4. NOMENCLATURE

4.1.

DESCRIPTION OF THE INSTRUMENT

Fig. 1: Description of the instrument
EN - 7
ECLIPSE - HT9025
CAPTION:
1. Inductive clamp jaw
2. DC Current positive
polarity
3. AC Voltage NCV detector
4. Jaw trigger
5. LCD display
6. Key MODE/VFD
7. Key HOLD/REL
8. Key /INRUSH
9. Key RANGE
10. Key IR/ (ECLIPSE)
Key (HT9025)
11. Rotary selector switch
12. Input terminal COM
13. Input terminal
VHz% CAP
s front
'
