Introduction
1.1 Feature Highlights
1.1

Feature Highlights

Ethernet Ports
•
•
•
•
•
•
Rated for Reliability in Harsh Environments
•
•
•
•
•
Power Supply
•
•
•
1.2

Description

The RUGGEDCOM RST916P features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
1
Requires external power supply
2
4 x sockets for SFP/SFP+ transceivers
2 x 10/100/1000Base-T copper Ethernet ports
10 x 10/100/1000Base-T RJ45 802.3af//802.3at/802.3bt compliant Power-over-
Ethernet (PoE) ports
Data and power over a single PoE cable
Auto-sensing ports provide power only to PoE end devices
Compatible with RUGGEDCOM WIN subscriber and base stations
Immunity to EMI and heavy electrical surges
-40 to 85 °C (-40 to 185 °F) ambient operating temperature (no fans)
Die Cast Aluminum
Panel mounting option provides secure mechanical reliability
[Optional] Conformal coated printed circuit boards
Dual redundant power inputs for 54 VDC nominal, 450 W (or greater) power
supplies compliant with IEEE 802.3af/802.3at Type 1 (15 W), IEEE 802.3at Type 2
(30 W), and IEEE 802.3bt Type 3 (60 W)
Terminal blocks for reliable maintenance free connections
CSA/UL 62368-1 safety approved to 85 °C (185 °F)
1
