7.6 & 7.7 Press and Hold for Open and Close Inputs
If this feature is ON the user must continuously press the open or close input for it to be activated.
7.8 Window or Louvre Mode
This mode optimises the control card for operating electronic windows or louvres.
7.10 & 7.11 Press and Hold for Remote Channel 1 (Open) and Channel 2 (Close)
The remote channel 1 & 2 buttons will need to be programmed to receiver channel 1 & 2. The user must
continuously press the remote button for the gate to open or close. The gates will stop as soon as the buttons
are released.
Menu 8 – Obstruction Detect Margins
This sets the current sensitivity margin above the normal run current to trip the gate if an obstruction is
detected. Different obstruction margins and response time can be set for the open and close direction.
The minimum margin will allow least pressure applied to trip the gate if it hits an object. The maximum
margin will allow for a large amount of pressure applied to trip the gate if it hits an object.
Obstruction Detect Margins and
Menu No.
8.1 Open Obstruction Margin
8.2 Close Obstruction Margin
Open and Close Slow Speed
8.3
8.4 Obstruction Detect Response Time
8.5
Margin Example
Motor is running at 2 Amps and the margin is set to 1.5 Amps, an obstruction detect will occur at
3.5 Amps (Normal Running Current + Margin).
For high margin settings, the supply transformer should be large enough to supply the high margin current.
If the gate hits an object on closing it will automatically stop and then re-open. If the gate hits an object on
opening it will automatically stop.
www.elsema.com
Response Time
Obstruction Margin
Exit
Factory Default
1 Amp
1 Amp
1 Amp
Medium Fast, Medium, Slow and Very Slow
Adjustable
0.2 - 6.0 Amps
0.2 - 6.0 Amps
0.2 - 6.0 Amps
23
