Digital Input Output Control - FLIR GRASSHOPPER 3 Series Technical Reference

pgrAutoExposureCompensationLowerLimit
pgrAutoExposureCompensationUpperLimit
C.5

Digital Input Output Control

Name
LineSelector
LineMode
LineSource
LineInverter
StrobeEnabled
UserOutputValue
LineDebounceTime
LineStatus
LineStatusAll
StrobeDuration
ExposureActiveMode
3.3VEnable
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
Name
Auto Exposure
Compensation Lower
Limit
Auto Exposure
Compensation Upper
Limit
Display Name
Selects the physical line (or GPIO pin) of
+ Line Selector the external device connector to
configure.
Controls whether the physical line is used
Line Mode to Input or Output a signal. Choices are
dependent on which line is selected.
Selects which input or output signal to
Line Source output on the selected line. Line Mode
must be Output.
Controls the invertion of the signal of the
Line Inverter
selected input or output line
Strobe Enabled Enables/disables strobe
User Output Value Sets the value of the user output selector
Line Debounce Sets the value of the selected line
Time debouncer time in microseconds
Returns the current status of the selected
Line Status
input or output line
Returns the current status of all available
Line Status All line signals at time of polling in a single
bitfield
Outputs a specified number of pulses
Strobe Duration
with programmable high and low duration
If the camera supports rolling shutter with
a global reset, the strobe can be set to
active from the start of exposure of the
Exposure Active
first line to the end of exposure on the
Mode
last line (Any pixel) or from the start of
exposure on the last line to the end of
exposure on the first line (All pixels).
3.3 V Enable Enable or disable 3.3 V output
Grasshopper
Display Name
Lower limit of the auto
exposure compensation
value(EV) parameter
Upper limit of the auto
exposure compensation
value(EV) parameter
Description
®
3 PGE Technical Reference
C GenICam Features
Description Value
Value
Line 0
Line 1
Line 2
Line 3
Input
Trigger
Strobe
Output
Exposure Active
External Trigger Active
True
False
True
False
True = High
False = Low
True = High
False = Low
00: Line 1 Exposed
01: Any pixel exposed
(only for global reset
mode)
10: All pixels exposed
(same as Line 1 for global
reset mode)
106
