Menu 9 – Motor Speed, Slow Speed Area
Motor Speed, Slow Speed
Menu No.
Area and Reverse Time
9.1
9.2
9.3 Open and Close Slow Speed
9.4 Open Slow Speed Area
9.5 Close Slow Speed Area
9.6
9.7
After changing open speed, close speed or slow speed, i-Learn has to be done again.
9.1 & 9.2 Open and Close Speed
This sets the speed at which the gate will travel. If the gate is travelling too fast reduce this value.
9.3 Slow Speed
This sets the speed at which the gate will travel in the slow speed region. If the gate is travelling too slow
increase this value.
9.4 & 9.5 Slow Speed Area
This sets the slow speed travel area. If you want more travel time for the slow speed area increase this
value.
9.6 Obstruction Stop Reverse Delay Time
This sets the stop and reverse delay time when the gate hits an obstruction.
24
and Reverse Time
Open Speed
Close Speed
Stop Reverse Delay
Exit
Factory
Adjustable
Default
80% 50% to 125%
70% 50% to 125%
50% 25% to 65%
4
5
0.4 seconds 0.2 to 2.5 seconds
Gate & Door Controller
1 to 12
1 to 12
