- Page 1 Temposonics ® Magnetostrictive Linear Position Sensors OPERATION MANUAL High Pressure Housing (HPH) ATEX The Measurable Difference...
-
Page 2: Technical Data
PRECISION POSITION MEASUREMENT – HPH This High Pressure Housing (HPH) is ATEX-IECEx as well as UL and Safety Instructions cUL approved for use in hazardous locations with Temposonics The sensor must only be used according to the EX-certifi cate no. ®... -
Page 3: Technical Drawing
Operation Manual High Pressure Housing TECHNICAL DRAWING Mounting Damping 147…198 Zone Zone 19.5 Measuring Length 50…7500 Zone 1 Zone 0 * Measuring length > 5000 mm = 66 mm Top mounted cable gland Side mounted cable gland Ø 85 Ø 85 Ø... - Page 4 The normal way is that the sensor and the HPH housing are in one order and then MTS Sensors supply the sen- sor mounted in the WPH housing. Go to step 7.
- Page 5 Operation Manual High Pressure Housing Assemble the top and bottom turning clockwise. Tighten firmly until the top and bottom flanges come together. Tighten gable gland according to the manufacturer’s specifications. Side mounted cable gland(s) Enter the cable through the gland without tightening. For cable sizes larger than 7mm or very rigid cables, you may need to remove the outer insulation jacket from inside the cable gland to the connector...
- Page 6 Operation Manual High Pressure Housing Insert and fasten the sensor. Make the connections. Insert a bag of Desiccant in the top. Assemble the top and bottom turning clockwise and tighten firmly until top and bottom flanges come together. (see fig. 11) Tighten the cable glands according to manufacturer‘s specifications.
- Page 7 Operation Manual High Pressure Housing ACCESSORIES Position magnet Cable glands ATEX Ø 32.8 Ø 4.3 Ø 23.8 Ø 13.5 Ring magnet OD33 M20 × 1,5 M20 × 1,5 ½" NPT cable gland ATEX/CSA US, Part no. 201 542-2 Part no. CG-816679 Part no.
- Page 8 Document Part Number: 551751 Revision A (EU.EN) 07/2014 GERMANY FRANCE MTS and Temposonics are registered trademarks of MTS Systems Corporation. All other ® MTS Sensor Technologie MTS Systems SAS trademarks are the property of their respective owners. Printed in Germany. Copyright ©...
