- Page 1 4th Edition Axiom Sliding Gate Motor Kit with Eclipse Operating System ® iS600/iS900 (EOS) AXIOM iS600 / iS900 Axiom Sliding Gate Motor Kits Setup and Technical Information Includes latest Intelligent Technology www.elsema.com...
- Page 2 Elsema Pty Ltd shall not be liable for any injury, damage, cost, expense or any claim whatsoever to any person or property which may result from improper use or installation of this product.
-
Page 3: Table Of Contents
Menu 9 – Motor Speed and Slow Speed Area ..............21 Menu 10 – Anti-Jam and Braking ..................22 Menu 11 – i-Learning ......................23 Menu 12 – Password .......................23 Menu 13 – Operational Records..................23 Menu 14 – Tools ......................24 Accessories ........................25 PentaFOB Programming Instructions ................27 ® www.elsema.com... -
Page 4: Features
It uses a large 4-line LCD screen showing live reading of the motor performance and status of all inputs and outputs. Elsema’s easy options to add remote controls or any other accessory makes for a very user friendly approach, while avoiding the lockdown approach. -
Page 5: Part Number
AXIOM SERIES ELSEMA INTELLIGENT SLIDING GATE OPENER ® iS600 iS900 Part Number: Part No. Contents Part No. Contents Standard iS600 Kit includes 4metres or gear rack, Standard iS900 Kit includes 4metres or gear rack, iS600 iS900 3 x FOB remotes and Photo Electric Beam... -
Page 6: Menu Structure
Menu Structure Press Master Control for 2 seconds to enter the menu structure MAIN Auto Close Auto Close Time AC Time with PE Trig SCREEN Pedestrian Access PA Travel Time PA AC Time Input Functions PE Polarity Limit Sw Polarity PE Beam Stops Motor PE Safety Beam Function on Close Cycle... - Page 7 13.3 13.4 Reset Max Current Records EXIT 14.7 14.6 14.3 14.4 14.5 Fuse Type : 10 or 15 Amps Solar Gate Mode Reset Factory Default Test Inputs Travel Timer for Slip Motors 14.8 14.9 Slow Speed Ramp Down Exit www.elsema.com...
-
Page 8: Connection Diagram
Connection Diagram AC Supply AC Supply AC Supply AC Supply Motor AC Supply Motor AC Supply Battery + AC Supply Battery - AC Supply Push Button Open Common Close Stop Common PED Access Photo Beam Program 2 Common Program 1 + 12 VDC Antenna 1 - 12 VDC... -
Page 9: Supply And Motor Inputs
The diagram below shows the supply, motors, and inputs available and the factory default setting for each input. Master Control Open Close Stop ELSEMA Output Rated at 250mA Normally Open Normally Closed User can change User can change Setup i-Learning Steps: 1. -
Page 10: Menu 1 - Auto Close
Auto Close and several special Auto Close features each one having its own countdown timers. Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto Close options are used. -
Page 11: Menu 2 - Pedestrian Access Features
There are several types of Pedestrian Access modes. Pedestrian Access opens the gate for a short time to allow someone to walk through the gate but does not allow access to a vehicle. Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto Close options are used. -
Page 12: Menu 3 - Input Functions
2.1 Pedestrian Access Travel Time This sets the time the gate opens when a Pedestrian Access input is activated. 2.2 Pedestrian Access Auto Close Time This sets the countdown timer for automatically closing the gate when a Pedestrian Access input is activated. -
Page 13: Menu 4 - Photoelectric Beam
The factory default for the PE beam input is “normally closed” but this can be changed to normally open in Menu 3.1. Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto Close options are used. -
Page 14: Menu 5 - Relay Output Functions
Menu 5 – Output Functions The control card has two outputs, Output 1 and Output 2. The user can change the function of these outputs to lock / brake, courtesy light, service call, strobe (Warning) light or gate open (gate not fully closed) indicator. - Page 15 The factory default for the courtesy light is on output 2. Output 2 is an open collector output. This output is used to switch an external relay such as Elsema’s REL12-1 which can be purchased separately. See diagram on the next page.
- Page 16 Either output 1 or output 2 can be changed to service call indicator. This will trigger the output when the software service counter is reached. Used to alert installers or owners when the gate is to be serviced. Using Elsema’s GSM receiver allows installers or owners to get a SMS message and a call when the service is due.
