3510/3510KP/3512/3512KP System Manual
13. Insert the new bulb assembly, and push in until the tab locks in place.
Xycom Automation recommends replacing both bulbs at the same time.
14. Repeat steps 12 and 13 for the second bulb assembly.
15. Reverse steps 1 through 10 to reassemble the unit.
D-6
Figure D-3. Model #LQ12S41 Bulb Assembly
Note
