Appendix C – Pinouts
This appendix provides the pinouts for the keyboard, AUX, LPT1, COM1, COM2,
USB1, and VGA connectors. (NC indicates no connection.)
Keyboard Port Connectors
This connector is a standard PS/2-compatible connector.
Aux Port Connector
This PS/2 mini-DIN connector allows you to attach a serial device.
You cannot use the AUX port when the touchscreen controller is using it.
Dual USB Connector (USB1)
This connector is only available on units with AHIP6+ boards.
Pin Number
1A
2A
3A
4A
Pin
1A
2A
3A
4A
5A
6A
Pin
1B AUX_DATA
2B NC
3B GND
4B 5VFUSE
5B AUX_CLK
6B NC
Note
Description
5VFUSE
USBP0-
USBP0+
GND
Signal
KB_DATA
NC
GND
5VFUSE
KB_CLK
NC
Signal
Pin Number
1B
2B
3B
4B
Description
5VFUSE
USBP1-
USBP1+
GND
