5.11. INRUSH CURRENT MEASUREMENT

Make sure that all the test leads are disconnected from the meter terminals
for current measurement.
Fig. 33: Use of the instrument for AC Inrush current measurement
1. Select positions 60A
2. Press the MODE/VFD key to select
3. Long press the key
symbols appears at display (see Fig. 33 – left side)
4. Put the conductor to be tested inside to the center of clamp jaw (see Fig. 33 – right
side) in order to perform accurated measurements. Consider the notches on jaws as
reference (see Fig. 3)
5. The display shows the value of inrush current.
6. If the display shows the message
reached.
7. To use the HOLD function, see § 4.2
8. To use the internal functions, see § 4.3
9. To save the measured result, see § 4.3.4
, 600A or 1000A
A
" "
/INRUSH to activate the "INRUSH" function. The "
OL
" "
EN - 31
CAUTION
measurement
, the maximum measurable value has been
ECLIPSE - HT9025
" and "- - - -"
