8.8

Brightness

Brightness, also known as offset or black level, controls the level of black in an image.
The camera supports brightness control.
GenICam—Analog Control
n
FlyCapture
n
8.9

Exposure Time

The Grasshopper3 PGE supports Continuous, Off, and Once control of the image sensor exposure time.
Exposure times are scaled by the divider of the basic frame rate. For example, dividing the frame rate by two (e.g.
15 FPS to 7.5 FPS) causes the maximum exposure time to double (e.g. 66 ms to 133 ms).
The maximum exposure time can be extended beyond the normal range by disabling the frame rate. Once the
frame rate is disabled, you should see the maximum value of the exposure time increase.
The supported exposure time range is:
GS3-PGE-23S6M-C
GS3-PGE-23S6C-C
GS3-PGE-50S5M-C
GS3-PGE-50S5C-C
GS3-PGE-60S6M-C
GS3-PGE-60S6C-C
GS3-PGE-91S6M-C
GS3-PGE-91S6C-C
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
API—Setting Brightness Using the FlyCapture API
Note: The terms "integration", "exposure" and "shutter" are
interchangeable.
Model
0.017 ms to 32 seconds
0.017 ms to 32 seconds
0.030 ms to 32 seconds
0.030 ms to 32 seconds
0.040 ms to 4 seconds (extended to 32 seconds in mode 7)
0.040 ms to 4 seconds (extended to 32 seconds in mode 7)
0.040 ms to 32 seconds
0.040 ms to 32 seconds
Note: The exposure range may vary depending on the video
mode. For more information, see
Grasshopper3 cameras the maximum range is in Mode 7. For
the GS3-PGE-23S6 models, maximum exposure can be
achieved when packet size is set to minimum.
Grasshopper
8 Grasshopper3 PGE Attributes
Range
Video Modes Overview. For
®
3 PGE Technical Reference
Firmware
1.11.3.0
1.11.3.0
1.6.3.0
1.6.3.0
1.9.3.0
1.9.3.0
1.5.3.0
1.5.3.0
