Installation Manual
SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM RSG910C
https://www.siemens.com/ruggedcom

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC NET RUGGEDCOM RSG910C

Summary of Contents for Siemens SIMATIC NET RUGGEDCOM RSG910C

  • Page 1 Edition 04/2022 Installation Manual SIMATIC NET Rugged Ethernet Switches RUGGEDCOM RSG910C https://www.siemens.com/ruggedcom...
  • Page 2 Preface Introduction Installing the Device SIMATIC NET Device Management Rugged Ethernet Switches RUGGEDCOM RSG910C Communication Ports Technical Specifications Installation Manual Certification 04/2022 C79000-G8976-1405-11...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 4: Table Of Contents

    Accessing Documentation ....................... v Registered Trademarks ......................v Warranty ..........................vi Training ..........................vi Customer Support ........................vii Contacting Siemens ....................... vii Introduction ........................... 1 Feature Highlights ....................1 Description ......................2 Required Tools and Materials ................. 3 Decommissioning and Disposal ................3 Installing the Device ......................
  • Page 5 Table of Contents Copper Ethernet Port Specifications ..............27 Operating Environment ..................27 Mechanical Specifications ..................27 Dimension Drawings ................... 28 Certification ......................... 31 Approvals ......................31 6.1.1 CSA ........................31 6.1.2 CSA/Sira ......................32 6.1.3 European Union (EU) ..................33 6.1.4 FCC ........................

  • Page 6: Preface

    SIMATIC NET Glossary The SIMATIC NET Glossary describes special terms that may be used in this document. The glossary is available online via Siemens Industry Online Support (SIOS) at: https://support.industry.siemens.com/cs/ww/en/view/50305045 Accessing Documentation The latest user documentation for RUGGEDCOM RSG910C is available online at https://support.industry.siemens.com.

  • Page 7: Warranty

    Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.

  • Page 8: Customer Support

    Preface Customer Support Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request to submit a Support Request (SR) or check on the status of an existing SR.
  • Page 9 Preface Contacting Siemens viii RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...

  • Page 10: Introduction

    • Removable SFP Transceivers Ports 7 to 10 can be customized with a wide array of 1000Base-X Small Form- factor Portable (SFP) transceivers offered by Siemens, making the device flexible to the needs of the redundant network application. • Fixed Ethernet Ports...

  • Page 11: Description

    Introduction 1.2 Description Rated for Reliability in Harsh Environments • Immunity to EMI and heavy electrical surges • Certified for use in explosive environments in accordance with the ATEX directive • Hazardous Location Certification: Class I Division 2 • -40 to 85 °C (-40 to 185 °F) ambient operating temperature (no fans) •...

  • Page 12: Required Tools And Materials

    Introduction 1.3 Required Tools and Materials Power Supply Terminal Blocks Chassis Ground Screw Figure 1.1 RUGGEDCOM RSG910C POWER LED Illuminates green during boot up and when power is supplied to the device. ALARM LED Illuminates red when an alarm condition exists. Console Port The USB Type-B console port is for interfacing directly with the device and accessing initial management functions.
  • Page 13 Introduction 1.4 Decommissioning and Disposal Decommissioning This device may include sensitive, proprietary data. Before taking the device out of service, either permanently or for maintenance by a third-party, make sure it has been fully decommissioned. For more information, refer to the associated "Configuration Manual". Recycling and Disposal For environmentally friendly recycling and disposal of this device and related accessories, contact a facility certified to dispose of waste electrical and electronic...

  • Page 14: Installing The Device

    This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by Siemens Canada Ltd. could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment.

  • Page 15: General Procedure

    Inspect the package for damage before opening it. Visually inspect each item in the package for any physical damage. Verify all items are included. Note If any item is missing or damaged, contact Siemens for assistance. RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...

  • Page 16: Installing The Device In Hazardous Locations

    Installing the Device 2.3 Installing the Device in Hazardous Locations Installing the Device in Hazardous Locations The RUGGEDCOM RSG910C is designed to comply with the safety standards for Class I, Division 2, Zone 2 hazardous locations where concentrations of flammable gases, vapors or liquids may be present, as opposed to normal operating environments.

  • Page 17: Mounting The Device

    Installing the Device 2.4 Mounting the Device Sample Hazardous Location Label The following is an example of the RUGGEDCOM RSG910C hazardous location label: Figure 2.1 Compliance Label (Example) Mounting the Device The RUGGEDCOM RSG910C is designed for maximum mounting and display flexibility. It can be equipped with adapters that allow it to be attached to a DIN rail or panel.
  • Page 18 Installing the Device 2.4.1 Mounting the Device on a DIN Rail NOTICE DIN rail mounting is not recommended for constant vibration environments. Mounting the Device To mount the device to a DIN rail, do the following: Hook the top teeth of the adapter onto the DIN rail. Note The adapter features a sliding release with a slot at the bottom for a flathead screwdriver.

