- Page 1 User’s manual FLIR A400/FLIR A700 series...
- Page 2 Important note Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers. Důležitá poznámka Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se jimi.
-
Page 3: Table Of Contents
Important note about this manual..........5 Note about authoritative versions..........5 Customer help ..................6 General .................. 6 Submitting a question ..............6 Downloads ................6 FLIR’s Partner Network...............7 Introduction ..................8 Example system overviews ............9 6.1.1 Early fire detection............9 6.1.2 Quality assurance ............ - Page 4 Power/Digital I/O connector and cable ......... 39 A-series connection board..............40 13.1 Connection examples .............. 42 Software supporting FLIR A400/FLIR A700 series cameras ....48 Mechanical drawings ............... 49 EU Declaration of conformity ............53 Indicator LEDs and factory reset button ..........55 17.1...
-
Page 5: Disclaimers
1.7 Copyright © 2020 FLIR Systems, Inc. All rights reserved worldwide. No parts of the software in- cluding source code may be reproduced, transmitted, transcribed or translated into any language or computer language in any form or by any means, electronic, magnetic, opti- cal, manual or otherwise, without the prior written permission of FLIR systems. -
Page 6: Safety Information
WARNING Applicability: Digital devices subject to 15.21. NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems may void the FCC authorization to operate this equipment. WARNING Applicability: Digital devices subject to 2.1091/2.1093/KDB 447498/RSS-102. - Page 7 Safety information CAUTION Do not apply solvents or equivalent liquids to the camera, the cables, or other items. For cleaning, refer to 18 Cleaning the camera. CAUTION Do not use too much force when you clean the infrared lens. Damage to the infrared lens or to the anti- reflective coating of the lens can occur.
-
Page 8: Notice To Customer
3.1 Calibration FLIR Systems recommends that you verify your calibration yearly. You can verify the cali- bration yourself or with the help of a FLIR Systems Partner. If preferred, FLIR Systems of- fers a calibration, adjustment, and general maintenance service. -
Page 9: Important Note About This Manual
Notice to customer 3.6 Important note about this manual FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply to your particular camera model. -
Page 10: Customer Help
• The communication protocol, or method, between the camera and your device (e.g., SD card reader, HDMI, Ethernet, USB, or FireWire) • Device type (PC/Mac/iPhone/iPad/Android device, etc.) • Version of any programs from FLIR Systems • Full name, publication number, and revision number of the manual 4.3 Downloads... -
Page 11: Flir's Partner Network
FLIR’s Partner Network We welcome you to join our Partner Network at our Customer Support site! The Partner Network is located on the Partners tab at http://support.flir.com (partner registration needed) and is specifically aimed at distributors and system integrators. Once your company has been approved, you can do one or more of the following, from a single location: •... -
Page 12: Introduction
Introduction The Smart Sensor and Image Streaming cameras of the FLIR A400/FLIR A700 series of- fer unmatched power and flexibility to tailor effective thermal monitoring that improves quality, productivity, maintenance, and safety. • The Smart Sensor cameras analyze the images and then deliver a result to the user. -
Page 13: Example System Overviews
6.1.1 Early fire detection Figure 6.1 Hot spot detection, self-combustible material on conveyor belt 1. Coal mine conveyor belt. 2. FLIR A400/A700 Smart Sensor camera. 3. Ethernet connector, X-coded. 4. Power I/O connector, A-coded. 5. Digital output to a programmable logic controller (PLC). - Page 14 1. Computer running VMS or HMI/SCADA software. 2. CAT-6 Ethernet cable. 3. Industrial Power over Ethernet (PoE) switch. 4. FLIR A400/FLIR A700 Smart Sensor cameras. 5. Industrial process to be monitored, e.g. a coal pile. 6. Example of thermal image.
