4.2
Grasshopper3 PGE Dimensions
Model
GS3-PGE-23S6
GS3-PGE-50S5
GS3-PGE-60S6
GS3-PGE-91S6
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
Figure 4.1: Grasshopper3 PGE Dimensional Drawing
Barrel Length "A"
7.480
8.000
8.400
8.400
Note: To obtain 3D models, go to our
Support.
Grasshopper
4 Grasshopper3 PGE Physical Interface
Downloads
®
3 PGE Technical Reference
site or contact
20
