HT ECLIPSE HT9025 User Manual page 39

In the representation, it is possible to see how the IFOV (Instant Field Of View =
geometrical resolution of the instrument = size of the single pxl of the IR sensor) is equal
to 4.53mm at a distance of 1m of the instrument from the object being measured. This
means that the instrument is capable of carrying out correct temperature measurements at
a distance of 1m on objects with a size not lower than 4,53mm.
9. Press key HOLD/REL to freeze the result. Message
on the display (see Fig. 45)
10. Press key to save the value as a BMP image on the instrument
press key HOLD/REL again to quit the function.
11. Enter the General menu to display the saved result (see Fig. 46
12. Press key HOLD/REL to select the "Delete" option and confirm with key MOD/VFD
screen
13. Use the arrow keys
mobile devices through the APP HTMercury and Bluetooth connection (see § 5.15)
Fig. 45: Saving IR images
Fig. 46: Recalling and deleting IR images
or to select the option
EN - 38
HOLD and SAVE
" "
s internal memory or
'
left side)
–
Share in order to share the image on
" "
ECLIPSE - HT9025
key appears
