E.6

VMODE_ERROR_STATUS: 628h

Format:
Field
Vmode_Error_Status
E.7 CAMERA_LOG: 1D00 – 1DFFh
Format:
Offset
1D00..1DFF
E.8

LED_CTRL: 1A14h

Format:
Field
Presence_Inq
LED_Ctrl
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
Bit
Error status of combination of video format, mode, frame rate and ISO_SPEED
setting.
[0] 0: no error, 1: error
This flag will be updated every time one of the above settings is changed by writing
a new value.
[1-31] Reserved.
Each byte is the hexadecimal representation of an ASCII character. The log is in reverse byte order,
with the latest entry at the beginning of the log. The most significant byte of address 1D00h is the
last byte in the log.
Note: On GigE Vision cameras, this register enables or disables
both the main camera status LED and the GigE connector
indicator LEDs, if equipped.
Bit
Presence of this feature
[0]
0: Not Available, 1: Available
[1-22] Reserved
Enable or disable the LED
[23-31]
0x00: Off, 0x74: On
Grasshopper
E Control and Status Registers
Description
Description
Description
®
