Section 7: IDP, SK, SD and SWIFT™ SLC Device Installation
CAUTION:
!
To avoid the risk of electrical shock and damage to the unit, power should be OFF at the control panel while installing or servicing

7.1 List of IDP SLC Devices

The following IDP SLC devices can be used with the control panel. See the appropriate section number in this manual or the device
installation instructions (packaged with the device) for more information.
IDP Part Number
IDP-Photo
IDP-Photo-T
IDP-PhotoR
IDP-Acclimate
IDP-Beam
IDP-Beam-T
DNR/DNRW
IDP-Heat
IDP-Heat-ROR
IDP-Heat-HT
IDP-Pull-SA
IDP-Pull-DA
IDP-ISO
ISO-6
IDP-Monitor
IDP-Minimon
IDP-Monitor-2
IDP-Monitor-10
IDP-Relay
IDP-Relay-6
IDP-RelayMon-2
IDP-Zone
IDP-Zone-6
IDP-Control
IDP-Control-6
IDP-FIRE-CO
B200S//IV
B210LP
B224BI/IV
B224RB/IV
B200SR/IV
B501
B200SR-LF/IV
B200S-LF/IV
IDP-PHOTO-W/IV
IDP-PHOTO-R-W/IV
IDP-PHOTO-T-W/IV
IDP-HEAT-W/IV
IDP-HEAT-ROR-W/IV
IDP-HEAT-HT-W/IV
77
Model Name/Description
Photoelectric smoke detector
Photoelectric smoke detector with thermal (135°F)
Photoelectric replacement smoke detector with remote test capability in DNR I56-3569-000
Multi criteria photoelectric smoke detector with thermal (135°F)
Reflected beam smoke detector without test feature
Reflected beam smoke detector with test feature
Duct smoke detector housing. Non-relay (PhotoR sold separate)
Fixed temperature thermal detector (135°F)
Rate-of-rise thermal detector with 135° fixed temperature
Fixed high temperature thermal detector (190°F)
Addressable single action pull station
Addressable dual action pull station
Fault isolator module
Six fault isolator Module
Monitor module
Mini monitor module
Dual input monitor module
10 input monitor module
Addressable relay module
Six relay control module
Multiple Module with 2 Relay Outputs and 2 Monitor Inputs
Addressable zone interface module
Six zone interface module
Supervised control module
Six circuit supervised control module
CO Smoke Detector
Sounder Base. White or Ivory
6" Flanged Intelligent Detector Base, Low Profile
6" isolator base. White or Ivory
6" relay base. White or Ivory
Sounder Base. White or Ivory
4" mounting base
Low Frequency Sounder Base. White or Ivory
Low Frequency Sounder Base. White or Ivory
Photoelectric smoke detector. White or Ivory
Photoelectric replacement smoke detector with remote test capability in
DNR. White or Ivory
Photoelectric smoke detector with thermal (135°F) White or Ivory
Fixed temperature thermal detector (135°F). White or Ivory
Rate-of-rise thermal detector with 135° fixed temperature. White or Ivory
Fixed high temperature thermal detector (190°F). White or Ivory
Table 7.1 IDP SLC Devices
IFP-300 / IFP-300ECS Manual P/N LS10145-001SK-E:B 12/18/2017
Install Sheet PN
I56-3611-000
I56-3611-000
I56-2735-00
I56-3051-00
I56-3608-00
I56-3606-00
I56-3605-00
I56-2729-00
I56-4096-00
I56-3603-00
I56-3604-00
I56-3614-00
I56-2731-00
I56-3601-00
I56-2732-00
I56-3734-00
I56-3602-00
I56-2733-00
I56-3600-00
I56-2734-00
I56-3946-00
I56-3387-00
I56-0595-00
I56-0725-00
I56-3737-00
I56-3392-00
I56-0357-00
I56-4152-00
I56-4151-00
I56-6531-00
I56-6532-00
I56-6534-00
I56-6533-00
I56-6533-00
I56-6533-00
