3.3 Order code of Temposonics
1 2 3 4 5
R D 4
a b
a Sensor model
R D
4 Detached sensor electronics
b Design
C Threaded flange M18×1.5-6g, A/F 46
D Threaded flange ¾"-16 UNF-3A, A/F 46
G Threaded flange M18×1.5-6g, A/F 24
M Threaded flange M18×1.5-6g, A/F 23
S Pressure fit flange Ø 26.9 mm f6
T Threaded flange ¾"-16 UNF-3A, A/F 23
c Integral cable of sensor rod
For side cable entry on sensor electronics housing
D 1 S PUR cable with M16 connector, length 250 mm (9.8 in.)
D 2 S PUR cable with M16 connector, length 400 mm (15.7 in.)
D 3 S PUR cable with M16 connector, length 600 mm (23.6 in.)
For bottom cable entry on sensor electronics housing
R 2 B PUR cable / wires with flat connector, length 65 mm (2.6 in.)
R 4 B PUR cable / wires with flat connector, length 170 mm (6.7 in.)
R 5 B PUR cable / wires with flat connector length 230 mm (9.1 in.)
R 6 B PUR cable / wires with flat connector, length 350 mm (13.8 in.)
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments
5/ Note: Specify magnet number for your sensing application and order separately
RD4
®
6 7 8 9 10 11 12
c d
13 14 15 16 17 18 19
D 5 6 U 3 0
e
f
d Stroke length
X M Flange »C«, »D«, »G«, »M«, »T«:
X X X
0025...5080 mm
Flange »S«: 0025...2540 mm
Standard stroke length (mm)*
25...500 mm
500...750 mm
750...1000 mm
1000...2500 mm
2500...5080 mm
X U Flange »C«, »D«, »G«, »M«, »T«:
X X X .
001.0...200.0 in.
Flange »S«: 001.0...100.0 in.
Standard stroke length (in.)*
100...200 in.
200...300 in.
e Connection type
D 5 6 2 × M12 female connectors (4 pin),
1 × M8 male connector (4 pin)
Operating voltage
+24 VDC (−15 / +20 %); Standard, not indicated in order code
f Output
1 Powerlink V2
U 3 0
Optional:
g Magnet number for multi-position measurement
Z 0 2 2 magnets
Z 0 3 3 magnets
Z 0 4 4 magnets
I 7 I
Temposonics R-Series Powerlink V2
®
20 21 22
1
g
optional
Ordering steps
5 mm
10 mm
25 mm
50 mm
100 mm
Ordering steps
1...20 in. 0.2 in.
20...30 in. 0.4 in.
30...40 in. 1.0 in.
40...100 in. 2.0 in.
4.0 in.
10.0 in.
