Lut Control - FLIR GRASSHOPPER 3 Series Technical Reference

C.9

LUT Control

Name
LUTSelector
LUTEnable
LUTIndex
LUTValue
LUTValueAll
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
Display
Name
Selects which LUT to control. Typically not available when
LUT Selector
only a single LUT is supported.
LUT Enable Activates the selected LUT
Controls the index (offset) of the coefficient to access in the
LUT Index
selected LUT
Returns the Value at entry LUTIndex of the LUT selected by
LUT Value
LUTSelector
Accesses all the LUT coefficients in a single access without
Lut Value All
using individual LUTIndex
Grasshopper
Description
®
3 PGE Technical Reference
C GenICam Features
Value
Luminance
Red
Green
Blue
Device-
Specific
True
False
≥0
Device-
specific
Device-
specific
112
