset /eos/preset number of preset to select /eos/preset=1 Recall Preset Ion Classic User Manual...
  • Page 633 OSC Method Arguments Examples/Comments /eos/preset/fire number of preset to recall /eos/preset/fire=1 number for button edge: 1.0=down, /eos/preset/<number>/fire /eos/preset/1/fire 0.0=up (optional) OSC Intensity Palette OSC Method Arguments Examples/Comments Select Intensity Palette /eos/ip number of intensity palette to select /eos/ip=1 Recall Intensity Palette /eos/ip/fire number of intensity palette to recall /eos/ip/fire=1...
  • Page 634 1.0 complete String argument with /eos/out/active/cue/text= /eos/out/active/cue/text descriptive text about “1/1 Label 5.00 100%” active cue /eos/out/pending/cue/<list>/<cue> None /eos/out/pending/cue/5/1.5 String argument with /eos/out/pending/cue/<list>/<cue>/tex /eos/out/pending/cue/text= descriptive text about “1/1.5 Label 5.00” active cue Gets default cue /eos/get/setup times Ion Classic User Manual...
  • Page 635 OSC Cue List Banks Note: <index> is a 1-based index of any number of OSC cue list banks you wish to create. Eos will send the cue list label and cue information for all OSC cue list banks. Explicit OSC Output for more information.
  • Page 636 (set OSC user to match con- /eos/user number for OSC user ID sole) /eos/user=0 (set OSC user as background user) Implicit OSC Output (on page 624) Current User ID Output – see for more information /eos/out/user=1 number for current OSC user /eos/out/user Ion Classic User Manual...
  • Page 637 OSC Command Line Command line instructions can be sent directly. String substitution with arguments is also allowed. To add a substitution, add %1 (or %2, %3, etc…) where the number given is the argument number where the actual value should be found.
  • Page 638 String argument with current command line text OSC Settings OSC Method Arguments/Comments /eos/out/user Integer argument with current OSC user ID /eos/out/wheel Float argument with current OSC wheel mode: 0.0=Coarse, 1.0=Fine /eos/out/switch Float argument with current OSC wheel mode: 0.0=Coarse, 1.0=Fine Ion Classic User Manual...
  • Page 639 OSC Active Channels and Parameters OSC Method Arguments/Comments String argument with active channels and current value from the /eos/out/active/chan 1st channel String argument with parameter name and current value from /eos/out/active/wheel/<number> the 1st channel: 0=Null/Unassigned, 1=Intensity, 2=Focus, 3=Color, 4=Image, 5=Form, 6=Shutter Note: This allows you to create a ML Controls style interface via OSC.
  • Page 640 Integer argument: 0=Blind, 1=Live Note: When Eos receives the command “/eos/ping” it will reply with “/eos/out/ping”. You may optionally add any number of arguments and Eos will reply with the same arguments. This may be useful for testing latency. Ion Classic User Manual...

  • Page 641: Eos Family Show Control Capabilities

    Eos Family Show Control Capabilities Note: Net3 Show Control Gateway has been abbreviated to SC GW for this table. Hardware MIDI Show MIDI Time Device MIDI MIDI Notes SMPTE Code (MTC) Control (MSC) Connections Local Local Local Via SC In/Out Eos Titanium (Ti) Yes, In/Out GW In In Only Also...
  • Page 642 *Ion consoles that have a DVI splitter and any Ion RPU have a local RS-232 port that is not enabled.  For questions, please contact ETC Technical Services. See Help from ETC Technical Services (on page 3) to find the office closest to you.

  • Page 643: Advanced Osc

    Advanced OSC OSC List Convention The OSC List convention is used to send OSC commands that may exceed 512 bytes of data. To add an OSC List of items to an OSC Command, append the OSC Command Path with /list/<index>/<count>, where <index> is the zero-based index offset into the entire list and <total>...
