7. TECHNICAL SPECIFICATIONS

Accuracy calculated as [%reading + (num. digits*resolution)] at 18°C
DC Voltage
Range Resolution
600.0mV 0.1mV
6.000V 0.001V
60.00V 0.01V
600.0V 0.1V
1500V 1V
AC TRMS Voltage
Range Resolution
6.000V 0.001V
60.00V 0.01V
600.0V 0.1V
1.000V 1V
(*) Accuracy specified from 10% to 100% of the measuring range, Input impedance: > 9M , sinusoidal waveform
Accuracy of PEAK function: ±(10%reading), Response time of PEAK function: 1ms
For a non-sinusoidal waveform, accuracy is: (10.0%rgd + 20digits)
Integrated NCV sensor for AC voltage detection: LED on for phase-earth voltage in range 100V - 1000V, 50/60Hz.
AC+ DC TRMS Voltage
Range Resolution
6.000V 0.001V
60.00V 0.01V
600.0V 0.1V
1.000V 1V
AC TRMS Voltage with low impedance (LoZ)
Range Resolution
6.000V 0.001V
60.00V
600.0V
1000V
(*) Accuracy specified from 10% to 100% of the measuring range ssinusoidal waveform
For a non-sinusoidal waveform, accuracy is: (10.0%rgd + 20digits)
AC+DC TRMS Voltage with low impedance (LoZ)
Range Resolution
6.000V 0.001V
60.00V
600.0V
1000V
Accuracy
(0.8%rdg + 8dgt)
(0.5%rdg + 5dgt)
(0.8%rdg + 5dgt)
(0.8%rdg + 5dgt)
(50Hz 60Hz)
(1.2%reading + 5digits)
Accuracy
(50Hz 1kHz)
(2.5%reading+20digits)
Accuracy (*)
(50Hz 1kHz)
0.01V
(3.0%readings+20dgt)
0.1V
1V
Accuracy
(50Hz 1kHz)
0.01V
(3.5%readings+40dgt)
0.1V
1V
Input impedance
>10M
Accuracy (*)
(61Hz 1kHz)
(2.5%reading+5digits) 1000VDC/ACrms
Input impedance
>10M
Input impedance
300k
Input impedance
<300k
EN - 41
ECLIPSE - HT9025
28°C <75%RH.
Overload
protection
1500VDC
Overload
protection
Overload
protection
1000VDC/ACrms
Overload
protection
1000VDC/ACrms
Overload
protection
1000VDC/ACrms
