Figure 1.1
POWER LED
ALARM LED
Console Port
Communication Ports
Failsafe Alarm Relay
Power Supply Terminal Blocks
Chassis Ground Terminal
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RSG910C:
AC power cord (16 AWG)
USB Type-B console port cable
CAT-5 Ethernet cables
Flathead screwdriver
Phillips screwdriver
Torx screwdriver
4 x M5 or #10-24 screws
1.4

Decommissioning and Disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
RUGGEDCOM RSG910C
Installation Manual, 02/2020, C79000-G8976-1405-06
Power Supply Terminal Blocks
Chassis Ground Screw
RUGGEDCOM RSG910C
Tools/Materials
Illuminates green when power is supplied to the device.
Illuminates red when an alarm condition exists.
The USB Type-B console port is for interfacing directly with the de-
vice and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page
Communication ports in general receive and transmit data, as well
as provide access to the RUGGEDCOM RUGGEDCOM RSG910C Web
interface. For more information about the various ports available,
refer to
"Communication Ports (Page
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
"Connecting the Failsafe Alarm Relay (Page 11)"
"Failsafe Alarm Relay Specifications (Page 26)"
Pluggable terminal blocks for connecting one or more power
sources. For more information, refer to
13)"
and
"Power Supply Specifications (Page
Protects the device from power surges and accumulated static elec-
tricity. For information about grounding the device, refer to
necting Power (Page
13)".
For connecting power to the device.
For connecting to the RUGGEDCOM RUGGEDCOM
RSG910C console interface.
For connecting the device to a LAN.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For attaching mounting brackets to the device.
For mounting the device to a panel.
Introduction
1.3 Required Tools and Materials
19)".
21)".
"Connecting Power (Page
25)".
Purpose
"Con-
3
