Gs3-Pge-50S5 Specifications - FLIR GRASSHOPPER 3 Series Technical Reference

1.2

GS3-PGE-50S5 Specifications

Firmware
Resolution
Frame Rate
Megapixels
Chroma
Sensor
Readout Method
Pixel Size
Lens Mount
Gain Range
Exposure Range
Trigger Modes
Partial Image Modes
Image Processing
User Sets
Flash Memory
Opto-isolated I/O Ports
Non-isolated I/O
Serial Port
Auxiliary Output
Interface
Power Requirements
Power Consumption
Dimensions/Mass
Machine Vision
Standard
Compliance
Temperature
Humidity
Warranty
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
GS3-PGE-50S5M-C
1.6.3.0
2448 x 2048
15 FPS
5.0 MP
Mono
Sony ICX625, CCD, 2/3"
Global shutter
3.45 µm
C-mount
ADC 14-bit
-6.510 dB to 24 dB, increment 0.985 dB
0.030 ms to 32 seconds
Standard, bulb, low smear, overlapped, multi-shot
Pixel binning, ROI
Gamma, lookup table, and sharpness
2 memory channels for custom camera settings
2 MB non-volatile memory
1 input, 1 output
2 bi-directional
1 (over non-isolated I/O)
3.3 V, 150 mA maximum
GigE PoE
Power over Ethernet or 12 V nominal, 8 - 24 V
<4.7 W maximum
44 mm x 29 mm x 58 mm/90 grams
GigE Vision v1.2
CE, FCC, KCC, RoHS. The ECCN for this product is:
EAR099.
Operating: 0° to 50°C
Storage: -30° to 60°C
Operating: 20% to 80% (no condensation)
Storage: 20% to 95% (no condensation)
3 years
Grasshopper
1 Grasshopper3 PGE Specifications
-6.510 dB to 24 dB, increment 0.985 dB
Standard, bulb, low smear, overlapped, multi-shot
Gamma, lookup table, hue, saturation, and sharpness
2 memory channels for custom camera settings
Power over Ethernet or 12 V nominal, 8 - 24 V
CE, FCC, KCC, RoHS. The ECCN for this product is:
Operating: 20% to 80% (no condensation)
Storage: 20% to 95% (no condensation)
®
3 PGE Technical Reference
GS3-PGE-50S5C-C
1.6.3.0
2448 x 2048
15 FPS
5.0 MP
Color
Sony ICX625, CCD, 2/3"
Global shutter
3.45 µm
C-mount
14-bit
0.030 ms to 32 seconds
Pixel binning, ROI
2 MB non-volatile memory
1 input, 1 output
2 bi-directional
1 (over non-isolated I/O)
3.3 V, 150 mA maximum
GigE PoE
<4.7 W maximum
44 mm x 29 mm x 58 mm/90 grams
GigE Vision v1.2
EAR099.
Operating: 0° to 50°C
Storage: -30° to 60°C
3 years
