1.2 Description
Compact 1U form factor
•
Front loading modular design
•
Dual redundant smart power supplies
•
•
•
•
Reliability in harsh environments
•
•
•
•
•
1.2

Description

The RUGGEDCOM RST2228P features various ports, controls and indicator LEDs for
connecting, configuring, and troubleshooting the device.
1
2
1
2
3
4
5
6
7
2
Space-saving design
Allows for simple, cost effective, in-field servicing and upgrading
HI voltage AC/DC: 88-300 VDC or 85-264 VAC
LO voltage DC: 10.5-15 VDC, 13-36 VDC or 36-72 VDC
Smart power supplies able to detect loss of input voltage
Load sharing of 45/55 percent during normal operation
Immunity to EMI and heavy electrical surges
Zero-Packet-Loss technology
Supports Siemens FastConnect RJ45 Cabling System
-40 to 85 °C (-40 to 185 °F) operating temperature (fan-less)
Conformal coated printed circuit boards (optional)
5
3 4 6
Status panel
ACO button
CLP port
USB console port
Failsafe alarm relay terminal block
Main power input terminal block
SFP/SFP+ transceiver sockets
7
9 10
8
9