-
Page 15: Quality Assurance
2. CAT-6 Ethernet cables. 3. Industrial Power over Ethernet (PoE) switches with fiber-optic posts. 4. Fiber-optic cable. 5. FLIR A400/FLIR A700 Image Streaming cameras. 6. Industrial process to be monitored, e.g. items on a conveyor belt. 7. Example of thermal image. -
Page 16: Condition Monitoring
1. Computer running custom-made software. 2. CAT 6 Ethernet cable. 3. Industrial power over Ethernet (PoE) switch. 4. FLIR A400/A700 Image Streaming cameras. 5. Industrial process to be monitored, e.g., a gasifier. 6. Example thermal image. #T810409; r. AB/66574/66574; en-US... -
Page 17: Research & Development
Introduction 6.1.4 Research & development Figure 6.5 Checking heat dissipation on PCB during development 1. Computer running FLIR science software, e.g., FLIR Research Studio. 2. CAT 6 Ethernet cable. 3. Laboratory setup with a FLIR A400/A700 Image Streaming camera. 4. Example thermal image. -
Page 18: Camera Parts
Camera parts Figure 7.1 View from the rear Figure 7.2 View from the front 1. Power/error indicator LED (blue/red). 2. Ethernet communication indicator LED (green). 3. Ethernet/PoE connector, X-coded. 4. Power-I/O connector, A-coded. 5. Antenna. 6. RS232/485 connector, A-coded. 7. Factory reset button. 8. -
Page 19: Camera Installation
Connect the PoE cable to the camera, and then to a PoE switch on the same net- work as the computer. 3. The camera is set to use DHCP. On the computer, use FLIR IP Config to identify the camera on the network, and change the IP settings if necessary. -
Page 20: Mechanical Installation
For further information regarding mounting recommendations, contact FLIR Systems. #T810409; r. AB/66574/66574; en-US... -
Page 21: Rtsp Streams
RTSP Streams It is possible to establish streaming sessions with the Smart Sensor, the Advanced Smart Sensor, and the Advanced Image Streaming cameras of the FLIR A400/FLIR A700 series. The following URLs can be used: • rtsp://<IP>/avc?source=0 • rtsp://<IP>/mpeg4?source=0 • rtsp://<IP>/mjpg?source=0 •... -
Page 22: Camera Web Interface
Follow this procedure: 1. Do one of the following: a. Identify your camera by the MAC address in FLIR IP Config, and then double- click it. b. Type the IP address of your camera into the address bar of a web browser. -
Page 23: Camera Tab
Note Available functionality depends on the type of your FLIR camera; Image Stream- ing camera or Smart Sensor camera. 11.4.1 Working with measurement tools To measure a temperature, you can use one or more measurement tools, e.g., a spot, a... - Page 24 Camera web interface 11.4.1.2 Box A box measurement tool can show the minimum temperature, the maximum temperature, and the average temperature within a selected area of the image. It is possible to have up to ten boxes and masks at the same time. To add a box measurement tool, follow this procedure: 1.
- Page 25 Camera web interface 3. To configure Settings for the tool, click next to the tool in the Active measure- ments section. This displays the Settings dialog box. 3.1. To change the label of the tool, change the Mask name. 3.2. To select what measurement results to display, use the Maximum, Minimum, and Average check boxes.
-
Page 26: Working With Alarms
Camera web interface 2. In the image, click to insert the starting point of the polyline. Move the pointer and click to insert the next point. Continue until you have the desired shape. Finish by clicking Confirm. The tool is labeled with a number, and it is also displayed in the Ac- tive measurements section. - Page 27 Camera web interface When an alarm is triggered, the camera can perform one or more tasks, e.g. save an im- age or video sequence to camera memory, or send the image/video by e-mail to prede- fined recipients or to an FTP site. The camera can also further trigger a variety of external devices, using the digital output.
- Page 28 Camera web interface 11.4.2.2 Setting an alarm based on the digital input To configure an alarm based on the digital input, follow this procedure: 1. In the Active Measurements section, click the plus sign under Add alarm next to the digital input result to be used for the alarm.
