Appendix A – Technical Specifications
Hardware Specifications
Characteristic
Mechanical
Height
Width
Depth
Weight
Electrical
AC
DC
Power Supply
Available Power
Passive Backplane
Mounting
Flat Panel
Agency Approvals
Regulatory
Compliance
Hardware Specifications
11.0" Front Panel; 12.25" (KP units)
13.0" Front Panel 16.50" (KP units)
4.5" overall
5.75" behind front panel
0.75" front panel protrusion
7.25" overall with back-mounted external floppy
12 lbs; 14 lbs with external floppy
115/230 VAC 50-60 Hz
20-36 VDC 24 V nominal
80 watts (AHIP4)
With AHIP4+ CPU board
+ 5 V 6.17A
+12 V 1.88A
–12V 0.71A
Caution: Total expansion power not
to exceed 46 watts.
Two PC/AT bus ¾ length expansion slots
One PCI or PC/AT bus ¾ length expansion slot
Panel Mount or 19" rack with optional filler plate.
10.4" TFT active color display
12.1" TFT active color display
UL 1950
UL 1604
CUL C22.2, No. 950
CUL C22.2, No. 213
FCC 47 CFR. Part 15, Class A
CE
EMI
IMMUNITY
SAFETY
Specification
3.0/1.5 AMPS
10 A maximum
200watts (AHIP6+)
With AHIP6+ CPU board
+3.3 V 9A
+5 V 6A
+12 V 1.5A
-12 V .45A
Caution: Total expansion power not
to exceed 48 watts.
EN55022: 1994 Class A
EN50082-2:1995
EN60950