  • Page 644 /eos/get/group/count • /eos/get/group/displayed/count • /eos/get/macro/count • /eos/get/sub/count • /eos/get/preset/count • /eos/get/ip/count (ip = Intensity Palette) • /eos/get/fp/count (fp = Focus Palette) • /eos/get/cp/count (cp = Color Palette) • /eos/get/bp/count (bp = Beam Palette) • /eos/get/curve/count • Ion Classic User Manual...
  • Page 645 /eos/get/fx/count (fx = Effect) • /eos/get/snap/count (snap = Snapshot) • /eos/get/pixmap/count • /eos/get/ms/count (ms = Magic Sheet) • /eos/get/3dserver/count • /eos/get/patch/<channel number>/<part number>/augment3d/position (returns index, • UUID, position x, position y, position z, orientation x, orientation y, orientation z, fpe set number) /eos/get/patch/<channel number>/<part number>/augment3d/beam (returns index, •...
  • Page 646 /eos/out/get/curve/<curve number>/list/<list index>/<list count> = <uint32: list index> • <string: UID> ... /eos/out/get/fx/<fx number>/list/<list index>/<list count> = <uint32: list index> • <string: UID> ... /eos/out/get/snap/<snap number>/list/<list index>/<list count> = <uint32: list index> • <string: UID> ... Ion Classic User Manual...
  • Page 647 /eos/out/get/pixmap/<pixmap number>/list/<list index>/<list count> = <uint32: list • index> <string: UID> ... /eos/out/get/ms/<ms number>/list/<list index>/<list count> = <uint32: list index> • <string: UID> ... /eos/out/get/3dserver/<3dserver number>/list/<list index>/<list count> = <uint32: list • index> <string: UID> ... /eos/out/get/patch/<channel number>/<part number>/augment3d/position = <uint32: •...
  • Page 648 However, you can use the following convenience commands for editing the most common show data attributes: /eos/set/patch/<channel number>/label = <string: text> (include part number in the • path when necessary) /eos/set/patch/<channel number>/text1 = <string: text> • /eos/set/patch/<channel number>/text2 = <string: text> • /eos/set/patch/<channel number>/text3 = <string: text> • Ion Classic User Manual...
  • Page 649 /eos/set/patch/<channel number>/text4 = <string: text> • /eos/set/patch/<channel number>/text5 = <string: text> • /eos/set/patch/<channel number>/text6 = <string: text> • /eos/set/patch/<channel number>/text7 = <string: text> • /eos/set/patch/<channel number>/text8 = <string: text> • /eos/set/patch/<channel number>/text9 = <string: text> • /eos/set/patch/<channel number>/text10 = <string: text> •...
  • Page 650 CUELIST (1 OF 2): /eos/out /get/cuelist/<cue list number>/list/<list index>/<list count> = <uint32: index> <string: OSC UID> <string: label> <string: playback mode> <string: fader mode> <bool: independent> <bool: HTP> <bool: assert> <bool: block> <bool: background> <bool: solo mode> Ion Classic User Manual...
  • Page 651 <uint32: timecode list> <bool: OOS sync> Example: /eos/out/get/cuelist/1/list/0/13 = 0, “00000000-0000-0000-0000- 000000000000”, “My Cue List One Label”, “Master”, “Proportional”, True, False, True, False, False, False, 1, False CUELIST (2 OF 2): /eos/out /get/cuelist/<cue list number>/links/list/<list index>/<list count> = <uint32: index> <string: OSC UID>...
  • Page 652 /eos/out/get/cue/1/1/0/fx/list/0/3 = 0, “00000000-0000-0000-0000- 000000000000”, “1-3” CUE (3 OF 4): /eos/out /get/cue/<cue list number>/<cue number>/<cue part number>/links/list/<list index>/<list count> = <uint32: index> <string: OSC UID> <OSC Number Range: linked cue lists list> Example: /eos/out/get/cue/1/1/0/links/list/0/3 = 0, “00000000-0000-0000-0000- 000000000000”, 2 Ion Classic User Manual...
