Temposonics R-Series Powerlink V2
®
Operation Manual
11.2 Technical data of Temposonics
Output
Interface
Data protocol
Measured value
Measurement parameters
Resolution
Cycle time
Linearity
11
Repeatability
Hysteresis
Temperature coefficient
Operating conditions
Operating temperature
Humidity
Ingress protection
12
Shock test
Vibration test
EMC test
Operating pressure
Magnet movement velocity
Design / Material
Sensor electronics housing
Sensor flange
Sensor rod
Stroke length
Mechanical mounting
Mounting position
Mounting instruction
Electrical connection
Connection type
Operating voltage
13
Ripple
Current consumption
13
Dielectric strength
Polarity protection
Overvoltage protection
11/ With position magnet # 251 416-2
12/ The IP rating is not part of the UL approval
13/ Power supply must be able to provide current of 1 A for power up process
RH
®
Ethernet POWERLINK
POWERLINK V2 according to IEEE 802.3
Position, velocity / option: multi-position measurement (2...4 positions)
1 μm, 2 μm, 5 μm, 10 μm, 50 μm or 100 μm (selectable)
1.0 ms up to 2400 mm stroke length,
2.0 ms up to 4800 mm stroke length,
4.0 ms up to 7620 mm stroke length
< ±0.01 % F.S. (minimum ±50 µm)
< ±0.001 % F.S. (minimum ±2.5 µm) typical
< 4 µm typical
< 15 ppm/K typical
−40...+75 °C (−40...+167 °F)
90 % rel. humidity, no condensation
IP67 (if mating connectors are correctly fitted)
100 g (single shock), IEC standard 60068-2-27
15 g (10...2000 Hz), IEC standard 60068-2-6 (resonance frequencies excluded)
Electromagnetic immunity EN 61000-6-2
Electromagnetic emission EN 61000-6-3
The sensor meets the requirements of the EC directives and is marked with
350 bar (5076 psi); Peak: 700 bar (10 007 psi); RH-J: Peak 800 bar (13053.4 psi)
Any
Aluminum
Stainless steel 1.4305 (AISI 303) / RH-J: Stainless steel 1.4305 (AISI 303)
Stainless steel 1.4306 (AISI 304L) / RH-J: Stainless steel 1.4301 (AISI 304)
25...7620 mm (1...300 in.)
Any
Please consult the technical drawings
2 × M12 female connector (4 pin), 1 × M8 male connector (4 pin)
+24 VDC (−15 / +20 %); UL Recognition requires an approved power supply with energy limitation
(UL 61010-1), or Class 2 rating according to the National Electrical Code (USA) / Canadian Electrical Code.
≤ 0.28 V
PP
110 mA typical
500 VDC (DC ground to machine ground)
Up to −30 VDC
Up to 36 VDC