-
Page 29: Changing Object Parameters
Camera web interface 5. In the Action section, select which actions the camera will perform when an alarm is triggered: Digital OUT Outputs a digital pulse. Also, type a pulse length (in millisec- onds) in the Pulse time box. E-mail Automatically sends the captured Image, Result, or Video to the recipients defined in Settings >... -
Page 30: Working With Image Modes
2. Change the parameter to the desired value, and then press Enter or click anywhere on the screen. 3. To reset the global parameters to the default values provided by FLIR, click Reset. 11.4.3.2 Local parameters The local parameter settings override the global values. To change the local parameters, follow this procedure: 1. -
Page 31: Colorizing The Image
Camera web interface • FSX (Flexible Scene Enhancement): The camera displays the thermal image with en- hanced image details. To select the image mode, follow this procedure: 1. On the toolbar and in the Data presentation modes section, click Image mode. 2. -
Page 32: Auto-Adjust Region
Camera web interface • Below Applies a contrasting color (blue) to all pixels with a temperature below the specified temperature level. • Interval Applies a contrasting color (yellow) to all pixels with a temperature between two speci- fied temperature levels. To configure an isotherm, follow this procedure: 1. -
Page 33: Calibrating The Camera
Camera web interface 4. To resize the region, click and hold one of the corners of the region in the image, and then move it to the desired size and shape. 5. To remove the region, click X in the region label. 11.4.7 Calibrating the camera The calibration of the camera is performed as a non-uniformity correction (NUC). -
Page 34: Flipping The Image
Camera web interface The temperature scale is located to the right of the live image. When a temperature level is manually adjusted, the Auto button is displayed next to the temperature scale box. To manually adjust the image, follow this procedure: 1. -
Page 35: Saving A Snapshot
Camera web interface 11.4.12 Saving a snapshot It is possible to take a snapshot and save the image with the current measurement re- sults. The image can later be viewed and managed on the Library tab. Up to 100 images can be saved. -
Page 36: Ssl Certificates
Note When altering the network settings, the address of the camera might change. Make sure your settings are correct before saving them or the camera might not be reachable afterwards. If this occurs, you can use FLIR IP Config to locate the camera again or reset the camera to its default settings. -
Page 37: System And Firmware
Camera web interface 11.5.7.1 Ethernet setup Follow this procedure: 1. In the navigation pane, click Network settings. 2. Select one of the following: • To automatically obtain an IP address for the camera, click Obtain IP address au- tomatically (DHCP). •... -
Page 38: Settings Tab
Camera web interface 1. In the navigation pane, click System and firmware. 2. In the System section, click Reset to factory settings. This displays a dialog box. 3. In the dialog box, click OK. The camera will restart. 11.5.8.3 Upgrade camera firmware Follow this procedure: 1. -
Page 39: Alarm Recipients
Camera web interface 11.6.2 Alarm recipients Use the Alarm recipients page to configure alarm notifications. Notifications can be sent by e-mail or to a folder on an FTP server. To configure delivery by e-mail, follow this procedure: 1. In the navigation pane, click Alarm recipients. 2. -
Page 40: Mqtt
The topics will be updated when the data is updated, for ex- ample; if you subscribe to the topic FLIR/ec501-xxxxxx/alarm1, your MQTT client will receive an update when alarm1 is triggered and then another update when alarm1 criteria are no longer fulfilled. -
Page 41: Screening
Camera web interface 4. Type the following information: 4.1. Select which Measurement function and Update interval (ms) to use. The Up- date interval (ms) defines how often a new value is sent over Modbus to the external analogue output box. 4.2. -
Page 42: Pin Configurations
Pin configurations 12.1 Ethernet connector and cable Configuration Figure 12.1 Female X-coded M12 Ethernet connector Figure 12.2 Ethernet cable M12 to RJ45 #T810409; r. AB/66574/66574; en-US... -