  • Page 653 CUE (4 OF 4): /eos/out /get/cue/<cue list number>/<cue number>/<cue part number>/actions/list/<list index>/<list count> = <uint32: index> <string: OSC UID> <string: ext link action> Example: /eos/out/get/cue/1/1/0/actions/list/0/3 = 0, “00000000-0000-0000-0000- 000000000000”, “Chan 90 At Full” GROUP (1 OF 2): /eos/get/group/<group number>/list/<list index>/<list count> = <uint32: index>...
  • Page 654 False, True, False, “”, “0”, “Man”, “0” SUB (2 OF 2): /eos/get/sub/<sub number>/fx/list/<list index>/<list count> = <uint32: index> <string: OSC UID> <OSC Number Range: effect list> Example: /eos/out/get/sub/3/fx/list/0/3 = 0, “00000000-0000-0000-0000- 000000000000”, 10 PRESET (1 OF 4): /eos/get/preset/<preset number>/list/<list index>/<list count> = Ion Classic User Manual...
  • Page 655 <uint32: index> <string: OSC UID> <string: label> <bool: absolute> <bool: locked> Example: /eos/out/get/preset/10/list/0/5 = 0, “00000000-0000-0000-0000- 000000000000”, “My Preset Ten Label”, True, True PRESET (2 OF 4): /eos/get/preset/<preset number>/channels/list/<list index>/<list count> = <uint32: index> <string: OSC UID> <OSC Number Range: channel list> Example: /eos/out/get/preset/10/channels/list/0/3 = 0, “00000000-0000-0000-0000- 000000000000”, “1-5”...
  • Page 656 /eos/out/get/ip/1/byType/list/0/2 = 0, “00000000-0000-0000-0000- 000000000000” CURVE (1 OF 1): /eos/get/curve/<curve number>/list/<list index>/<list count> = <uint32: index> <string: OSC UID> <string: label> Example: /eos/out/get/curve/901/list/0/2 = 0, “00000000-0000-0000-0000- 000000000000”, “IES Square” EFFECT (1 OF 1): /eos/get/fx/<fx number>/list/<list index>/<list count> = Ion Classic User Manual...
  • Page 657 <uint32: index> <string: OSC UID> <string: label> <string: effect type> <string: entry> <string: exit> <string: duration> <uint32: scale> Example: /eos/out/get/fx/901/list/0/8 = 0, “00000000-0000-0000-0000- 000000000000”, “Circle”, “Focus”, “Immediate”, “Immediate”, “Infinite”, SNAPSHOT (1 OF 1): /eos/get/snap/<snap number>/list/<list index>/<list count> = <uint32: index> <string: OSC UID>...
  • Page 658 To verify that basic OSC communication is working, you may send the command /eos/ping and Eos will reply with /eos/out/ping.  You may also add any number of arguments to the command, for example, if you want to measure latency. Ion Classic User Manual...

  • Page 659: Eos Osc Keys

    Eos OSC Keys The following is a list of the supported key names for use with OSC: /eos/key/ Internal Eos Command CHAN_SUBGROUP_BEGIN CHAN_SUBGROUP_END PLUS MINUS POINT SLASH COLON PLUS10 MINUS10 100_channel_display 100_CHANNEL_DISPLAY _last SLOTLAST _next SLOTNEXT DIMMER_A about ABOUT absolute ABSOLUTE_EFFECT acn_device_disconnect ACN_DEVICE_DISCONNECT action...
  • Page 660 AUTOSAVE autosavetime AUTOSAVE_TIME avab/udp AVAB_INTERFACE axis AXIS DIMMER_B back BACK background BACKGROUND_FADER background_mode MACRO_BACKGROUND backspace BACKSPACE backtime BACK_TIME beam BEAM_CAT beam_palette BEAM_PALETTE before_sunrise RTC_BEFORE_SUNRISE before_sunset RTC_BEFORE_SUNSET blackout BLACKOUT_BUTTON blackout_enable BLACKOUT_ENABLE blind PREVIEW block BLOCK bounce BOUNCE Ion Classic User Manual...
