Raven SmarTrax Installation Manual page 13

Introduction: Kit Contents
Item Description
U-Bolt - 3/4" W x 1-1/4" L x 1/4"-20
UNC Thread
Bolt - 1/4"-20 UNC x 1" Hex
Bolt - 5/16"-18 UNC x 7/8" Hex
Bolt - M8 x 1.25 x 35mm Metric Hex
Screw - 1/2"-20 Knurled Cup Hex
Socket Head Set
Nut - 1/4"-20 UNC Flanged Lock
Nut - M10 x 5mm x 1.5 Pitch Jam
Nut - 3/8"-16 Nylon Insert Lock
Nut - M10 x 1.5 Nylon Insert Lock
Nut - 3/8"-16 Nylon Insert Thin Lock
Washer - 5/16" Split Lock
INTRODUCTION
Part Number Qty.
107-0172-102 2
311-0050-105 1
311-0052-104 4
311-0070-020 2
311-0015-729 2
312-1001-168 5
312-1002-035 2
312-4000-061 2
312-4000-208 1
312-4001-109 3
313-1000-019 4
9