-
Page 17: Menu 6 - Relay Output Modes Relay Output Modes
The relay output in the courtesy mode can be adjusted from 30 to 300 seconds. This sets the time the courtesy light is activated. Factory default is 60 seconds. Factory Menu No. Courtesy Light Mode Adjustable Default 6.2.1 Courtesy Light Activation 60 seconds 30-300 seconds 6.2.2 Exit www.elsema.com... - Page 18 Also the control card outputs can be configured to be activated if the number of cycles is completed. Connecting Elsema’s GSM receiver to the output allows owners to get a phone call & SMS message when the service is due.
-
Page 19: Menu 7 - Special Features
When this feature is disabled, the gate will only stop. Automatic opening will be disabled. 7.5 Receiver Channel 2 Options The receivers 2nd channel can be programmed to control a courtesy light, pedestrian access or can be used for close only. www.elsema.com... -
Page 20: Menu 8 - Motor Obstruction
7.6 & 7.7 Press and Hold for Open and Close Inputs If this feature is ON the user must continuously press the open or close input for it to be activated. 7.8 Window or Louvre Mode This mode optimises the control card for operating electronic windows or louvres. 7.10 &... -
Page 21: Menu 9 - Motor Speed And Slow Speed Area
This sets the slow speed travel area. If you want more travel time for the slow speed area increase this value. 9.6 Obstruction Stop Reverse Delay Time This sets the stop and reverse delay time when the gate hits an obstruction. www.elsema.com... -
Page 22: Menu 10 - Anti-Jam And Braking
Menu 10 – Anti-Jam, Electronic Braking and Gate Movement after Obstruction Anti-Jam or Factory Menu No. Adjustable Electronic Braking Default 10.1 Open Anti-Jam 0.1 to 2.0 seconds 10.2 Close Anti-Jam 0.1 to 2.0 seconds 10.3 Electronic Braking Off/On Gate Movement after Obstruction in Stop / Reverse for 2 sec / 10.4 Stop... -
Page 23: Menu 11 - I-Learning
This will allow the user to enter a password to prevent unauthorised users from entering the control card settings. User must remember the password. The only way to reset a lost password is to send the control card back to Elsema. To delete a password select Menu 12.2 and press Master Control. -
Page 24: Menu 14 - Tools
14.1 Battery Type The iS900B motor kit is with Lithium-ion battery backup. Only use Lithium-ion batteries supplied by Elsema. Part number Li7800. 14.2 Set the Supply Voltage The control card automatically sets the supply voltage during setup. This option allows you to manually set the control card to 12 or 24 Volt supply. -
Page 25: Accessories
Accessories Solar Applications For solar use the iS900Solar24 Pre-made Inductive Loops & Loop Detectors Elsema has a range of Saw-Cut and Direct Burial loops. They are pre-formed with recommended loop sizes for commercial or domestic applications and makes Inductive Loop Loop Detectors installation quick and easy. - Page 26 Keyring Remotes The latest PentaFOB keyring remotes ensure your gates or doors are secure. ® Visit www.elsema.com for more details. PentaFOB Remotes ® PentaFOB Programmer ® Add, edit and delete PentaFOB remotes from ® the receiver’s memory. The receiver can also be password protected from unauthorised access.
-
Page 27: Pentafob ® Programming Instructions
Backup Chips ® This chip is used to backup or restore the contents of a receiver. When there are 100’s of remotes programmed to a receiver the installer normally backups the receiver memory in case the receiver is damaged. www.elsema.com... - Page 28 LCD Display Explained Input Status Gate Status Limit Switch Status Gate Status Description Gate Opened Gate is in the fully open position Gate Closed Gate is in the fully close position Gate Stopped Gate has been stopped by either one of the inputs or remote control Obstruction Detected Control card has sensed an obstruction Limit Switch Status...
- Page 29 Gate does not respond to remotes or Check the LCD for Input status (see previous page). If any input is activated and held any local trigger. active, the card will not respond to any other command. www.elsema.com...
- Page 30 Keyring remote controls Sliding gate Swinging gate motor kits motor kits Sliding gate Swinging gate motor kits motor kits Motor control cards & Kits ELSEMA PTY LTD 31 Tarlington Place Smithfield NSW 2164 Australia 02 9609 4668 www.elsema.com...