  • Page 661 /eos/key/ Internal Eos Command break_nested BREAK_NESTED break_nested_off BREAK_NESTED_OFF build BUILD bump SC_BUMP bump_1 BUMP01 bump_10 BUMP10 bump_2 BUMP02 bump_3 BUMP03 bump_4 BUMP04 bump_5 BUMP05 bump_6 BUMP06 bump_7 BUMP07 bump_8 BUMP08 bump_9 BUMP09 by_type BY_TYPE_PALETTE calibrate CALIBRATE can't_be CANT_BE can_be CAN_BE cancel_command CANCEL capture...
  • Page 662 COLOR_SCRUB color_scrub_replay COLOR_SCRUB_REPLAY column_move_left COLUMN_MOVE_LEFT column_move_right COLUMN_MOVE_RIGHT column_resize_larger COLUMN_RESIZE_LARGER column_resize_smaller COLUMN_RESIZE_SMALLER command_history OPENCMDHISTORY commandline_on_psd CMDLNONPSD complete GOTO_CUE_COMPLETE confirm_command CONFIRMED continuous_run CONTINUOUS_RUN control CONTROL_CAT control_cat CONTROL_FILTER copy_to COPY_TO create_type NEW_EFFECT_TYPE create_virtual_hsb CREATE_VIRTUAL_HSB cue_beam_time SETUP_CUE_BEAM_TIME cue_color_time SETUP_CUE_COLOR_TIME Ion Classic User Manual...
  • Page 663 /eos/key/ Internal Eos Command cue_down_time SETUP_CUE_DOWN_TIME cue_focus_time SETUP_CUE_FOCUS_TIME cue_list SFF_CUELIST cue_sheet CUE_SHEET cue_up_time SETUP_CUE_UP_TIME cueonly Q_ONLY cueonlytrack CUE_ONLY_TRACK cues SFF_CUES curve CURVE curve_edit EDIT_CONTROL curves SFF_CURVES cycles NUM_CYCLES cycletime CYCLE_TIME data DATA data_mode_latch DATA_MODE_LATCH database_mode CIAPATCH_DB_MODE date RTC_DATE days RTC_DAYS decaytime EFFECT_STEP_OUT_TIME default...
  • Page 664 DURATION_NUM_CYCLES dwell DWELL earliest EARLIEST earliest_m EARLIEST_MARK_CUE edit EDIT edit_frame EDIT_FRAME edit_mode EDIT_MODE edit_target TARGET_EDIT_EVENT edmx EDMX effect EFFECT effect_axis_wheel EFFECT_AXIS_WHEEL effect_edit EFFECT_PATTERN_EDIT effect_form_horizontal_wheel EFFECT_FORM_HORIZONTAL_WHEEL effect_form_vertical_wheel EFFECT_FORM_VERTICAL_WHEEL effect_rate_wheel EFFECT_RATE_WHEEL effect_rotate_wheel EFFECT_ROTATE_WHEEL effect_scale_wheel EFFECT_SCALE_WHEEL effect_shape_horizontal_wheel EFFECT_SHAPE_HORIZONTAL_WHEEL Ion Classic User Manual...
  • Page 665 /eos/key/ Internal Eos Command effect_shape_vertical_wheel EFFECT_SHAPE_VERTICAL_WHEEL effect_size_wheel EFFECT_SIZE_WHEEL effect_time_wheel EFFECT_TIME_WHEEL effects SFF_EFFECTS effectsub EFFECT_SUB element_bump_1 ELEMENT_BUMP_1 element_bump_10 ELEMENT_BUMP_10 element_bump_11 ELEMENT_BUMP_11 element_bump_12 ELEMENT_BUMP_12 element_bump_13 ELEMENT_BUMP_13 element_bump_14 ELEMENT_BUMP_14 element_bump_15 ELEMENT_BUMP_15 element_bump_16 ELEMENT_BUMP_16 element_bump_17 ELEMENT_BUMP_17 element_bump_18 ELEMENT_BUMP_18 element_bump_19 ELEMENT_BUMP_19 element_bump_2 ELEMENT_BUMP_2 element_bump_20 ELEMENT_BUMP_20 element_bump_21 ELEMENT_BUMP_21 element_bump_22...
