Introduction
1.2 Description
Rated for Reliability in Harsh Environments
•
•
•
•
•
•
•
Universal Power Supply Options
•
•
•
•
•
1.2

Description

The RUGGEDCOM RSG910C features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
3
4
5
1
2
3
4
5
6
2
Immunity to EMI and heavy electrical surges
Certified for use in explosive environments in accordance with the ATEX directive
Hazardous Location Certification: Class I Division 2
-40 to 85 °C (-40 to 185 °F) ambient operating temperature (no fans)
Die Cast Aluminum
Panel mounting option provides secure mechanical reliability
[Optional] Conformal coated printed circuit boards
Fully integrated power supply
Dual high-voltage AC/DC inputs: 88-300 VDC or 85-264 VAC
Dual low-voltage DC inputs: 12, 24 or 48 VDC
Terminal blocks for reliable maintenance free connections
CSA/UL 60950-1 safety approved to 85 °C (185 °F)
1
2
8
10
7 9
POWER LED
ALARM LED
USB Console Port
SFP Tranceiver Ports 7 to 10
Copper Ethernet Ports (Ports 1 to 6)
Failsafe Alarm Relay
6
7
8
RUGGEDCOM RSG910C
Installation Manual, 02/2020, C79000-G8976-1405-06
