HT ECLIPSE HT9025 User Manual page 44

Frequency (electrical circuits)
Range
40.00Hz 10kHz
Sensitivity: 2Vrms
Frequency (electronic circuits)
Range
60.00Hz
600.0Hz
6,000kHz
60.00kHz
600.0kHz
6,000MHz
10.00MHz
Sensitivity: >2Vrms (@ 20%
Resistance and Continuity test
Range Resolution
600.0 0.1
6.000k 0.001k
60.00k 0.01k
600.0k 0.1k
6.000M 0.001M
60.00M 0.01M
Duty Cycle
Range
10.0% 90.0%
Pulse frequency range: 40Hz
Capacitance
Range Resolution
60.00nF 0.01nF
600.0nF 0.1nF
6.000 F 0.001 F
60.00 F 0.01 F
600.0 F 0.1 F
6000 F 1 F
60.00mF 0.01mF
100.0mF 0.1mF
Temperature with K-type probe
Range
-40.0°C ÷ 600.0°C
601°C ÷ 1000°C
-40.0°F ÷ 600.0°F
601°F ÷ 1800°F
245.0K ÷ 600.0K
601K ÷ 1273K
(*) Instrument accuracy without probe ; Specified accuracy with stable environmental temperature at ±1°C
Resolution
0.01Hz 0,001kHz
Resolution
0.01Hz
0.1Hz
0,001kHz
0.01kHz
0.1kHz
0,001MHz
0.01MHz
80% duty cycle) and f<100kHz; >5Vrms (@ 20%
Accuracy
(1.0%rgd + 10digits)
(0.8%reading + 5digits)
(2.5%rgd + 10digits)
Resolution
0.1%
10kHz, Pulse amplitude: ±5V (100 s
Accuracy
(3.0%rdg + 20dgt)
(3.0%rdg + 8dgt)
(3.5%rdg + 20dgt)
(5.0%rdg + 40dgt)
Resolution Accuracy (*)
0.1°C
(1.5%rdg + 3°C)
1°C
0.1°F
(1.5%rdg+ 5.4°F)
1°F
0.1K
(1.5%rdg+ 3K)
1K
Accuracy
(0.5%reading)
Accuracy
(0.2%rdg+5digits)
80% duty cycle) and f>100kHz
Buzzer
<50
100ms)
EN - 43
ECLIPSE - HT9025
Overload protection
1000VDC/ACrms
Overload
protection
1000VDC/ACrms
Overload
protection
1000VDC/ACrms
Accuracy
(1.2%rdg + 8digits)
Overload protection
1000VDC/ACrms
Overload protection
1000VDC/ACrms