  • Page 666 ENCODER3 encoder_4 ENCODER4 encoder_5 ENCODER5 encoder_6 ENCODER6 encoder_category_color ENCODER_CAT_COLOR encoder_category_custom ENCODER_CAT_CUSTOM encoder_category_focus ENCODER_CAT_SPARE encoder_category_form ENCODER_CAT_BEAM encoder_category_image ENCODER_CAT_GRAPHIC encoder_category_intensity ENCODER_CAT_OTHER encoder_category_shutter ENCODER_CAT_SHUTTER encoder_ext_1 ENCODER_EXT_1 encoder_ext_2 ENCODER_EXT_2 encoder_ext_3 ENCODER_EXT_3 encoder_ext_4 ENCODER_EXT_4 encoder_ext_5 ENCODER_EXT_5 encoder_ext_6 ENCODER_EXT_6 encoder_flexi ENCODER_FLEXI Ion Classic User Manual...
  • Page 667 /eos/key/ Internal Eos Command encoder_lockout ENCODER_LOCKOUT encoder_mode_1 ENCODER_MODE_1 encoder_mode_2 ENCODER_MODE_2 encoder_mode_3 ENCODER_MODE_3 encoder_mode_4 ENCODER_MODE_4 encoder_mode_5 ENCODER_MODE_5 encoder_wheel_move ENCODER_WHEEL_MOVE encoders SNAPSHOT_ENCODERS end_query QUERY_COMPLETE enter ENTER entry ENTRY_MODE entrytime ENTRY_TIME escape ESCAPE even EVEN even_effect EFFECT_EVEN event SC_EVENT eventlist SC_EVENT_LIST exclusive EXCLUSIVE execute EXECUTE exit...
  • Page 668 DIMMER_FLASH flash_off FLASH_OFF flash_on FLASH_ON flexi_all FLEXI_ALL flexi_channel_partition_toggle FLEXI_PARTITION_TOGGLE flexi_in_use FLEXI_ACTIVE flexi_manual FLEXI_MANUAL flexi_moved FLEXI_MOVED flexi_patch FLEXI_PATCH flexi_selected FLEXI_SEL flexi_show FLEXI_SHOW flexi_time FLEXI_TIME flexichannel_mode FLEXI_MODE flip FLIP flip_h PIXELMAP_FLIP_HORIZONTAL flip_v PIXELMAP_FLIP_VERTICAL focus FOCUS_CAT focus_effect FOCUS_EFFECT Ion Classic User Manual...
  • Page 669 /eos/key/ Internal Eos Command focus_palette FOCUS_PALETTE follow FOLLOW force_grandmaster_move FORCE_GRANDMASTER_MOVE foreground_mode MACRO_USER form FORM_CAT format FORMAT forward FORWARD frame_rate FRAME_RATE freeze PLAYBACK_FREEZE friday RTC_FRIDAY full FULL DB_GEL gel_ COLOR_FADE_GEL_SIM gel_match_setting_brightest GEL_MATCH_BRIGHTEST_SETTING gel_match_setting_hybrid GEL_MATCH_HYBRID_SETTING gel_match_setting_spectrum GEL_MATCH_SPECTRUM_SETTING gio_encoder_display GIO_ENCODER_DISPLAY global GLOBAL_PALETTE gm_exempt GM_EXEMPT PLAYBACK_GO (Master Fader) go_0...
  • Page 670 INTENSITY_CAT intensity_block INTENSITY_BLOCK intensity_master INTENSITY_MASTER intensity_palette INTENSITY_PALETTE intensitydown INTENSITY_DOWN intensityup INTENSITY_UP interface INTERFACE interleave FAN_INTERLEAVE internal INTERNAL interpolate INTERPOLATE intime EFFECT_STEP_IN_TIME intime_effect INTIME_EFFECT invert PIXELMAP_SELECT_INVERT invert_pan INVERT_PAN invert_tilt INVERT_TILT ion_encoder_1 ION_ENCODER_1 ion_encoder_2 ION_ENCODER_2 ion_encoder_3 ION_ENCODER_3 Ion Classic User Manual...
