Infrared temperature (ECLIPSE)
Type of IR sensor
Spectrum response
Visual range (FOV) / Lens
IFOV (@1m)
Thermal sensitivity / NETD
Focusing
Minimum focus distance
Image frequency
Temperature readings
Available color palettes
Laser pointer
Built-in illuminator
Emissivity correction
Measuring cursors
Measuring range
Accuracy
General characteristics
Reference standards
Safety:
EMC:
Insulation:
Pollution level:
Measurement category:
Max operating altitude:
Mechanical characteristics
Size (L x W x H):
Weight (battery included):
Mechanical protection:
Max conductor size:
Power supply
Battery type:
Battery charger power supply:
Low battery indication:
Recharging time:
Battery duration:
Auto Power Off (disabled):
Display
Conversion:
Characteristics:
Sampling frequency:
External memory
Internal memory
UFPA (80x80pxl, 34 m)
8 14 m
21°x 21° / 7.5mm
4.53mrad
<0.1°C (@30°C /86°F) / 100mK
automatic
0.5m
50Hz
°C,°F, K
5 (Iron, Rainbow, Grey, Reverse grey, Feather)
class 2 according to IEC 60825-1
white-light LED
0.01 ÷ 1.00 in steps of 0.01
3 (Fixed, Max Temp., Min Temp.)
-20°C ÷ 260°C (-4°F ÷ 500°F)
±3%reading or ±3°C (±5.4°F) (environmental
temperature 10°C ÷ 35°C, object temperature >0°C)
IEC/EN61010-1
IEC/EN61326-1
double insulation
2
CAT IV 600V, CAT III 1000V
2000m (6562ft)
280 x 100 x 50mm (11 x 4 x 2in)
505g (18 ounces)
IP40
40mm (2in)
1x7.4V rechargeable Li-ION battery, 1200mAh
100/240VAC, 50/60Hz, 12VDC, 2A
symbol " " on the display
approx. 2 hours
approx. 8 hours (Bluetooth deactivated)
approx. 7 hours (active Bluetooth)
after 15 60min minutes' idling
TRMS
color TFT, 6000 dots with bargraph
3 times/s
max 128 snapshots in BMP format
max 16 recordings or 34 hours (SI=1s),
sampling interval: 1s ÷ 15min
duration single recording: max 10 hours
