Menu 5 – Output Functions
The control card has two outputs, Output 1 and Output 2. The user can change the function of these
outputs to lock / brake, courtesy light, service call, strobe (Warning) light or gate open (gate not fully
closed) indicator.
Output 1 is a relay output with common and normally open contacts. Factory default is lock / brake
release function.
Output 2 is an open collector output. Factory default is courtesy light function.
Menu No.
Function
5.1 Output 1
5.2 Output 2
5.3
16
Output Factory
Default
Lock / Brake
Courtesy Light
Exit
Adjustable
Lock / Brake
------------------------------------
Courtesy Light
------------------------------------
Service Call
------------------------------------
Strobe (Warning) Light
------------------------------------
Gate Open
Lock / Brake
------------------------------------
Courtesy Light
------------------------------------
Service Call
------------------------------------
Strobe (Warning) Light
------------------------------------
Gate Open
