About This Manual - FLIR GRASSHOPPER 3 Series Technical Reference

About This Manual

This manual provides the user with a detailed specification of the Grasshopper3 PGE camera system. The user
should be aware that the camera system is complex and dynamic – if any errors or omissions are found during
experimentation, please contact us.
This document is subject to change without notice.
Where to Find Information
Chapter
Grasshopper3 PGE
Specifications
Grasshopper3 PGE
Installation
Tools to Control the
Grasshopper3 PGE
Grasshopper3 PGE Physical
Interface
General Grasshopper3 PGE
Operation
Input/Output Control
Image Acquisition
Grasshopper3 PGE
Attributes
Troubleshooting
Appendix: FlyCapture API
Code Samples
Appendix: FlyCapture SDK
Examples
Appendix: GenICam
Features
Appendix: GigE Vision
Bootstrap Registers
Appendix: Control and
Status Registers
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
Note: All model-specific information presented in this manual
reflects functionality available in the model's firmware version.
For more information see
General camera specifications and specific model specifications, and camera
properties.
Instructions for installing the Grasshopper3 PGE, as well as introduction to
Grasshopper3 PGE configuration.
Information on the tools available for controlling the Grasshopper3 PGE.
Information on the mechanical properties of the Grasshopper3 PGE.
Information on powering the Grasshopper3 PGE, monitoring status, user
configuration sets, memory controls, and firmware.
Information on input/output modes and controls.
Information on asynchronous triggering and supported trigger modes.
Information on supported imaging parameters and their controls.
Information on how to get support, diagnostics for the Grasshopper3 PGE, and
common sensor artifacts.
Examples of FlyCapture API code.
Sample programs provided with the FlyCapture SDK.
Information on GenICam Feature controls.
Information on GigE Vision Bootstrap Registers.
Information on IIDC Control and Status Registers for functions not handled via
FlyCapture API.
Grasshopper
Camera Firmware.
What You Will Find
®
3 PGE Technical Reference
