1.4 Auto Close after Power Restored
If the gate is open in any position and then there is a power failure, when power is reconnected the gate will
close with this timer.
1.5 Normal Auto Close on Sequential Obstructions
If the normal Auto Close is set and the gate closes onto an object the gate will stop and reopen. This setting
sets the amount of times the gate will try to Auto Close. After trying for the set limit the gate will remain
open.
1.6 Auto Close Only when Fully Opened
The Auto Close timer will not time out unless the gate is fully open.
Menu 2 – Pedestrian Access
There are several types of Pedestrian Access modes. Pedestrian Access opens the gate for a short time to
allow someone to walk through the gate but does not allow access to a vehicle.
Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the
Auto Close options are used.
Menu No.
2.1
2.2
2.3 Pedestrian Access Auto Close Time with PE trigger
2.4 Pedestrian Access Auto Close on Sequential Obstructions
2.5
2.6
www.elsema.com
Pedestrian Access Features
Pedestrian Access Travel Time
Pedestrian Access Auto Close Time
Pedestrian Access with Hold Gate
Exit
Factory
Adjustable
Default
3 seconds 3 - 20 seconds
Off 1 - 60 seconds
Off 1 - 60 seconds
Min = Off,
2
Max = 5
Off Off/On
