3510/3510KP/3512/3512KP System Manual
7. Using the touchscreen manual do the following:
•
•
•
8. Replace the lid.

Using a Pointing Device with a Touchscreen

The touchscreen setup program needs to know if you are using another pointing
device with the touchscreen. The Windows touchscreen driver does not display the
cursor. Instead, the pointing device driver is responsible for displaying the cursor.
In the touchscreen setup program, Support for Another Pointing Device, select the
following:
If you are
using a mouse with
the touchscreen
not using a mouse

Calibrating the Touchscreen

If you need to recalibrate the touchscreen, refer to the sections in the touchscreen
manual that explain calibration and using the diagnostic utility.
You need to calibrate the touchscreen in the following cases:
•
The cursor does not follow the movement of your finger or pen.
•
You adjust the size of the video image or change the video mode.
The touchscreen and controller are a matched pair calibrated at the
factory.

Installing the System into a Panel

The system's rugged design allows it to be installed in most industrial environments.
The system is generally placed in a NEMA 4/4X/12 enclosure to protect against
contaminants such as dust, moisture, etc. Metal enclosures also help minimize the
effects of electromagnetic radiation that nearby equipment can generate.
3-20
Load the touchscreen drivers.
Reconfigure the touchscreen driver for COM2.
Recalibrate the touchscreen.
Select Result
Yes The pointing device driver controls the cursor display
No The Setup program loads a cursor display driver
(MTSMOUSE.DRV) as well as the Windows touchscreen driver
Note