  • Page 19: 2.4.2 Mounting The Device To A Panel

    Installing the Device 2.4.2 Mounting the Device to a Panel Removing the Device To remove the device from a DIN rail, do the following: Insert a flathead screwdriver into the slot of the sliding release and move it down. DIN Rail DIN Rail Adapter Figure 2.3 Removing the Device from a DIN Rail...
  • Page 20 Installing the Device 2.4.2 Mounting the Device to a Panel To mount the device to a panel, do the following: Secure the mounting adapters to the top and bottom of the device using the four M4 screws included with the device. Screw (M4) Panel Mount Adapter Figure 2.4...

  • Page 21: Connecting The Failsafe Alarm Relay

    Installing the Device 2.5 Connecting the Failsafe Alarm Relay Place the device against the panel and align the adapters with the mounting holes. Screw (M5 or #10-24) Panel Mount Adapter Figure 2.5 Panel Mounting Secure the adapters to the panel with M5 or #10-24 screws. Connecting the Failsafe Alarm Relay The failsafe relay can be configured to latch based on alarm conditions.
  • Page 22 Installing the Device 2.5 Connecting the Failsafe Alarm Relay To connect the failsafe alarm relay, do the following: Insert the failsafe alarm relay terminal block into the device and tighten the screws. Figure 2.6 Assembling the Failsafe Alarm Relay Terminal Block Connect a failsafe device to the terminal block. Failsafe Alarm Relay Terminal Block Normally Open Common...

  • Page 23: Connecting Power

    Installing the Device 2.6 Connecting Power Connecting Power The RUGGEDCOM RSG910C features two input terminals that allow the device to be powered by: • Up to one independent AC and one independent DC power source • Two independent DC power sources NOTICE Electrical hazard –...
  • Page 24 Installing the Device 2.6.1 Connecting AC or DC Power • Make sure a terminal block is installed in the unused port and that any wires from the secondary terminal block are properly terminated • Make sure the first power source is off before connecting (or disconnecting) a second power source If connecting a secondary power source, make sure the power source currently connected to the device is disabled (e.g.

  • Page 25: 2.6.2 Wiring Examples

    Installing the Device 2.6.2 Wiring Examples Connect the ground wire to the 5 POS Terminal Block Chassis/Ground Terminal chassis/ground terminal on the Negative Terminal terminal block. Positive Terminal LO DC Power supply Figure 2.9 Terminal Block Wiring Connect the Positive wire to the positive (+) terminal on the terminal block.
  • Page 26 Installing the Device 2.6.2 Wiring Examples HI Power Supply Configurations   Figure 2.11 Single HI AC Power Input Figure 2.12 Single HI DC Power Input Configuration Configuration RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...
  • Page 27 Installing the Device 2.6.2 Wiring Examples   Figure 2.13 Dual HI AC and DC Power Figure 2.14 Dual HI DC Power Supplies Supplies RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...

  • Page 28: Device Management

    Device Management This section describes how to connect to and manage the device. Connecting to the Device The following describes the various methods for accessing the RUGGEDCOM RSG910C console and Web interfaces on the device. For more detailed instructions, refer to the "RUGGEDCOM ROS Configuration Manual" for the RUGGEDCOM RSG910C.

  • Page 29: Configuring The Device

    Device Management 3.2 Configuring the Device Ethernet Ports Connect any of the available Ethernet ports on the device to a management switch and access the RUGGEDCOM RSG910C console and Web interfaces via the device's IP address. The factory default IP address for the RUGGEDCOM RSG910C is https://192.168.0.1.

  • Page 30: Communication Ports

    Communication Ports The RUGGEDCOM RSG910C can be equipped with various types of communication ports to enhance its abilities and performance. Ports 7 to 10 Ports 1 to 6 Figure 4.1 Port Assignment Port Type 7 to 10 SFP Transceiver (1000Base-SX/LX) 1 to 6 Copper (10/100/1000Base-TX) Ethernet Ports Copper Ethernet Ports The RUGGEDCOM RSG910C supports multiple 10/100/1000Base-TX Ethernet ports...

  • Page 31: Sfp Transceivers

    "Copper Ethernet Port Specifications (Page 27)". SFP Transceivers The RUGGEDCOM RSG910C supports up to four Small Form-Factor Pluggable (SFP) transceiver sockets, which are compatible with a wide array of SFP transceivers available from Siemens. RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...
  • Page 32 "RUGGEDCOM SFP Transceiver Catalog [https:// support.industry.siemens.com/cs/ca/en/view/109482309]". Note Only use SFP transceivers approved by Siemens for RUGGEDCOM products. Siemens accepts no liability as a result of performance issues related in whole or in part to third-party components. RUGGEDCOM RSG910C...
  • Page 33 Communication Ports 4.2 SFP Transceivers RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...

  • Page 34: Technical Specifications

    Technical Specifications This section provides important technical specifications related to the device. Power Supply Specifications Note When determining cable lengths, make sure the nominal input voltage for the power supply is provided at the power source. Hazardous Environments Power Input Voltage Internal Isolation Maximum...

