Elsema Eclipse MCS Setup And Technical Information page 21

Menu 6.4 – Service Call Output Mode
This sets the number of complete cycles (Open and Close) required before the built-in buzzer is
activated. Also the control card outputs can be configured to be activated if the number of cycles is
completed. Connecting Elsema's GSM receiver to the output allows owners to get a phone call & SMS
message when the service is due.
When "Service Call Due" message shows up on the LCD a service call is required. After service has
been done, follow the messages on the LCD.
Menu No. Service Call Mode
6.4.1
6.4.2
www.elsema.com
Service Counter
Exit
Factory
Default
Off Min: 2000 to Max: 50,000
Adjustable
21