  • Page 671 /eos/key/ Internal Eos Command ion_encoder_4 ION_ENCODER_4 is_in IS_IN isn't_in ISNT_IN jump FAN_JUMP keyboard_shortcuts KEYBOARD_SHORTCUTS keywords KEYWORDS label LABEL lamp_control LAMP_CONTROLS lamp_controls_edit CIAPATCH_LAMPCMDS lamp_ctrls LAMP_CONTROL_KEYS lamp_on LAMP_ON landscape LANDSCAPE last LAST last_ref LAST_REF last_ref_off LAST_REF_OFF last_time END_TIME layer_chan LAYER_CHAN ld_flags PATCH_LD_FLAGS learn LEARN learn_time_discrete_steps...
  • Page 672 MACRO_816 macro_817 MACRO_817 macro_818 MACRO_818 macro_819 MACRO_819 macro_820 MACRO_820 macro_button MACRO_STAR macro_entry_delete MACRO_ENTRY_DELETE macro_loop_begin MACRO_LOOP_BEGIN macro_loop_end MACRO_LOOP_END macro_loop_num MACRO_LOOP_NUM_BEGIN macro_mode MACRO_MODE macro_wait MACRO_WAIT macros SFF_MACROS magic_sheet MAGIC_SHEET magic_sheet_apply MAGICSHEET_APPLY magic_sheet_edit MAGICSHEET_EDIT magic_sheet_recall MAGICSHEET_RECALL magic_sheets SFF_MAGICSHEETS Ion Classic User Manual...
  • Page 673 /eos/key/ Internal Eos Command make_absolute MAKE_ABSOLUTE make_manual MAKE_MANUAL make_null MAKE_NULL manual MANUAL manual_master MANUAL_MASTER manual_override MANUAL_OVERRIDE mark MARK mark_cue_designation MARK_CUE_DESIGNATION mark_time MARK_TIME marks DELAY_MARKS media SFF_RESOURCELIST midi MIDI midi_cue_list MIDI_CUELIST midi_raw MIDI_STRING miditimecode MIDI_TC minimum RESTORE_MINIMUM minus_links MINUS_LINKS mirror_in FAN_MIRROR_IN mirror_mode MIRROR mirror_out...
  • Page 674 OPEN_DMX_PATCH open_effect_blind OPEN_EFFECT_PREVIEW open_effect_status OPENEFFECTSTATUS open_fader_config OPENSLIDERCONFIGURATION open_file OPENFILE open_fp_blind OPEN_FOCUS_PALETTE_PREVIEW open_group_blind OPEN_GROUP_PREVIEW open_ip_blind OPEN_INTENSITY_PALETTE_PREVIEW open_macro_preview OPEN_MACRO_PREVIEW open_magic_sheet_blind OPEN_MAGIC_SHEET_PREVIEW open_mirror_dialog OPEN_MIRROR_DIALOG open_ml_controls OPEN_ML_CONTROLS open_park_blind OPEN_PARK_PREVIEW open_partition_preview OPEN_PARTITION_PREVIEW open_pattern_effects OPEN_PATTERN_EFFECTS open_preset_blind OPEN_PRESET_PREVIEW open_setup OPEN_SETUP open_sub_blind OPEN_SUBMASTER_PREVIEW Ion Classic User Manual...
  • Page 675 /eos/key/ Internal Eos Command ordered_view ORDERED_VIEW OSC_ENABLED osc_rx_port_number OSC_RX_PORT_NUMBER osc_tx_ip_address OSC_TX_IP_ADDRESS osc_tx_port_number OSC_TX_PORT_NUMBER page_column_1 PAGE_COLUMN_1 page_column_2 PAGE_COLUMN_2 page_column_3 PAGE_COLUMN_3 page_column_4 PAGE_COLUMN_4 page_column_5 PAGE_COLUMN_5 page_column_6 PAGE_COLUMN_6 page_column_7 PAGE_COLUMN_7 page_down PAGE_DOWN page_encoders_down PAGE_ENCODERS_DOWN page_encoders_up PAGE_ENCODERS_UP page_mode SCROLL_MODE page_up PAGE_UP palettes SFF_PALETTES paper_size_a2 PAPER_SIZE_A2 paper_size_a3 PAPER_SIZE_A3...