Page 43: Power/Digital I/O Connector And Cable
Pin configurations 12.2 Power/Digital I/O connector and cable Configuration EXTPWR_RTN EXTPWR_IN FAULT_A FAULT_B DIGOUT1A DIGOUT1B DIGOUT2A DIGOUT2B DIGIN1 DIGIN2 Not Connected DIGIN_RTN Figure 12.3 Male A-coded M12 Power/Digital I/O connector Section A—A Wire colour Black Green Purple Yellow Pink Orange Figure 12.4 Cable M12 to pigtail Brown White... -
Page 44: Series Connection Board
A-series connection board The A-series connection board is an accessory designed for the FLIR A400/FLIR A700 cameras. It can be used to test functionality and digital connections to/from the camera. Figure 13.1 A-series connection board For schematics and connection examples, see the next pages. -
Page 46: Connection Examples
A-series connection board 13.1 Connection examples (See next page) #T810409; r. AB/66574/66574; en-US... -
Page 52: Software Supporting Flir A400/Flir A700 Series Cameras
Software supporting FLIR A400/ FLIR A700 series cameras The following table explains which software supports FLIR A400/FLIR A700 series cameras: Software Support Comment FLIR IP Config • Detecting FLIR A400/FLIR A700 series cameras on the network. Note Use FLIR IP Config ver- •... -
Page 53: Mechanical Drawings
Mechanical drawings (See next page) #T810409; r. AB/66574/66574; en-US... -
Page 57: Eu Declaration Of Conformity
EU Declaration of conformity [See next page] #T810409; r. AB/66574/66574; en-US... - Page 58 This declaration of conformity is issued under the sole responsibility of the manufacturer. The object of the declaration: FLIR A4XX-, A7XX-series and GF7Xa (Product Model Name FLIR-A8590). The object of the declaration described above is in conformity with the relevant Union harmonisation...
-
Page 59: Indicator Leds And Factory Reset Button
Indicator LEDs and factory reset button For location of the indicator LEDs and the factory reset button, see Figure 7.1 View from the rear, page 14. 17.1 Power/error indicator LED and factory reset button Note Do not hold down the factory reset button when connecting the camera to power. Factory reset button Indicator LED status Explanation... -
Page 60: Cleaning The Camera
Cleaning the camera 18.1 Camera housing, cables, and other items 18.1.1 Liquids Use one of these liquids: • Warm water • A weak detergent solution 18.1.2 Equipment A soft cloth 18.1.3 Procedure Follow this procedure: 1. Soak the cloth in the liquid. 2. -
Page 61: About Calibration
19.3 Camera calibration at FLIR Systems Without calibration, an infrared camera would not be able to measure either radiance or temperature. At FLIR Systems, the calibration of uncooled microbolometer cameras with a measurement capability is carried out during both production and service. Cooled cam- eras with photon detectors are often calibrated by the user with special software. -
Page 62: The Differences Between A Calibration Performed By A User And That Performed Directly At Flir Systems
The calibration information, no matter if the calibration is done by FLIR Systems or the user, is stored in calibration curves, which are expressed by mathematical functions. As... -
Page 63: Non-Uniformity Correction
About calibration Calibration is also a prerequisite for adjustment, which is the set of operations carried out on a measuring system such that the system provides prescribed indications corre- sponding to given values of quantities to be measured, typically obtained from measure- ment standards. -
Page 64: About Flir Systems
• Extech Instruments (2007) Figure 20.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a manufacturing plant in Tallinn, Estonia. -
Page 65: More Than Just An Infrared Camera
20.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infra- red camera systems. We are committed to enabling all users of our infrared camera sys- tems to work more productively by providing them with the most powerful camera–... -
Page 66: Supporting Our Customers
20.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equipment and expertise to solve it within the shortest possible time. - Page 67 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T810409...
