PentaFOB
Coding the PentaFOB
1. Using the Receiver
2. Using another Remote Control
Coding using the Receiver
1. Press and hold the program button on the receiver
2. Press the remote button for 2 seconds, receiver LED will flash and then turn Green
3. Release the button on the receiver and the remote
4. Press remote control button to test the receiver output
Coding using another Remote Control (you should be near the receiver for this procedure)
1. Open the case of a remote control that is already programmed and press and release the
program button on the back of the board (The receiver enters learning mode)
2. Press the button of the remote in step 1 which activates the receiver
3. Press the button on the new remote which needs to be programmed for 2 seconds
4. Press the program button again of the remote in step 1(The receiver exits learning mode)
5. Press the new remote control button to test the receiver output
Deleting Receivers Memory
Short the Code Reset pins on the receiver for 10 seconds.
the receiver's memory.
PentaFOB Programmer
®
This programmer allows you to add and delete certain remotes from the receiver memory. This is used when
a remote control is lost or a tenant moves from the premises and the owner wants to prevent un-authorised
access.
PentaFOB Backup Chips
®
This chip is used to backup or restore the contents of a receiver. When there are 100's of remotes
programmed to a receiver the installer normally backups the receiver memory in case the receiver is
damaged.
30
Programming Instructions
®
remotes and receivers can be done in 2 different ways.
®
This will delete all the remotes from
Gate & Door Controller with Eclipse Operating System (EOS)
®