  • Page 676 PLAYBACK_RATE playbackrelease PLAYBACK_RELEASE plus_patch PLUS_PATCH plus_show ENTIRE_SHOW popup_virtual_keyboard POPUP_VIRTUAL_KEYBOARD port_offset PORT_OFFSET portrait PORTRAIT positive POSITIVE post_select_softkeys POST_SELECT_SOFTKEYS power_off POWEROFF preheat PREHEAT preheat_off PREHEAT_OFF preheat_time PREHEAT_TIME preserve_blind_cue PRESERVE_BLIND_CUE preserve_native_on_patch_change PRESERVE_NATIVE_ON_PATCH_CHANGE preset PRESET presets SFF_PRESETS prev_channels RESTORE_CHANNEL_LIST Ion Classic User Manual...
  • Page 677 /eos/key/ Internal Eos Command previous RESTORE_PREVIOUS print_color_printout PRINT_COLOR_PRINTOUT print_feedback_errors PRINT_FEEDBACK_ERRORS print_file PRINTFILE print_folder PRINTFOLDER print_summary_view PRINT_SUMMARY_VIEW print_tracked_levels PRINT_TRACKED_LEVELS priority SOURCE_PRIORITY properties PROPERTIES proportion PROPORTION proportional_master PROPORTIONAL_MASTER psd_time_countdown DISPLAY_FADING_CUE_TIME query QUERY quit QUIT random RANDOM random_groups RANDOM_GROUPS random_rate RANDOM_RATE rate RATE rate_wheel_move RATE_WHEEL_MOVE ratewheel...
  • Page 678 RPU_19 rpu_2 RPU_2 rpu_20 RPU_20 rpu_21 RPU_21 rpu_3 RPU_3 rpu_4 RPU_4 rpu_5 RPU_5 rpu_6 RPU_6 rpu_7 RPU_7 rpu_8 RPU_8 rpu_9 RPU_9 rtc_time RTC_TIME run_cue RUN_CUE run_rig_check DIMRACK_RUN_RIG_CHK rvi_settings RVI_SETTINGS sacn sat_adjust COLOR_FADE_SAT saturday RTC_SATURDAY save SAVE Ion Classic User Manual...
  • Page 679 /eos/key/ Internal Eos Command save_file SAVEFILE save_folder SAVEFOLDER save_show SAVE_SHOW scale SCALE scroller_frame SCROLLER_FRAME second_action SECOND_ACTION security_settings SECURITY_SETTINGS select SELECT select_active SELECT_ACTIVE select_all SELECT_ALL select_last SELECT_LAST select_last_params SELECT_LAST_PARAMS select_live_cue_blind SELECT_LIVE_CUE_BLIND select_live_cue_live SELECT_LIVE_CUE_LIVE select_manual SELECT_MANUAL select_nonsub_active SELECT_NONSUB_ACTIVE send_midi_raw SEND_MIDI_STRING send_string SEND_SERIAL_STRING server_chan MAIN_LAYER_CHAN set_chan_level...
  • Page 680 STOP05 stop_6 STOP06 stop_7 STOP07 stop_8 STOP08 stop_9 STOP09 stop_all STOP_ALL_EFFECT stop_and_fade STOP_AND_FADE stop_and_hold STOP_AND_HOLD stop_effect STOP_EFFECT stop_effect_button STOP_EFFECT_BUTTON stopback PLAYBACK_STOP_BACK stopeffect STOP_EFFECT string SERIAL_STRING string_and_osc_rx SERIAL_RX_ENABLE string_and_osc_tx SERIAL_TX_ENABLE string_midi_tx SERIAL_MIDI_TX string_rx_group_ids SERIAL_RX_GROUP_IDS string_rx_port SERIAL_RX_PORT_NUMBER Ion Classic User Manual...