  • Page 35: Failsafe Alarm Relay Specifications

    Technical Specifications 5.2 Failsafe Alarm Relay Specifications Failsafe Alarm Relay Specifications Hazardous Environments Maximum Switching Voltage Rated Isolation Switching Current 30 VDC 5.0 kVAC between coil and contacts 1.0 kVAC between contacts 250 VAC 5.0 kVAC between coil and contacts 1.0 kVAC between contacts 50 to 60 Hz for 1 minute Non-Hazardous Environment...

  • Page 36: Copper Ethernet Port Specifications

    Technical Specifications 5.4 Copper Ethernet Port Specifications Standard 10 Mbps 100 Mbps 1000 Mbps Ports Notes Ports Ports IEEE • • • Precision Time Control 1588-2008 (PTP) Version 2 • • • Media Redundancy 62439-2:2016 Protocol (MRP) Copper Ethernet Port Specifications The following details the specifications for copper Ethernet ports that can be ordered with the RUGGEDCOM RSG910C.

  • Page 37: Dimension Drawings

    Technical Specifications 5.7 Dimension Drawings Dimension Drawings Note All dimensions are in millimeters, unless otherwise stated. 162.72 Figure 5.1 Overall Dimensions 38.1 163.12 Figure 5.2 Panel Mount Dimensions RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...
  • Page 38 Technical Specifications 5.7 Dimension Drawings 162.72 Figure 5.3 DIN Rail Mount Dimensions RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...
  • Page 39 Technical Specifications 5.7 Dimension Drawings RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...

  • Page 40: Certification

    Certification The RUGGEDCOM RSG910C device has been thoroughly tested to guarantee its conformance with recognized standards and has received approval from recognized regulatory agencies. Approvals This section details the standards to which the RUGGEDCOM RSG910C complies. 6.1.1 This device meets the requirements of the following Canadian and U.S. standards under certificate CSA 18CA70171440: •...

  • Page 41: 6.1.2 Csa/Sira

    Certification 6.1.2 CSA/Sira • ANSI/UL 60079-15:13 Electrical Apparatus for Explosive Gas Atmospheres – Part 15: Type of Protection "n" The device is marked with a CSA symbol that indicates compliance with both Canadian and U.S. requirements. It is specifically approved for use in Division 2 and Zone 2 hazardous locations with the following markings: •...

  • Page 42: European Union (Eu)

    Electromagnetic compatibility of multimedia equipment – Emission requirements The device is marked with a CE marking and can be used throughout the European community. A copy of the CE Declaration of Conformity is available from Siemens Canada Ltd.. For contact information, refer to "Contacting Siemens (Page vii)".

  • Page 43: 6.1.5 Fda/Cdrh

    Title 21 Code of Federal Regulations (CFR) – Chapter I – Sub-chapter J – Radiological Health 6.1.6 ISED This device is declared by Siemens Canada Ltd. to meet the requirements of the following ISED (Innovation Science and Economic Development Canada) standard: • CAN ICES-3 (A)/NMB-3 (A) 6.1.7...

  • Page 44: Iso

    Certification 6.1.9 ISO A copy of the KC Declaration of Conformity is available from Siemens Canada Ltd.. For contact information, refer to "Contacting Siemens (Page vii)". Notices specific to the RRA: WARNING Class A Equipment (Industrial Broadcasting and Communication Equipment) This device complies with the limits of a Class A electromagnetic wave device and is intended for use outside of a residential environment.

  • Page 45: 6.1.11 Rohs

    Certification 6.1.11 RoHS 6.1.11 RoHS This device is declared by Siemens Canada Ltd. to meet the requirements of the following RoHS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: • China RoHS 2...
  • Page 46 Certification 6.2 EMC and Environmental Type Tests Test Description Test Levels Severity Levels AC Power ± 4 kV @ 2.5 kHz, 5 kHz Ports Earth ± 4 kV @ 2.5 kHz, 5 kHz Ground Ports Surge Signal Ports ± 4 kV Line-to-Ground 61000-4-5 ±...
  • Page 47 Certification 6.2 EMC and Environmental Type Tests Test Description Test Levels Severity Levels AC Power 5 kV   Ports EMC Immunity Type Tests per IEEE 1613 Note RUGGEDCOM products meet Class 1 requirements for copper Ethernet configurations and Class 2 for fiber Ethernet configurations. Class 1 allows for temporary communication loss, while Class 2 requires error-free and interrupted communications.
  • Page 48 Certification 6.2 EMC and Environmental Type Tests Test Description Test Levels Severity Levels IEC 60068-2-2 Dry Heat Test Bd 85 °C (185   °F), 16 Hours Dry Heat Storage Test Bd 85 °C (185   °F), 16 Hours IEC 60068-2-30 Humidity (Damp Test Dd 95% (Non-  ...
  • Page 49 Certification 6.2 EMC and Environmental Type Tests RUGGEDCOM RSG910C Installation Manual, 04/2022, C79000-G8976-1405-11...
  • Page 50 For more information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens Canada Ltd. Digital Industries Process Automation 300 Applewood Crescent Concord, Ontario, L4K 4E5 Canada © 2022 Siemens Canada Ltd. Subject to change...
