MTS Sensors Temposonics Powerlink V2 R Series Operation Manual page 11

4.3 Styles and installation of Temposonics
RH-H / -M / -S / -V
53
(2.09)
RH-D
RH-T / -U
51.3
(2.02)
RH-R
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
Fig. 6: Temposonics
® RH with ring magnet part 1
RH
®
Sensor electronics housing
133
(5.24)
18
(0.71)
Null zone
51
(2.01)
10
(0.4)
A/F 46
25
Flange
(0.98)
Flange
A/F 46
Flange:
M18×1.5-6g
Null zone
51
9.65
(0.38) (2.01)
7.11
(0.28)
A/F 44.5
A/F 46
Flange:
M18×1.5-6g
I 11 I
Temposonics R-Series Powerlink V2
®
Stroke length Dead zone
25...7620 63.5 / 66*
(1...300) (2.5 / 2.6* )
»M« / »V«: M18×1.5-6g
»S« / »H«: ¾"-16 UNF-3A
* Stroke length > 5000 mm (196.9 in.)
Dead zone
63.5 / 66*
(2.5 / 2.6*)
Ø 10 3
»D«
(Ø 0.39) (0.12) (0.87)
* Stroke length > 5000 mm (196.9 in.)
Stroke length Dead zone
25...7620 63.5 / 66*
(1...300) (2.5 / 2.6* )
Flange »T« / »U«:
¾"-16 UNF-3A
* Stroke length > 5000 mm (196.9 in.)
Dead zone
70 / 72.5*
(2.76 / 2.85*)
»R«
3.5
(0.14) (0.24)
* Stroke length > 5000 mm (196.9 in.)
Operation Manual
8
(0.31)
22 15
(0.59)
M4 thread
6