  • Page 681 /eos/key/ Internal Eos Command string_tx_group_ids SERIAL_TX_GROUP_IDS string_tx_ip_address SERIAL_TX_IP_ADDRESS string_tx_port SERIAL_TX_PORT_NUMBER SUBMASTER subassert SUB_ASSERT subdown SUB_BUMP_DOWN subfreeze SUB_FREEZE submasters SFF_SUBMASTERS submove SUB_MOVE suboff SUB_OFF subrelease SUB_RELEASE subtype SUB_TYPE subup SUB_BUMP_UP sunday RTC_SUNDAY sw_go_1 SW_GO_1 sw_go_10 SW_GO_10 sw_go_11 SW_GO_11 sw_go_12 SW_GO_12 sw_go_13 SW_GO_13 sw_go_14 SW_GO_14...
  • Page 682 SW_STOP_26 sw_stop_27 SW_STOP_27 sw_stop_28 SW_STOP_28 sw_stop_29 SW_STOP_29 sw_stop_3 SW_STOP_3 sw_stop_30 SW_STOP_30 sw_stop_31 SW_STOP_31 sw_stop_32 SW_STOP_32 sw_stop_33 SW_STOP_33 sw_stop_34 SW_STOP_34 sw_stop_35 SW_STOP_35 sw_stop_36 SW_STOP_36 sw_stop_37 SW_STOP_37 sw_stop_38 SW_STOP_38 sw_stop_39 SW_STOP_39 sw_stop_4 SW_STOP_4 sw_stop_40 SW_STOP_40 sw_stop_5 SW_STOP_5 Ion Classic User Manual...
  • Page 683 /eos/key/ Internal Eos Command sw_stop_6 SW_STOP_6 sw_stop_7 SW_STOP_7 sw_stop_8 SW_STOP_8 sw_stop_9 SW_STOP_9 swap SWAP swap_address SWAP_ADDRESS swap_pan/tilt SWAP_FIXTURE system_settings SFF_SYSTEMSETTINGS SHEET tab_down TAB_DOWN tab_up TAB_UP tb_pan_swap TB_PAN_SWAP tb_tilt_swap TB_TILT_SWAP tb_xy_swap TB_XY_SWAP test_fixture TEST_LAMP text1 TEXT1 text10 TEXT10 text2 TEXT2 text3 TEXT3 text4 TEXT4...
  • Page 684 MACRO_PAUSE_FOR_INPUT wednesday RTC_WEDNESDAY wheel WHEEL wheel0 WHEEL0 wheel1 WHEEL1 wheel2 WHEEL2 wheel3 WHEEL3 wheel4 WHEEL4 wheel5 WHEEL5 wheel6 WHEEL6 wheel7 WHEEL7 wheel8 WHEEL8 wheel9 WHEEL9 wheelandencoderbutton WHEEL_AND_ENCODER_BUTTON white_point PATCH_WHITE_POINT white_point_xyz PATCH_WHITE_POINT_XYZ width PIXEL_WIDTH year RTC_YEAR Ion Classic User Manual...

  • Page 685: Regulatory

    Regulatory Apex 5, 10, and 20, Apex Remote Processor, Eos Remote Interface, and Windows 10-based Ion Xe, Ion Xe20, Ion Xe RPU, Gio@5, and Element 2 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 686: Etcnomad Puck

    Connect the equipment into an outlet on a circuit different from that to which the • receiver is connected. Consult the dealer or an experienced radio/TV technician for help. • Contains Model: AX200NGW Contains FCC TX ID: PD9AX200NG Canada IC:1000M- AX200NG Japan RF:003-190022 TEL:D190021003 South Korea R-C-INT-AX200NGW Ion Classic User Manual...
  • Page 687 | Support support.etcconnect.com | Contact etcconnect.com/contactETC © 2022 Electronic Theatre Controls, Inc. | Trademark and patent info: etcconnect.com/ip Product information and specifications subject to change. ETC intends this document to be provided in its entirety. 4310M1210-3.1.1 Rev A Released 2022-03...

This manual is also suitable for:

Element classic

Table of Contents

Save PDF
